Silent Knight SWIFT® Wireless Detector Data Sheet

Intelligent Wireless Devices WSK PHOTO T WSK HEAT Wireless Detectors wireless detectors are intelligent addressable detectors which provide reliable communication to the Fire Alarm Control Panel FACP across a Class mesh network Wireless detectors create an opportunity for applications where it is concrete walls ceilings buried wires obtrusive surface mount conduit or dangerous asbestos to use traditional wired devices In addition both wired wireless devices can be present on the same FACP providing an integrated wired solution for increased installation potential SWIFT detection line includes a photoelectric photo thermal standard fixed and rate of rise heat detectors The photoelectric detectors transmit a digital of smoke density through a wireless mesh to a gateway and on to a The photo thermal detectors combine a photoelectric chamber and a 135 temperature heat detector The fixed heat detector and rate of rise detectors sensors designed for open area protection with 50 foot spacing capability as by UL 521 sensors offer addressable code wheels and two LEDs The LEDs are controlled by panels Operation modes include red green and amber colors with various solid blink patterns mesh network within the SWIFT system creates a child parent relationship the devices so that each device has two parents providing a second path for on every device If one device can no longer operate for any reason rest of the devices can still communicate with each other directly or through one more intermediate devices SWIFT system also engages frequency hopping to prevent system interference intentional or accidental devices communicate across the mesh network through a gateway to the FACP FACP views the SWIFT wireless device and another addressable device on the providing similar detection functions and outputs as a wired counterpart In both wired and wireless devices can be present on the same FACP to meet needs of a given application A SWIFT wireless system can use any combination of smoke and heat detectors pullstations and A V bases BENEFITS Wireless Detector in B501W Base Wireless installation Addressable code Commercial Class A mesh network UL 268 listed Frequency hopping Bi directional Control Panels 6700 6808 6820 6820EVS Components and Ordering Information WSK PHOTO Intelligent wireless photo detector Ships with base included Requires 4 CR 123A batteries included WSK HEAT ROR Intelligent wireless rate of rise 135 heat Ships with B501W base included Requires 4 CR 123A included WSK PHOTO T Intelligent wireless photo heat detector Ships B501W base included Requires 4 CR 123A batteries WSK HEAT Intelligent wireless fixed temperature 135 heat Ships with B501W base included Requires 4 CR 123A included WSK WGI Wireless SWIFT Gateway 1 SWIFT Gateway is required each wireless mesh and supports up to 49 SWIFT detectors or Connects to the SLC loop of a compatible panel using SK Power may be supplied by the SLC circuit or via an 24VDC input Use of the 24VDC input may be more convenient for service as it allows for powering a gateway without shutting down an SLC loop WSK MONITOR Wireless monitor module Used to monitor with mechanical contact actuation Includes a special with a built in tamper magnet Recommended for in a SMB500 WH box ordered separately rather than metal backbox for best performance Requires 4 CR 123A included WSK RELAY Wireless relay module for use with the WSK WGI gateway Includes a special cover with a built in tamper Recommended for installation in an SMB500 WH box separately rather than a metal backbox for best Requires 4 CR 123A batteries included WSK PULL DA Wireless addressable pullstation Requires 4 CR batteries included WAV CRL WAV CWL SWIFT Wireless Addressable A V bases 8 CR 123A batteries included Requires a non ceiling System Sensor L series notification device separately W SYNC Wireless sync module Requires 4 CR 123A batteries SMB500 WH Optional surface mount backbox SWIFT Tools Programming and diagnostic utility Free download www silentknight com For installation on a typically laptop running an approved version of Windows See Minimum Requirements for SWIFT Tools Requires the W USB radio dongle for communication with SWIFT Wireless devices W USB Wireless USB radio antenna dongle that plugs into the port of a PC running SWIFT Tools The W USB provides a link with SWIFT Wireless devices W BATCART Wireless battery cartridge 10 pack For use with pullstations and A V bases 2 of 3 351614 B 10 3 2018 WSK PHOTO T WSK HEAT ROR WSK HEAT Specifications OPERATING LISTINGS AND APPROVALS 2.4 inches 61 mm installed in B501W base 4.0 inches 102 mm installed in B501W base Weight includes 4 batteries 8.1 oz 230 g in B501W base Temperature Range Photo 32 120 49 Photo thermal with Heat 32 100 0 38 Velocity Photo thermal with Heat 0 4,000 fpm 0 m sec Humidity Range 10 93 non Ratings Fixed Temperature Set Point 135 Rate of Rise Detection 15 8.3 Frequency Range 902 928 MHz Type 4 Panasonic CR123A or 4 Duracell 123A Life 2 years Replacement Upon BATTERY LOW or BAT LOW and or during annual maintenance device complies with part 15 of the FCC rules operation is subject to two conditions The device may not cause harmful interference and 2 device must accept any interference received interference that may cause undesired listings and approvals below apply to the basic wireless detectors In some cases certain may not be listed by certain approval agencies or may be in process Consult factory for latest listing Listed S6173 S6228 7254 0559 0509 7272 0559 0506 Approved ID AUBWFSSD AND CODES SWIFT Wireless Intelligent Detectors comply with the UL Standards and with NFPA 72 Fire Alarm requirements 864 268 Knight System and SWIFT are trademarks of International Inc and Windows are trademarks of Corporation is a registered of Duracell U S Inc Panasonic is registered trademark of Corporation by Honeywell Inc All rights Unauthorized use of document is strictly document is not intended be used for installation We try to keep our information up to and accurate We cannot all specific applications anticipate all requirements specifications are subject to without notice of origin Mexico Silent Knight Clintonville Road CT 06472 1610 B 10 18 Honeywell International Inc
