Silent Knight SK-Control-6 Six Circuit Notification Module Manual

INSTALLATION AND MAINTENANCE INSTRUCTIONS Circuit Supervised Control Module Clintonville Road Northford CT 06472 Fax 203.484.7118 VDC mA mA assumes all six relays have been switched and all six LEDs solid on to 120 0 to 49 to 55 to 85 Non condensing H x 5.8 W x 1.25 D Cabinet and chassis AWG Operating Voltage Current Current Range Gauge NAC Circuit Loss Rating Per Circuit NAC Current Ratings VDC W 70.7 VAC 50 W 25 VAC class B wiring systems 3A class A wiring systems 2A INSTALLING the modules will be installed in an existing operational system inform the and local authority that the system will be temporarily out of service the power to the control panel before installing the modules This contains static sensitive components Always ground yourself with a wrist strap before handling any circuits so that static charges are re from the body The housing cabinet should be metallic and suitably This manual should be left with the owner user of this equipment DESCRIPTION SK Control 6 Six Circuit Supervised Control Module is intended for use an intelligent alarm system Each module is intended for switching ap involving AC or DC which require wiring supervision A common input is used for all modules Each module has its own address A pair rotary code switches is used to set the address of the first module from 01 154 The remaining modules are automatically assigned to the next five addresses Provisions are included for disabling a maximum of three modules to release the addresses to be used elsewhere Each module has panel controlled green LED indicators The panel can cause the LEDs blink latch on or latch off In order to synchronize strobes horn strobes speaker strobes a SYNC 1 accessory card sold separately must be used the SK Control 6 See the SYNC 1 installation manual for details on how install module has terminals for connection to an external supply circuit for devices on its NAC Each supply must be power limited and its volt limits must be at or below those specified There is a short circuit monitor for each module This is provided to protect the external supply against short circuit conditions on the NAC ON BOARD Small shunt in A B select position Shipped in Class B position remove for Class A Large shunts on Enable Power Supply Monitors Large shunts on Disable Short Circuit Protection Large shunts on Sync Generator 1 x 4 Terminal Blocks 2 11 4 32mm 15 Large Shunts offs Machine Screws 5 Short Power Suppy Jumpers Small Shunts Nuts Long Power Supply Jumper 47k Ohm End Line Resistors EOL Relay Connector 1 ShORT CIRCUIT PROTECTION UL 864 9Th EDITION REqUIREMENTS TO USERS INSTALLERS AUTHORITIES HAVING JURISDICTION AND OTHER INVOLVED PARTIES product incorporates field programmable software In order for the product to comply with requirements in the Standard for Control and Accessories for Fire Alarm Systems UL 864 certain programming features or options must be limited to specific values or not used all as indicated below Feature or Option Settings Permitted in UL 864 in 864 Y N short circuit protection a single power supply is by multiple NACs or Disable short protection short circuit protection when a single power sup is shared by multiple NACs Short circuit protection be disabled only when a power supply is not shared by NACs REqUIREMENTS ensure proper operation this module shall be connected to a compatible Knight system control panel following is a description of the SK Control 6 mounting framework or two SK Control 6 modules can be installed in a IDP ACB cabinet IDP ACB cabinet has a built in chassis that will accommodate one or two modules Module Installation There are two methods for installing a module in the rear position of a Method one is for installation of a rear module only when no will be installed in front of it Refer to Figure 3 for instructions two is for installation of a rear module when another module be installed in the chassis position in front of it Refer to Figures 4a 4b for method two All necessary screws and standoffs are supplied the modules 3 INSTALLATION OF REAR MODULE ONLY METhOD ONE 1 IDP ACB CABINET front SK Control 6 module positions of each chassis are offset below the SK Control 6 module positions so that all of the status indicators are vis For cabinet dimensions refer to the IDP ACB instruction manual STEPS Cabinet Mounting In a clean dry area mount the backbox using the four holes provided in the surface of the cabinet Figure 3 2 TYPICAL MOUNTING hOLE LOCATIONS 1 2 Insert the bottom of the SK Control 6 module down into a rear slot the chassis Carefully swing the upper edge of the board back towards the back the chassis until it touches the two standoffs 3 two 4 40 screws with the two standoffs and tighten 4 Address and wire the modules according to the instructions in this steps in Figures 4a and 4b describe and illustrate module installation the rear chassis position and the position in front of it will be filled position installation is possible only if the rear position is filled with a 4A INSTALLATION OF SK CONTROL 6 MODULE IN A REAR POSITION METhOD TwO 1 2 Insert the bottom edge of the SK Control 6 module down into a rear of the chassis Carefully swing the upper edge of the board towards the back of the until it touches the short standoff attached to the chassis 3 the long standoff with the short standoff and tighten 4B INSTALLATION OF SK CONTROL 6 MODULE IN FRONT POSITION short circuit protection for an address remove the corresponding on the Short Protection area When enabled this option isolate a short occurring on any active circuit allowing the remaining to continue normal operation Short circuit protection may only be enabled if power supply monitor is enabled Place unused shunts on single pin to store on board for future use Power must not be applied to the unit when changing functionality of shunts Whether in Class B or Class A wiring power supply monitoring and circuit protection must be enabled on the NAC circuits that are sharing power supply Short circuit protection can only be disabled if a power supply is not shared by multiple NACs 5 VIEW GENERATOR POWER SUPPLY MONITOR SHORT CIRCUIT PROTECTION SHUNT 1 2 Insert the bottom edge of the SK Control 6 module down into a slot of the chassis Carefully swing the upper edge of the board towards the back of chassis until it touches the 11 4 31.75mm standoffs installed the rear module 3 two 4 40 screws with the two standoffs and tighten 4 Address and wire the modules according to the instructions in this All wiring must conform to applicable local codes ordinances and Install module wiring in accordance with the job drawings and appropri wiring diagrams All wiring to the SK Control 6 is done via terminal blocks In order to make electrical connections strip approximately 1 4 of insula from the end of wire sliding the bare end of the wire under the plate screw Set the address on the modules per the job drawing Use the rotary code to set the address of the first module between 01 and 154
