Silent Knight IDPmonitor10 spec

Addressable Monitor Module IDP Monitor 10 is a 10 point addressable module for use with Silent Knight IFP fire alarm control panels FACPs IDP Monitor 10 acts as an interface to devices such as waterfowl switches and stations The multiple input design allows for and efficient installation IDP Monitor 10 supports ten Class B contact inputs or five Class A contact inputs Conventional 4 wire detectors can be monitored for alarm and conditions contact monitor Support for Class A and Class B wiring supervised indicator for each input Disable unused addresses Mount up to two modules in one accessory PN IDP ACB Rotary address switches for fast installation Removable 12 to 18 AWG plug in terminal for easy wiring and troubleshooting Mounting hardware included UL Listed can install up to two IDP Monitor 10 modules an accessory cabinet PN IDP ACB The cabinet has a built in mounting plate positions the module boards so that all of the indicators are visible IDP Monitor 10 is compatible with the FACPs Intelligent Fire Panel Intelligent Fire Panel Intelligent Fire Panel Intelligent Fire Panel Information 10 input Monitoring Module IDP Module Cabinet Meridian Circle Suite 100 Grove MN 55369 or 800 328 0103 350296 Rev C Honeywell International Inc Temp 32 120 0 49 10 93 non condensing 6.8 17.3 cm 5.8 14.7 cm 1.25 3 cm Weight 6.3 oz 196 g Gauge 12 18 Voltage 15 32 VDC Current All ten LEDs solid on 55mA Current 3.5 mA max Device Circuit Wiring Resistance 1500 Device Circuit Voltage 10.2 VDC max Device Circuit Current 240 max Wiring Resistance 40.5 max document is not intended to be used for installation purposes We try to keep product information up to date and accurate We cannot cover all specific or anticipate all requirements All specifications are subject to change notice For more information contact Silent Knight 7550 Meridian Circle 100 Maple Grove MN 55369 Phone 763 493 6400 or 800 328 0103 763 493 6475 www farenhyt com in USA
