Simplex 4010 Series 4010 TrueAlarm Fire Alarm Control Panels (C) (A) (F)

ULC CSFM Listed FM Approved NYC Acceptance Fire Alarm Controls Model 4010 Fire Alarm Control Panel for TrueAlarm Sensors and IDNet Addressable Devices features include Up to 250 addressable TrueAlarm sensor or addressable points using IDNet communications that operate either shielded or unshielded twisted pair wiring Four 2 A notification appliance circuits NACs with state current protection Power supply battery charger with 4 A available for and auxiliary power event reporting DACT module standard on 4010 9101 4010 9102 4010 9150 UL listed to Standard 864 convenience features Power limited design provides electronic modules on one piece chassis with up front terminal blocks for access Compact NEMA 1 rated cabinet is available in beige red and can be pre shipped for early installation programming and maintenance features Device level ground fault search locate and isolate Auto Program for general alarm operation TrueAlarm individual analog sensing with front panel and selection access TrueAlarm sensor maintenance alerts service status reports including dirty Default TrueAlarm sensor device type operation TrueAlarm sensor peak value performance report Duplicate address error detection Front panel or PC programming WALKTEST silent or audible system test Software verification simulation mode the following IDNet devices Addressable manual stations TrueAlarm sensor bases housings and isolator bases Quad state zone adapter modules ZAMs for initiating monitoring Quad state line powered individual addressable modules for initiating device monitoring and relay control 4009 IDNet NAC Extenders and accessories option modules include Door mounted 24 LED annunciator std on ULC models Network connection or Point Reporting DACT Class A NAC adapter module RS 232 ports for printer and maintenance PC Expansion power supply Auxiliary Relay Module or Interface Equipment for Suppression Release Applications to data sheet S4010 0003 with Simplex auxiliary panels 4003 Voice Control Panel 4081 Battery Cabinet with charger for 50 Ah batteries Fire Alarm Control Panel with standard door TrueAlarm fire alarm control panels have the ability provide location accuracy for monitoring and control equipped with TrueAlarm analog sensing for smoke heat detection the processing power of the control also has the ability to analyze conditions at each to provide accurate detection with significantly maintenance costs 4010 TrueAlarm Fire Alarm Control Panel has been designed to provide addressable operation and detection in a cost effective package for application that previously were considered only appropriate for zoned monitoring and Service Ease The 4010 mounts on a chassis for quick installation and removal Terminal are large and up front for easy access and inspection modules are easily and quickly installed and as required 4010 cabinet provides convenient stud markers for thickness and nail hole knockouts for quicker Smooth cabinet surfaces are provided for locally conduit entrance holes exactly where required 4010 and electronics can be ordered separately allowing cabinet installation Fault Assistance Ground fault problems often during installation The 4010 provides isolating control of isolator bases and software controlled to isolate ground faults to specific identified This assistance helps the installer to accurately the wiring problem for quicker repair Refer to page 6 for listing details This product has been approved by the California State Marshal CSFM pursuant to Section 13144.1 of the California Health and Safety Code CSFM Listing 7170 0026 226 for allowable values and or conditions concerning presented in this document Accepted for use City of New York Department of MEA35 93E Additional listings may be applicable contact your local Simplex supplier for the latest status Listings and approvals under Simplex Time Recorder are the property of Tyco Safety Products Westminster 5 2013 4010 Operator Control Summary Feature List The 4010 Fire Alarm Control provides access to an extensive feature list that Providing easy and powerful operator information with logical menu driven display Extensive and automatic diagnostics for maintenance History Logs available from the LCD or capable of being printed Software Verification allowing detailed logic simulation to be conducted without connected outputs Control Panel or service PC label editing Password access control Auto Program Quick Configuration Quick CFIG of modules and IDNet devices for general alarm to quickly get the system up and running 4010 Display Panel and Diagnostic Mode Status Information With the locking closed a window allows viewing of the status The 4010 status panel provides a two line by 40 super twist LCD information display and eight LED indicators as shown in the illustration below this display the LED indicators will describe the category of activity being displayed with the LCD more detail For the authorized user unlocking door will provide access to the control switches and further inquiry by scrolling the display for detail Refer to control panel functional below Diagnostic Operation Mode The process allows a single person to perform test The system records test inputs such as alarms or trouble and either logs the response WALKTEST operation or outputs a brief audible notification signal audible operation Extended Operator Control Panel Functions STATUS INDICATOR LEDs provide system status indications in to LCD information LEDs flash to indicate the condition and when acknowledged remain on until reset X 40 LCD READOUT LED backlighted during normal conditions and abnormal conditions provides up to 40 characters for custom label information ALARM DISPLAY Operation can be selected for maintained display of first until acknowledged PROGRAMMABLE LEDs custom labeling labels insert into pocket the top two LEDs are as red or yellow the bottom is selectable as green or yellow VIEW with door closed RESET restores panel to normal when alarmed inputs are to normal ACK acknowledges a Fire Alarm condition the acknowledge and silences the operator and all annunciator tone alerts EXTENDED FUNCTION KEYS accessible with door select and scroll through display prompts for locating system information performing maintenance or for front panel programming ACK acknowledges system supervisory logs the acknowledge and silences the panel and all annunciator tone alerts SILENCE causes audible notification appliances be silenced used after evacuation is complete and alarm source is being investigated ACK acknowledges system troubles the acknowledge and silences the operator and all annunciator tone alerts 5 2013 IDNet Addressable Interface The 4010 provides IDNet addressable device Using a two wire circuit individual such as manual fire alarm stations TrueAlarm and sprinkler waterflow switches can be directly or interfaced to the IDNet controller to their identity and status This addressability the location and condition of the connected device be displayed on the 4010 panel LCD and on system Additionally control circuits fans etc may be individually controlled by using a IAM individual addressable module The 4009 NAC Extender can be controlled for local or notification appliance expansion Refer to device lists on document S4090 0011 and t
