Silent Knight IFPnetUL Spec

IFP NETUL IFP NETUL is the next generation in advanced technology to monitor control fire facility information over a proprietary LonWorks network LonWorks network supports a variety of topologies and media and is industry standard open architecture system IFP NETUL PC workstation is the operator interface to the system It features plug in applications allowing continued of workstation and network functions These applications can new features to the software implement features specific to certain or even add situation and facility specific features IFP NETUL workstation software is an easy to use and learn graphical interface for an IFP series FACP installation The operator is with a consistent look and operation for all monitored equipment workstation features customizable screens and allows a wide variety of options for any situation IFP NETUL supports up to 16 nodes of compatible Farenhyt fire alarm panels and event printers as well as dry contacts IFP NETUL workstation is configured as follows Rackmountable cabinet 2.0 GHz Pentium IV processor with 256 MB of RAM 40 GB hard drive Sound card and speakers Microsoft Windows 2000 Professional 17 flat screen LCD monitor Standard mouse and keyboard Compatible with on a variety of fire system topologies Support IFP Series devices with IFPN NION installation packages and control panels with dry contacts with IFPN 2C8M installation Accommodate extended installation ranges with IFPN routers and Feature rich IFP NETUL software Autonavigation automatically locates and zooms to the device related an alarm or event based on the priority of the event System Administrator definable security profiles allow for extremely definitions for operator accounts Standard mouse control which uses and click operations Dynamically generated sizable key map New and Acknowledged Event boxes display all off normal events with graphic screens Operator log with response tracking History Manager records operator event and response with time and stamp to disk Powerful search filters for custom reporting of all events Screen database with screens for all sites Administrator definable macros for device communication Definable function keys functional buttons and navigational buttons Meridian Circle Grove Mn 55369 4927 763 493 6475 Monitoring Workstation Workstation Floor plans can be zoomed in and out to level Devices can be placed at any level vector wmf drawing files or bitmaps Full linked multimedia text audio video bitmaps to any device all definable by administrator Device pull downs and proximity displays device specific information and functions Labeling of hazardous material HAZMAT and handicap special needs using labels with full linked multimedia Event printing connected to workstation or requires optional IFPN PRN6 Printer Graphics printing for floor plans reports device listings requires approved printer Backup capability of screen member and databases IFP 1000 Intelligent Fire Panel IFP 100 Intelligent Fire Panel IFP 50 Intelligent Fire Panel IFP 1000VIP Voice Integration Panel IFP 100VIP Voice Integration Panel 350374 Rev A 08 06 2006 Silent Knight Information Monitoring Center Workstation Control Panel Installation Packages packages include a NION motherboard transceiver and 5824 Serial Parallel Printer Interface topology NION multi mode fiber NION on two fiber optic cables fiber NION communicates on fiber optic cable Device and Control Panel Packages packages include a 2C8M motherboard and cabinet topology IFPN 2C8M multi mode fiber on two fiber optic cables fiber IFPN 2C8M on single fiber optic cable and cabinet required Order separately repeater motherboard used with and FOXC motherboard used with FOXC and DFXC transceiver supports the basic communication It can be or home run basic fiber optic transceiver uses two one for transmit and one for Fiber provides the best distance and noise immunity enhanced fiber optic transceiver and receives on a single fiber provides the best distance and noise immunity cabinet column serial event desktop printer Parts replacement motherboard Requires Order separately replacement motherboard Requires Order separately for all NION transceivers except IFPN DFXC for the IFPN DFXC transceiver Chipset for all 2C8M transceivers except IFPN 2C8MDF Chipset for the IFPN 2C8MDF transceiver replacement battery computer interface board Optic Specification Multi mode 62.5 125 dia document is not intended to be used for installation purposes We try to keep our information up to date and accurate We cannot cover all specific applications anticipate all requirements All specifications are subject to change without notice more information contact Silent Knight 7550 Meridian Circle Suite 100 Maple Mn 55369 4927 Phone 800 328 0103 Fax 763 493 6475 in the U S A
