Silent Knight SD505-6IB 6 Isolator Base Data Sheet

INTELLIKNIGHT ACCESSORY SD505 6IB Isolator Base short circuit wiring an SLC loop without down the entire loop SD505 6IB isolates a short circuit wiring fault on a Class A Style 7 and Class B Style 4 SLC Normally if the FACP detects a short on the SLC loop the entire loop can be disabled When SD505 6IB is attached to the loop a short open or ground fault occurring on the SLC loop will detected as a trouble but all SLC devices will continue to operate The isolator module fits the SD505 6AB detector base Voltage 32 VDC Current Draw AC Loss Current Loop Resist mA mA mA Temp to 120 to 49 to 85 RH SD505 6IB SD505 6IB Line Isolator is compatible with Silent Addressable Fire control SD505 6IB can be used on A Style 7 and Class B 4 wiring configurations SD505 6IB mounts on a dual gang or 4 square Octagon electrical box to 508 SD505 6IBs can be used 5820XL and 127 per 5808 systems a short so that the SLC remains operational Fully supervised Can be used with either Class B 4 or Class A Style 7 Attaches underneath 6 inch base SD505 6AB for installation UL Listed CSFM Listed MEA 284 91 E Vol llI SD505 6IB ACCESSORY SD505 6IB Isolator Module Base Specifications Base Silent Knight module SD505 6IB shall be installed on fire alarm systems connected to the SLC Module shall be capable of detecting and isolating a shorted on an SLC loop but still allow devices to Module shall be compatible with Silent Knight detector models SD505 APS SD505 AHS and SD505 SD505 6IB with Detector and 6 Base ordered separately A Style 7 B Style 4 document is not intended to be used for installation purposes We try to our product information up to date and accurate We cannot cover all applications or anticipate all requirements All specifications are to change without notice For more information contact Silent Knight Clintonville Road Northford CT 06472 1610 800 328 0103 Fax 203 484 7118 www silentknight com IN AMERICA 350316 Rev D 2010 Honeywell International Inc
