SIlent Knight 5217 10-Zone Expander for 5208

SK 5208 ACCESSORY Expander cost effective way to your SK 5208 system Model SK 5217 provides the SK 5208 with ten additional Class B style B zones The SK 5217 can be in the SK 5208 control cabinet or remotely up to 1500 ft in a SK 2190 accessory cabinet The SK communicates to the SK 5208 control panel via a 4 wire connection to the SBUS Zone Expander 10 Class B zone inputs to the FACP Two SK 5217 can be used with the for a total of 30 zones SK 5217 can be installed in SK 5208 cabinet or remotely a SK 2190 accessory Adds 10 zone inputs to the FACP Can be remotely mounted from up to 1500 ft Easy to install using a 4 wire connection Supervised UL Listed Voltage Draw Total Amp per Zone 3.0 mA per Zone mA VDC Initiation Resistance Wiring Distance FACP Temp ft to 120 F to 49 C to 85 Zone Expander in Cabinet in SK 2190 Cabinet ACCESSORY Expander Specification contractor shall furnish and install where indicated on the plans the module SK 5217 Zone expander shall be capable of supporting 10 zones of Class B including smoke detectors and dry contacts with a of 50 ohms of resistance per circuit Module shall have provisions for mounting in the main control or in the SK 2190 Accessory cabinet Module shall be programmed by a 4 position dip switch with a of 3 module per panel and connect to the main fire alarm panel via SBUS B Style B Input Wiring Wiring to FACP document is not intended to be used for installation purposes We to keep our product information up to date and accurate We cover all specific applications or anticipate all requirements All are subject to change without notice For more contact Silent Knight 12 Clintonville Road Northford CT Phone 800 328 0103 Fax 763 493 6475 IN AMERICA 350322 Rev D 2010 Honeywell International Inc
