Direct Connect Module Instructions 5220 is a direct connect module used to a fire alarm control panel FACP to a box or polarity reversal communicator The instruction are generic installation refer to the FACP installation for compatibility and usage and wiring of this device must be done in with NFPA 72 and local ordinances Voltage 19.4 to 28 VDC Box Current 1 A for 1 Second coil resistance 30 ohms Reversal 20 mA max loop resistance 3 k ohms Temperature 32 to 120 0 to 49 or within the range of 10 93 at 30 86 6 1 2 x 1 5 16 x 2 1 8 16.51 cm W x 3.33 cm H x 5.40 cm D Wire Rating 12 24 AWG 5220 comes equipped with its own cabinet The 5220 is intended for indoor use in a dry location Remove the cover from the 5220 Mount the 5220 with four screws in the holes in Figure 1 Screw Holes Holes Screw 1 Mounting the 5220 Wiring the 5220 as shown in Figure 2 Replace the 5220 cover and secure it with two self tapping screws supplied 151409 Direct Connect Module Installation Instructions Connect the 5220 as shown in Figure 2 2 5220 Wiring Connections Meridian Circle Grove MN 55369 4927 or 800 328 0103 763 493 6475 2006 Silent Knight PN 151409 Rev A
