Silent Knight SD505-DUCT Duct Housing & Smoke Data Sheet

INTELLIKNIGHT ACCESSORY SD505 DUCT Smoke Detector smoke in air handling systems and handling equipment with Silent Knight duct smoke detector SD505 DUCT addressable duct smoke detector including the SD505 APS Analog Photoelectric Smoke is used for detecting smoke and products of combustion present in air moving through an HVAC air system When smoke is detected in a duct the unit communicates the condition to the IntelliKnight panel The panel in turn depending on programming and wiring turns off fans blowers and other Now there even more power and flexibility available to the IntelliKnight family of products Smoke Detector Model SD505 DUCT Duct Detector is a heavy duty housing with the SD505 Analog Photoelectric Smoke pre installed It provides detection of smoke and of combustion present in moving through HVAC ducts in and Industrial SD505 DUCT is in a heavy gray steel back box with a cover It installs quickly and sampling is accomplished by tubes which protrude into the An exhaust tube of one length 7.5 is provided the detector housing Intake tubes ordered are supplied in three lengths Duct mounting is through a template 4 sheet metal screws Two wire connection to SLC LED alarm indication and on sensor head Detects and limits the spread of Rugged steel backbox with clear cover template included Large terminal connection 3 standard tube lengths UL 268A listed complies with 72 and 101 Parts housing with 7.5 exhaust SD505 APS analog Photo sensor Installation 4 mounting screws models not included with SD505 Sampling tube for 6 to duct width Sampling tube for 2.5 5.0 duct width Sampling tube for to 10.0 duct width mA alarm and standby Velocity Temperature to 120 0 to 49 to 85 RH H x 7.25 W x 2.25 D backbox with clear cover to 4000 fpm ACCESSORY SD505 DUCT Smoke Detector Specifications air duct smoke detector shall be Silent Knight Model SD505 DUCT The housing shall contain a Analog Smoke Sensor Silent Knight model SD505 APS The detector head must perform an automatic check every 3 hours duct detector housing shall be of metal construction Complete mechanical installation must be able to be without removal of the detector cover Terminal connections shall be screw type using a minimum of screw Dimensions document is not intended to be used for installation purposes We to keep our product information up to date and accurate We cannot all specific applications or anticipate all requirements All are subject to change without notice For more information Silent Knight 12 Clintonville Road Northford CT 06472 1610 800 328 0103 Fax 203 484 7118 www silentknight com IN AMERICA 350705 Rev B 2011 Honeywell International Inc
