Silent Knight 6700 Operation Card

Model 6700 Basic Operating Instructions Instructions must be framed and displayed next to the 6700 panel in accordance NFPA 72 fire code for Local Protected Fire Alarm Systems Test the system in to NFPA 72 Alarms and Alarms SILENCE then enter a code if prompted Silence LED will light to Perform RESET then enter a code if prompted up or down arrow to view Alarms Supervisories or Trouble Alarms Supervisories Troubles a Points Status a Fire Drill Detector Sensitivity is located Time and Date the screen as necessary Press ENTER to access Main Menu then enter a code if prompted Press 2 to select Point Functions Select the module the device is located on by using the up or down arrow Then press Enter the point number Press ENTER to access Main Menu then enter a code if prompted Press 1 to select System Tests then press 1 to select Fire Drill Press ENTER to start the fire drill Press ENTER to end the fire drill Press ENTER to access Main Menu Press 2 for Point Status From the list that displays select the SLC module where the point you want to The fourth line of the display shows the sensitivity status means the is in compliance with NFPA 72 MAINT means the detector is in with NFPA 72 but maintenance should be performed soon means the detector is not in compliance with NFPA 72 Press ENTER to access Main Menu then enter a code if prompted Press 4 to select Set Time Date Enter a code if prompted Make changes in the fields Press ENTER if you wish to keep the changes Press ENTER to set the entered time and Rotate the key or enter a code to access to access Main Menu Press 2 to select Point Functions Press 1 to select Disable Enable Point Press 7 to Disable Enable Pt Use the up or down arrow to move through the list Then press ENTER to select the where the point you want to disable enable is located Enter the point or circuit number that you want to disable enable Press the right arrow key to toggle between NORMAL enable or DISABLE Press ENTER to access Main Menu then enter a code if prompted Press 3 to select Event History Press the up or down arrow to view events in the history buffer Disable a Point Event History Service Call LS10166 001SK E Rev A ECN 16 0218
