INTELLIKNIGHT ACCESSORY Heat Detector addressable heat detectors combine heat detection with pin point location ID essential combination for any installation heat detectors are an essential component in virtually any IntelliKnight installation The IntelliKnight recognizes each detector by its specific address so precious seconds are not wasted in determining of an alarm other IntelliKnight detector models the SD505 HEAT offers a low profile for pleasing aesthetics IntelliKnight family of detectors has been designed to use a common base Model SD505 6AB allowing application and placement flexibility Combine all this with the features you come to expect from Knight detectors installation stable operation RF transient protection and vandal resistant it adds up to a flexible solution for all your fire protection needs SD505 HEAT Heat SD505 HEAT is a heat suited to virtually any setting The SD505 is an absolute temperature This means that it responds alarm if the temperature goes the trip point programmed the panel SD505 HEAT provides temperature measure data to the fire alarm control This heat detector is suited to environments smoke detectors cannot be because of the presence of or cooking fumes such as in kitchen SD505 HEAT unit is made up an externally mounted thermistor a specially designed cover that the thermistor while maximum air flow The reads the temperature the air it takes in It then a signal representing the to the IntelliKnight the temperature exceeds the trip programmed at the panel alarm occurs The status LED continuously during the alarm normal conditions the status blinks approximately every 15 indicating that the head is with the loop Low profile 2 inches including Absolute temperature device Simple and reliable addressing Uses digital communication The SD505 HEAT is UL Listed meets the requirements in NFPA 72 Inspection and Maintenance 7 CFSM listed MEA listed FM approved Voltage 17 to 41 VDC Consumption mA mA Temperature Range to 150 57 TO 65 Temperature to 120 0 to 49 4 SQR 4 OCT gang mud ring Spacing 70 between on smooth ceilings Bases SD505 6AB Separately SD505 6SB 350963 Rev A 2010 Honeywell International Inc ACCESSORY SD505 HEAT Heat Detector Specifications contractor shall furnish and install where indicated on the plans addressable heat detector Silent Knight The combination detector head and twist lock base shall be UL listed compatible with Silent IntelliKnight fire alarm control panels base shall permit direct interchange with Silent SD505 PHOTO Photoelectric Smoke Detector Base shall the appropriate twist lock base SD505 6AB heat detector shall have a flashing status LED for visual supervision When the detector is actuated the LED will latch on steady at full brilliance The detector may be reset by actuating the control panel reset vandal resistant security locking feature shall be used in those areas as indicated on the drawing The feature shall be field removable when not required and RF transient suppression techniques shall be employed to minimize false alarm potential SD505 6AB Detector Base View SD505 HEAT Detector Head View document is not intended to be used for installation purposes We try to keep our information up to date and accurate We cannot cover all specific applications or all requirements All specifications are subject to change without notice more information contact Silent Knight 12 Clintonville Road Northford CT 06472 1610 800 328 0103 Fax 203 484 7118 For Technical Support call 800 446 6444 www silentknight com
