Silent Knight SD500-ARM Addressable Relay Module Data Sheet

SD500 ARM Relay Module SD500 ARM is an addressable device that adds two Form C contacts the Farenhyt addressable system The contacts are rated at 2.0 amps VDC or 6 amp 120 VAC SD500 ARM allows you to control a wide variety of normally open and closed applications including elevator recall door closing fan and auxiliary notification And because the relay module is these applications can be located at any point in the signaling circuit SD500 ARM is compatible with the following Honeywell Silent Knight Addressable fire alarm control panel with up to 1,110 addressable points Addressable fire alarm control panel with an emergency mass system up to 1,110 addressable points Addressable fire alarm control panel with up to 198 addressable points Addressable fire alarm control panel with up to 100 addressable points Addressable fire alarm control panel Addressable fire alarm control panel with an emergency systems Addressable fire alarm control panel Addressable fire alarm control panel Two sets of Form C Double Throw Contacts are rated at 30 VDC or 6A VAC Up to 127 relays can used on each SLC Relay programming is flexible be mapped to conditions Polling LED visible cover plate UL listed complies NFPA 72 BENEFITSfirealarmresources com a complete listing of all approvals and please visit Windows and Windows Logo are trademarks trademarks of Corporation Knight and are registered of Honeywell Inc document is not to be used for purposes We to keep our product up to and accurate We cover all specific or anticipate requirements All are subject change without notice Technical Support 800 446 6444 Technical Specifications MOUNTING FOR SD500 ARM INFORMATION Addressable relay module LISTINGS AND APPROVALS Listed 429 92 E Vol 9 approved 4 square Temperature 32 to 120 0 to 0 to 93 relative humidity non Current 55 mA Current 55 mA Rating Form C 30VDC or 6A 120VAC more information more about Honeywell Silent Knight and other by visiting Silent Knight Clintonville Road CT 06472 G 11 17 2017 Honeywell International Inc
