COMMERCIAL FIRE ALARM CONTROL PANEL 5204 Fire Alarm Panel and Optional Communicator Knight 5204 is compact and easy install and service delivering features expect to find in systems costing more Silent Knight Model 5204 Fire Alarm Control Panel is a local fire evacuation control panel for applications requiring manual and automatic fire alarm as well as water flow and supervisory service basic 5204 unit offers local fire control for up to four zones central station communications the optional UL Listed Model Digital Communicator The has 3 Amp power supply 2 Amp supervised notification and supports both 2 and smoke detectors 5204 includes an annunciator the cabinet for annunciation operation LEDs are visible opening the cabinet keys include SILENCE RESET and DISPLAY annunciation is available the optional Model 5230 four wire annunciator can the same operation as the system annunciator and English language LCD and programming The 4 Class B can be converted to A using the Model 7181 Zone Fuseless design reduces service Field selectable 24 or 12 VDC supply 3 amp current output available for devices Compatible with 2 and 4 wire detectors as well as water and sounding devices Two 1.5 amp supervised notification programmable for steady or supervisory Auxiliary outputs of 1.5 amp at 12 or VDC and 175 mA at 12VDC Smoke verification pre alarm delay cross zoning minimize false Two general purpose relays 2.5A contact Form C Optional plug in UL Listed digital Model 5205 Up downloading reduces time Programmable from on board or optional remote Model 5230 Accu Zone diagnostics for on site Specifications AC 120 VRMS 60 hz 2.5A Accessory Load 3A 12 or 24 VDC 120 mA 400 mA Circuits Class B 1.5A 12 or 24 VDC for steady pulsing temporal supervisory for sprinkler system Outputs 12 or 24 VDC mA 12VDC Specifications x 19 5 8 H x 4 1 4 D x 49.8 x 10.6 cm Red Requirements of Jack RJ31X 2 required 864 72 Central Station Reporting Protective System Signaling System Signaling Part 68 and Part 15 7165 0559 117 York City MEA 429 92 E FIRE ALARM CONTROL PANEL 5204 Alarm Control Panel and Optional Digital Specifications contractor shall provide a completely electrically supervised fire alarm control system The system shall contain a fire control panel to supervise and operate heat and smoke detection devices alarm notification devices and visual An optional digital communicator shall transmit fire alarm trouble and supervisory signals to a central station controller shall be UL Listed for use under NFPA 72 standards It shall provide power and control for four supervised zones 2 supervised notification circuits and optionally an approved plug in digital communicator The controller be Silent Knight 5204 or equivalent shall be four Class B detection zones Products of combustion detection may be either 2 or 4 wire and shall be cross by UL for use on the system The detection zones shall be programmable to 1 be cross zones so that two adjacent must sense products of combustion 2 automatically reset a detector to verify that smoke exists and 3 see a detector in alarm an alarm is sounded and optionally transmit a signal to the central station shall be two 1.5 amp supervised alarm notification circuits They shall cause the bells horns to ring steady pulsing through the premises until reset or silenced control shall be equipped with two auxiliary relays that shall be programmable to operate on 1 alarm 2 trouble supervisory 4 supervisory trouble and 5 system trouble The relays shall maintain contact until cleared control shall have one on board touchpad and shall support 3 remote annunciators LEDs shall augment the display to the system status to an operator An integral touchpad shall be provided to operate set up and interrogate the system optional plug in digital communicator shall be UL Listed for use under NFPA 72 standards It shall have the capability to two telephone lines seize the phone line and send the alarm signal on one or both lines without additional It shall be able to communicate to a central station in SIA SK FSK 4 2 SK4 2 tone burst SK 3 1 SESCOA 3 1 BFSK The communicator shall sound a local trouble signal if the telephone service is interrupted for longer than seconds and it shall transmit a signal indicating restoral of phone service The optional digital communicator shall have ability to send a test signal to the central station every 24 hours The test signal shall be able to be transmitted at a time of day or night by setting a program within the communicator alarm signals transmitted to the central station shall indicate which zones are in alarm and which zones are in trouble from an alarm shall also be transmitted by zone Accessories Remote Annunciator all the same functions as on board annunciator and an LCD English language and backlighting Digital Communicator all the same functions as on board annunciator and LCD English language and backlighting Auxiliary Relay ground start phone lines Status Display Module 16 outputs to give alarm trouble conditions by zone be used to drive LED or annunciators Non Fire Zone Converter Class A zones to Class B vice versa Direct Connect Module for city box and polarity direct wire applications Downloading Software and Modem remote programming of 5204 other Silent Knight products an IBM PC or compatible Meridian Circle Maple Grove MN 55369 4927 or in Minnesota 612 493 6435 612 493 6475 Wide Web http www silentknight com IN AMERICA 350778 Rev B 02 04 2004 Silent Knight
