FIRE ALARM ACCESSORY Slave Communicator solution to most fire applications 5128 and 5129 5128 29 are four channel slave fire communicators designed to monitor UL listed local fire systems The 5128 29 are a cost effective answer to most fire communicator applications and are easy to and service Silent Knight knows digital communication With hundreds of thousands of our worldwide it shows more information about the IntelliKnight system or to locate your nearest source please call 5128 29 fire communicators four fully supervised channel to monitor UL listed fire alarm The 5128 comes in a vinyl acrylic enclosure for mounting in fire alarm control panel FACP The 5128 can report AC power using a dry contact active high input The 5129 comes in a cabinet for surface mounting the FACP The 5129 can monitor voltage directly UL listed as a slave fire for connection to UL 24 VDC local FACPs Four fully supervised input channels as voltage input high or low or as a contact input Dual phone line interface and line monitors Automatic 24 hour test Reports in most major formats Compact size of 5128 allows in most local FACPs Easy to install and service Program the 5128 to report FACP AC immediately or delay from 6 to 12 hours Set up direct FACP AC monitoring the FACP main power input the 5129 Onboard nonsilencing audible alarm Program remotely view current and change the 24 hour test with a PC running DOS and Knight 5541 software 5530 also required Specifications AC 120 VAC 60 Hz 45 mA DC 18 40 VDC DC Load 84 mA 24 VDC max Current with Annunciator mA 24 VDC max Current without Annunciator mA 24 VDC max Current with Annunciator mA 24 VDC max Current without Annunciator mA 24 VDC max Inputs 18 30 VDC High Current 15 mA max Contact Current 4.7 VDC 6 mA Monitor Input 5129 only AC output from FACP or 120 VAC Response 50 sec max Specifications Physical Description W x 8.75 H x 1.25 D 10.2 W x 22.2 H x 3.2 D cm 2 lbs 0.907 kg Black Physical Description W x 10.4 H x 3 D W x 26.4 H x 7.62 D cm 6 lbs 2.7 kg Red Requirements Part 15 approved of Jack RJ31X two required Power Phone line trouble Faulted input and system SK 3 1 Sescoa 3 1 SK 4 2 FSK 4 2 Radionics BFSK ID SIA 71 NFPA 72 864 7300 0559 120 429 92 E Vol III ALARM ACCESSORY Slave Fire Communicator Information Slave Fire Communicator Channel Slave Fire Communicator mounting inside FACP cabinet Slave Fire Communicator Channel Slave Fire Communicator in For mounting near FACP Remote Annunciator programming troubleshooting and operations One per 5128 29 Downloading Software for remote programming of the Download at no cost from the Knight Web site 5530 modem Modem for use uploading and programming information 5128 29 and other Silent Knight alarm accessories Cable for the 5230 remote annunciator 130294 used to connect to the document is not intended to be used for installation purposes We try to our product information up to date and accurate We cannot cover all applications or anticipate all requirements All specifications are to change without notice For more information contact Silent Knight Clintonville Road Northford CT 06472 1610 Phone 800 328 0103 Fax 484 7118 www silentknight com IN AMERICA 350780 Rev C 2010 Honeywell International Inc
