Silent Knight 9800 Desktop Receiver

ALARM MONITORING EQUIPMENT Digital Alarm Receiver next generation of the industry popular digital central station delivers the efficiency and you need from a you trust from the market leader in digital communications technology the next generation digital signal receiver This compact new receiver provides you with state of the art for your alarm signal and data processing needs The 9800 Receiver compact efficient design allows from one to twelve line cards and phone lines to be installed in a receiver Choose the industry receiver of choice from the longest running of digital central station receivers Choose the Silent Knight 9800 digital alarm receiver 9800 Alarm Receiver Silent Knight Model 9800 Station Receiver is a multi format receiver to receive display and data received from up to 12 lines 9800 receiver is compatible a broad range of automation and receives all major formats including SIA Ademco Contact ID installed in a 19 rack the Receiver is UL listed and FM 9800 Receiver has phone line settings the power supply supports 120VAC at 60Hz and 230VAC 50Hz operations making it for domestic or foreign 9800 Receiver is composed of master central processing unit and one to twelve line ease of use the 9800 receiver a modular design that the MCPU from the line Digital Alarm Receiver Line cards support Caller ID and Name Delivery Line card parameters are stored the MCPU for faster removal replacement Line cards are individually for format priority ring parameters Multiple receivers can be in a master slave for use with a automation and or printer UL Listed FM Approved A subchassis within the 9800 contains the MCPU the supply and the LCD panel cards slide into the enclosure the right of the subchassis power connections at the of the enclosure Phone are routed through below each line card and at the front of the line to ensure circuit integrity and access Handles up to twelve calls with one receiver Modular configuration for easy replacement and repair Each line card will communicate all supported formats Easy to set up and program MONITORING EQUIPMENT Cards Single line card supports all formats Up to 12 line cards per chassis Caller ID for diagnostics Programmable options stored in MCPU flash Largest event call buffer in the industry Up to 9,900 Programmable options include events Count on time off time detect type enable trap enable cancel formats delay Weight lbs 9815 Line Card one is shipped with receiver 6712 12VDC 7ah battery Not for UL installations Okidata Microline 320 Turbo Parallel printer 9811 Spare Card Kit 9540W Computer Automation Software MONITORING EQUIPMENT protocols System Features Silent Knight 9000 SIA Computer Interface Standard CIS Silent Knight expanded ADEMCO 685 FBII CP 220 Supply Supports 120 230 VAC 50 60 hz Monitors AC and battery connections Supperts external UPS connection Programmable audible annunciation Programmable auxiliary relay Time date selectable for Military European AM PM Viewing and filtering of history information System events can be viewed separately Two available user profiles Supports 40 users Trap and listen in capabilities Printer port Two RS485 ports for Master Slave configuration Two serial automation ports Remote uploads of O S upgrades RJ 11 Phone Cable MONITORING EQUIPMENT 9800 Central Station Receiver Formats SIA Digital Communication Standard Ademco Contact ID Express Touchtone BFSK SK 3 1 SK 4 2 SK FSK FSK0 FSK80 SK FSK1 FSK81 SK FSK2 FSK86 Franklin 3 1 Radionics Hex Sescoa 3 1 Super Fast Radionics 3 1 Checksum 3 1 Extended 4 1 Extended Acron Touchtone Modem ll lle Westec Formats document is not intended to be used for installation purposes We try to our product information up to date and accurate We cannot cover all applications or anticipate all requirements All specifications are to change without notice For more information contact Silent Knight Meridian Circle Suite 100 Maple Grove Mn 55369 4927 800 328 0103 or 763 493 6400 Fax 763 493 6475 IN AMERICA 350013 Rev B Honeywell International Inc
