Silent Knight 5820XL Data Sheet

INTELLIKNIGHT FIRE ALARM CONTROL PANEL Model 5820XL Fire Control System IntelliKnight System is the easy way make the most of fire alarm technology 5820XL is the first fire alarm system to provide you with revolutionary value and performance in sensing technology The 5820XL FACP offers exclusive built in digital communication distributed power a modular design and an expanded easy to use interface Powerful features such as drift and maintenance alert are delivered in this powerful FACP from Silent Knight more information about the 5820XL system or to locate your nearest source please call 800 328 0103 is an intelligent addressable fire alarm control panel The basic 5820XL system can be expanded by adding such as 5860 remote annunciator 5815XL signalling circuit expander 5824 serial parallel printer interface for printing system reports and 5895XL intelligent module 5820XL supports SD or SK devices 5820XL features a powerful built in dual line fire communicator that for reporting of all system activity to a remote monitoring Built in support for 99 SK detectors and 99 SK modules to 396 SK detectors and 396 SK modules using Sensor protocol Built in support for 127 SD devices expandable to 508 SD using the SD protocol Uses standard wire shielded or twisted pair required Built in digital communicator Central station reporting by point or by zone Built in synchronization for appliances from AMSECO Faraday System Sensor and Wheelock Flexput I O circuits Supports Class B Style 4 and Class A Style 6 configuration SLC SBUS and Flexput circuits 13 pre programmed output cadences including ANSI 3.41 4 programmable outputs Built in annunciator with 80 character LCD display RS 485 bus provides communication to system accessories Built in RS 232 and USB interface for programming via PC Built in Form C trouble relay rated at 2.5 amps at 27.4 VDC Improvements in SKSS software deliver five times faster 27.4 VDC Two built in Form C programmable relays rated at 2.5 amps Plex 1 door option combines a dead front cabinet door with a window limiting access to the panel while providing button operation of the reset and silence functions 5820XL 6 amp power supply and maximum capacity of 35 amp hours An cabinet enclosure is required for in excess of 18 amp hours Programmable date setting for Daylight Time 5820XL can be surface or flush 5820XL signal line circuit SLC multiple device types of the same SK System Sensor SD cannot mix SD and SK SLC devices on FACP FIRE ALARM CONTROL PANEL Model 5820XL Fire Alarm Control Panel Lights Alarm Red Flashes when in solid when alarm silenced Yellow Flashes when a condition exists solid when silenced Troubles Yellow Flashes a trouble condition exists solid trouble silenced Silenced Yellow On when an trouble or supervisory condition been silenced but not yet cleared Power Green Flashes for AC solid when power systems are Application has one built in signalling line SLC which supports multiple dependent on protocol being Three additional loops can be using the 5815XL SLC to increase overall capacity 5820XL SLC loops support device types including Addressable photoelectric smoke Addressable ionization smoke Addressable heat sensor Addressable duct smoke detector Contact module Relay output module Addressable notification module Addressable beam detector SK only Addressable multi criteria smoke SK protocol only Addressable multi modules SK only following advanced sensor are available with 5820XL Automatic drift compensation Maintenance alert Built in sensor test to comply with 72 calibration testing features a 6 amp power supply maximum battery charging of 35 amp hours An additional enclosure PN RBB is required batteries in excess of 18 amp hours circuits on 5820XL control can individually programmed to function notification circuits auxiliary power or initiation circuits that both 2 and 4 wire smoke 5820XL system operates on non unshielded cable when wired compliance with standard wiring as called out in the National Code 760 51 specifications for fire protective signalling No special wiring is required provides 13 preset notification patterns including ANSI 3.41 four user programmable selections fire alarm notification programmable general purpose C relay outputs are provided on the IntelliKnight system a built in walk test and auto Its innovative dead front design allows for flush or mounting System maintenance easy to perform Interface 5820XL built in annunciator with character LCD display and large tactile touchpad can be for system operation and maintenance It has LEDs for alarm supervisory trouble system silenced and power System operations silencing alarms and troubles alarms and the display of troubles and memory The non volatile event history stores 1000 events for viewing the built in or remote annunciator operation can be initiated with mechanical firefighter s key or a valid to 7 digit operator s code IntelliKnight system offers several to simplify and speed up The JumpStart feature programming to start a new system The keypad and 5860 remote give on site access to all You can also program using the 5660 Silent Knight Suite which is Windows software Digital Communicator features a built in UL listed communicator for remote of system activity and system The communicator has ability to seize two telephone lines report alarms and troubles to a facility The communicator two phone lines and will a trouble signal if a line failure sustained for more than 45 seconds communication features include if communication fails two phone capability download phone capability and Touch Tone or dialing The communicator is with SIA and Ademco ID The format is selectable by number 13 NFPA 15 NFPA 16 72 Central Station Remote Local Protective Signalling Auxiliary Protected Premises Water Deluge Releasing Suitable for automatic waterflow sprinkler DACT non coded services Approvals UL Listed 7165 0559 0135 429 92 E Vol VI FM Approved FIRE ALARM CONTROL PANEL Model 5820XL Fire Alarm Control Panel FIRE ALARM CONTROL PANEL Model 5820XL Fire Alarm Control Panel AC VRMS at 50 60 Hz 2.5A or VRMS at 50 60 Hz 1.4A Accessory Load 6A 27.4 VDC Current 215 mA Current 385 mA Circuits programmable circuits which can be individually as circuits 3A 27.4 VDC circuit power limited power circuits 3A 27.4VDC circuit power limited Circuits 100 mA 27.4VDC circuit power limited Mount Dimensions x 24.75 x 3.9 W x 62.9 H x 9.8 D cm Dimensions x 26.4 x 4.2 W x 67 H x 11.8 D cm 28 lbs 12.8 kg Red Charging Capacity 7.0 35 AH Size 18 AH max allowed in panel cabinet Larger capacity can be housed in RBB cabinet Requirements Part 15 and Part 68 approved of Jack RJ31X two required Accessories Remote Fire Annunciator the same 80 character backlit display keypad and firefighter s as the 5820XL 5860 is gray 5860R is red Signal Line Circuit Expander SLC expander is used to add more devices to the IntelliKnight 5820XL supports three Each 5815XL can support 99 detectors and 99
