REMOTE COMMAND UNIT Model EVS RCU Remote Command Unit EVS RCU is a combination supervised remote microphone and annunciator which is compatible with the Emergency Voice System The EVS RCU meets UL requirements for a LOC Local Operator more information about the EVS RCU or to locate your nearest source please call 800 328 0103 included Remote Voice Module provides an interface to the Voice System and a supervised microphone for live The annunciator is capable of performing operation of the fire alarm system including silencing resetting On board supervised microphone Programmable trigger inputs from an external source such as Monaco system to either the RVM or 5880 Up to eight available on the 5880 module After the main panel unit up to four EVS RCU can be to provide a total of five command units The meets the requirements for a LOC Up to 32 mappable speaker circuits using a combination of or EVS 125W and EVS CE4 mappable to 32 controlling selected output groups All Call and Non Active Call buttons to quickly select all active all the non active output groups Six wire connection to EVS system Two wires for the voice and four wires for the SBUS connections UL 864 and UL 2572 the requirements for NFPA 72 Local Protective Signaling Emergency Communication Systems Listings EVS RCU EVS RCU can be surface or flush EVS 50W is compatible with the panel 5820XL EVS Voice Integration Panel with Alarm Control 350604 Rev C 2015 Honeywell International Inc COMMAND UNIT Command Unit Information Switch Expander Trim Ring For flush mounting Mount Dimensions x 26.75 x 2.5 3 W x 68 H x 6.4 D cm Dimensions x 26.5 x 4.6 W x 67.3 H x 11.8 D cm Red Temperature 32 120 0 49 10 93 non condensing Current 100 mA 5860 RVM SW 24 Current 150 mA 5860 RVM SW 24 Integration Wiring conductor voice bus SBUS document is not intended to be used for installation purposes We try to keep our information up to date and accurate We cannot cover all specific applications or all requirements All specifications are subject to change without notice For information contact Silent Knight 12 Clintonville Road Northford CT 06472 Phone 484 7161 Fax 203 484 7118 For Technical Support please call www silentknight com in
