SK MONITOR Monitor Module SK MONITOR is an addressable monitor module for use with Silent Knight Series fire alarm control panels FACPs The is intended for use in intelligent two wire systems where address of each module is selected using the built in rotary SK MONITOR supports Class A supervised or Class B supervised to the load device Conventional 4 wire smoke detectors can be for alarm and trouble conditions SK MONITOR mounts directly into a 4 square electrical box The box have a minimum depth of 2 1 8 A surface mount electrical box Sensor PN SMB500 is available from Silent Knight Single contact monitor Support for Class A Class B wiring Fully supervised Panel controlled LED that green in state and is red in alarm UL Listed Rotary address for fast SEMS screws for easy BENEFITSfirealarmresources com Technical Specifications 4.5 x 4 W x 1.25 11.4 X 10.2 X 3cm Weight 6.3 oz 196 g INFORMATION Monitor Module Voltage 15 32VDC Draw LED on 5.0mA max Current LED flashing 375 Current 400 max 24 VDC one every 5 sec with 47K EOL 550 24 VDC one communication every 5 sec EOL 1K mA with LED latched on Current 5.5 mA with LED latched on Resistance 47K W Device Circuit Wiring Resistance 1,500 max Loop Resistance 40 W max Temperature 32 120 0 10 93 non condensing 4 Square surface mount electrical box SK MONITOR is compatible with the Honeywell Silent Knight fire alarm panels Addressable fire alarm control panel Addressable fire alarm control panel an emergency mass notification system Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel Addressable fire alarm control panel an emergency mass notification system a complete listing of all approvals and please visit Windows and Windows Logo are trademarks trademarks of Corporation Knight System and Honeywell registered of Honeywell Inc document is not to be used for purposes We to keep our product up to and accurate We cover all specific or anticipate requirements All are subject change without notice Technical Support 800 446 6444 more information more about Honeywell Silent Knight and other by visiting Silent Knight Clintonville Road CT 06472 350131 Rev G 11 17 2017 Honeywell International Inc
