Silent Knight IFPN Routerspec

IFPN ROUTMB IFPN 4WRMB IFPN ROUTMB and IFPN 4WRMB are routers designed to work with IFP NET and IFP NETUL IFP NET UL graphical monitoring systems IFPN ROUTMB is an intelligent router and the IFPN 4WRMB is a layer repeater These routers are integrated devices that connect or four communications channels and route system messages between communications channels a router is required if A segment is greater than 6000 feet A fiber run is required or A free topology star configuration would be more efficient IFPN ROUTMB is a field programmable protocol regenerating router It allows transparent passage of system messages two system segments of the same or different topologies The uses two transceiver boards to connect two system of the same or different types The IFPN ROUTMB counts as 1 16 nodes that the IFP NET system can support It may be powered by 24 VDC power limited filtered source with battery backup that is UL with fire protective signaling units IFPN 4WRMB is a free topology star physical layer repeater It transparent passage of system messages between four FT 10 segments The IFPN 4WRMB uses FTXC or FOXC transceivers to four system segments of wire or dual strand fiber The IFPN does NOT count as a system node It may be powered by any 24 power limited filtered source with battery backup that is UL Listed fire protective signaling units IFP NET UL system components are based on LonWorks Transparent multi channel support Integrated package Messages forwarded between two or four channels of the same or media type Supports wire or fiber optic topology Physical isolation between channels Polarity insensitive network connection wire only Packet LED indicates packet transfers between sides of the router Transformer coupled system connection for wire Fits in standard wall mount IFPN CAB1 enclosure systems systems Meridian Circle Grove Mn 55369 4927 763 493 6475 basic IFP NET UL wire system segment allows trunk length of 6,000 feet 1,828.8 m Routers used wherever necessary to exceed the system segment length the wire topology changes to fiber or a topology star configuration is required IFPN ROUTMB allows an additional 6,000 1,828.8 m segment Each wire segment T tapping with a maximum distance of feet 457.2 m between any two nodes or maximum length of 8,000 feet 2,438.4 m only one node is attached to the router on segment Fiber optic versions can run 8 dB attenuation point to point The IFPN ROUTMB as 1 of the maximum 16 nodes available the IFP NET UL system IFPN 4WRMB allows up to three wire or dual trunks to be home run back to a central to create a star configuration The amplifies the signal from the input but does not regenerate the signal as IFPN ROUTMB does Maximum segment distance may vary depending on conditions The IFPN 4WRMB not support the DFXC transceiver 350270 Rev B 05 06 06 2006 Silent Knight IFPN ROUTMB and IFPN 4WRMB use the standard cabinet order separately Temperature 32 to 120 0 to 49 93 non condensing at 86 30 connections for the IFPN ROUTMB and IFPN 4WRMB made via plug in screw terminals for wire operation Fiber system connections use ST connectors with fiber optic cable can come from any regulated power supply UL listed for with fire protective signaling units Platform LonWorks based system operating at 78.5 over wire or multimode fiber Bidirectional fiber IFPN 1250 Kbaud Support Wire T tapped or home run multimode fiber and multimode single fiber IFPN ROUTMB only Requirements Multimode 62.5 125 dia Mounts in standard IFPN CAB1 cabinet Cabinet Dimensions W x 16 H x 3 D cm W x 40.64 cm H x 7.62 cm D System traffic and power Requirements 24 VDC 75 mA 24 VDC 50 mA Information and cabinet required Order separately router that supports IFPN FTXC and DFXC transceivers layer repeater that supports and FOCX transceivers If routers of this model are installed IFPN ROUTMB must be installed each IFPN 4WRMB cabinet Dimensions W x 16 H x 3 D cm W x 40.64 cm H x 7.62 cm D transceiver supports the basic communication It can be or home run basic fiber optic transceiver uses two one for transmit and one for Fiber provides the best distance and noise immunity enhanced fiber optic transceiver and receives on a single fiber provides the best distance and noise immunity document is not intended to be used for installation purposes We try to keep our information up to date and accurate We cannot cover all specific applications anticipate all requirements All specifications are subject to change without notice more information contact Silent Knight 7550 Meridian Circle Suite 100 Maple Mn 55369 4927 Phone 800 328 0103 Fax 763 493 6475 in the U S A
