Silent Knight ifp100spec

IFP 100 is an intelligent analog addressable fire control panel The basic system has a single SLC loop and four notification appliance that can be programmed for notification outputs or auxiliary power also has a built in dual line digital fire communicator Form C relay and two programmable Form C relays The firmware has features such as detector sensitivity day night thresholds drift and pre trouble maintenance alert supports a variety of other devices that can be added to the such as RA 100 remote annunciator 5824 serial parallel printer module for printing system reports and 5496 intelligent power and Hochiki or Intelligent Device Protocol IDP devices Built in support for up to127 Hochiki devices or 99 IDP detectors and 99 modules Uses standard wire shielded or twisted pair required Built in digital communicator for remote reporting of system activity and programming using either SIA or CID formats Central station reporting by point or by zone Jumpstart auto programming Supports Class B Style 4 and Class A Style 6 or Style 7 configuration SLC Distributed intelligent power Built in synchronization for AMSECO Gentex Faraday System and Wheelock appliances Sensor sensitivity settings and day night sensitivity setting Automatic drift compensation Notification circuits configurable as 2 Class A Style Z 4 Class B Style or auxiliary power for resettable constant or door holder power Built in annunciator with a backlit 80 character LCD display RS 485 bus provides communication to system accessories Built in Form C trouble relay rated at 2.5 amps at 27.4 VDC Two built in Form C programmable relays rated at 2.5 amps at 27.4 VDC SLC device locator can be used to locate a single or multiple devices on SLC loop System automatically performs detector sensitivity test 13 preset notification cadence patterns including ANSI 3.41 and four programmable patterns Built in RS 232 and USB interface for programming Upload or download programming event history or detector status onsite from a remote location using a PC and 5650 5651 Silent Knight Suite SKSS Improvements in SKSS deliver five times faster upload downloads Non volatile event history stores up to 1000 events 125 Software zones and 125 output groups 6 amp power supply and maximum charging capacity of 35 amp hours additional cabinet enclosure is required for batteries in excess of 18 hours Clintonville Road CT 06472 1610 or 800 328 0103 203 484 7118 Loop Analog Addressable Alarm Control System Vol XIV Integrated dead front panel protects operator from to electrical components The FACP enclosure features a Plexiglass window to protect annunciator Programmable to automatically display oldest first or display tally of system events Acknowledge function allows operator to keep of event status Programmable date setting for Daylight Saving IFP 100 can be surface or flush mounted IFP 100 SLC supports multiple device types of same protocol Hochiki IDP cannot mix Hochiki and IDP devices on a FACP any combination of addressable devices of same protocol can be used on the IFP 100 Hochiki Devices specification sheet PN and IDP Device Protocol Devices sheet PN 350361 for more information 350388 Rev F 09 520 2009 Honeywell International Inc is a Registered Trademark of Silent Knight Mount Dimensions 14.5 x 24.75 x 3.5 W x 62.9 H x 8.73 D cm x 26.4 x 4.65 W x 67 H x 11.8 D cm Dimensions 28 lbs 12.8 kg Red Temperature 32 120 0 49 10 93 non condensing AC 120 VRMS 50 60 Hz 2.5A Accessory Load 6A 27.4 VDC power limited Current 170 mA Current 325 mA Charging Capacity 7 to 35 AH Size 18 AH max allowed in control panel cabinet capacity batteries can be housed in RBB accessory Appliance Circuits circuits that can be programmed individually as Circuits 3A per circuit 27.4 VDC power limited Power Circuits 3A per circuit 27.4 VDC Lights Red Flashes when in alarm solid when alarm silenced Yellow Flashes when a supervisory condition solid when supervisory silenced Yellow Flashes when a trouble condition exists solid trouble silenced Yellow Solid when an alarm trouble or supervisory has been silenced but not yet cleared Green Flashes for AC failure solid when power are normal FCC Part 15 Part 68 approved RJ31X two required 13 NFPA 15 NFPA 16 NFPA 70 72 Central Station Remote Signalling Local Protective Systems Auxiliary Protected Premises Unit Water Releasing Service Suitable for automatic manual sprinkler supervisory DACT non coded signalling Approvals UL Listed CSFM 7170 0559 142 429 92 E Vol XIV Releasing Solenoids Number VDC 3 A VDC 3 A Information Fire Alarm Control Panel Accessories 5865 4 Annunciator Same operation and appearance to FACP annunciator Annunciator Four line LCD with 20 characters per line Annunciator Four line LCD with 20 characters per line Power Module Power Module Printer Interface Module I O Module Fire Annunciators Interface Board and IDP Devices the specification sheets listed below for a complete listing the Hochiki and IDP devices Devices Specification Sheet Device Protocol Devices Sheet Accessories Knight Software Suite Provides upload download and event Knight Software Suite Provides monitoring Battery Box Accessory Cabinet if backup batteries are too large to fit FACP cabinet Dimensions W x 10 H x 6 D mm W x 254 mm H x 152 mm D document is not intended to be used for installation purposes We try to keep our information up to date and accurate We cannot cover all specific applications or all requirements All specifications are subject to change without notice For information contact Silent Knight 12 Clintonville Road Northford CT 06472 1610 800 328 0103 Fax 203 484 7118 www farenhyt com in the U S A
