INSTALLATION AND MAINTENANCE INSTRUCTIONS plug in Detector Base use with 1451 2451 AND 2451TH detectors Ohio Avenue St Charles Illinois 60174 FAX 630 377 6495 Diameter Height Temperature Range Humidity Range Ratings includes base and detector Voltage Contact Ratings Resistive Load Time after 60 second reset in 15.7 cm in 2.9cm lb 260 g square box with or without plaster ring minimum depth 1.5 in 4 inch octagon box minimum depth 1.5 in octagon box minimum depth 1.5 in to 49 32 to 120 to 93 Relative Humidity VAC 60 Hz A 2.0A 30VAC DC Form C 2.0A 30VAC DC 1.0A 125VAC used the RA400 RA100Z Remote Annunciator and RTC operates within the specified detector system voltage Seconds maximum INSTALLINg thoroughly read the System Sensor manual I56 407 Guide for Proper of System Smoke Detectors This manual provides detailed information on spacing placement zoning wiring and special applications and is at no charge from System Sensor For installation in Canada refer to Standard for the Installation of Fire Alarm Systems and CEC 1 Sec 32 This manual should be left with the owner user of this equipment The detector used with this base must be tested and maintained following NFPA 72 requirements The detector should be cleaned at once a year DESCRIpTION B404B detector base is designed for use with System Sensor model 2451 2451TH photoelectronic and 1451 ionization detector heads The capabil of plugging these detectors into a variety of special bases makes them more than equivalent direct wired models Refer to the System Sensor cata for other available plug in bases B404B base is intended for use in 4 wire systems with terminals provided power remote annunciator and relay connections This base also contains resistor to provide current limiting in the alarm state TERMINALS Annunciator Coil Used Annunciator Relay A Contacts Relay A Relay C Contacts detector base mounts directly to 31 and 4 inch octagon boxes and square boxes with or without plaster rings To mount the base remove decorative ring by rotating it in either direction to unhook the snaps before the ring from the base Use the screws supplied with the junction box attach the base to the box through the appropriate mounting slots in the base the decorative ring around the base and rotate it in either direction the ring snaps into place see Figure 2 gUIDELINES wiring must be installed in compliance with the National Electrical Code applicable local codes and any special requirements of the authority hav jurisdiction using the proper wire size The conductors used to connect detectors to control panels and accessory devices should be color coded reduce the likelihood of wiring errors Improper connections can prevent a from responding properly in the event of a fire signal wiring the wiring between interconnected detectors it is recom that the wire be no smaller than 16 gauge 1.5 square mm and that or three conductor wire be no smaller than 18 gauge 1.0 square mm best performance alarm loop conductors should be installed in separate conduit or shielded cable to protect the alarm loop from extraneous interference detectors and alarm systems control panels have specifications for al loop resistance Consult the control panel manufacturer specifica for the total loop resistance allowed for the particular model control being used before wiring the detector loops installations where normal ambient temperatures do not exceed 100 1 BASE TERMINALS GAUGE 14 TAB 2 MOUNTINg BASE TO BOx SUPPLIED ON SUPPLIED 3 TypICAL WIRINg DIAgRAM fOR 120VAC DETECTOR SySTEMS 9 10 9 10 LEADS INITIATION LOOP ABOVE DIAGRAM SHOWS NFPA REQUIRED WIRING OF SUPERVISED SYSTEMS SHOWN BELOW FOR REFERENCE BY PANEL INSTRUCTIONS Refer to the manufacturer instructions for releasing device wiring To ensure that electrical connections are supervised do NOT loop under terminals 8 9 10 and 11 Cut the wire at each terminal make electrical connections strip approximately 3 inch 1 cm insulation the end of each wire slide the bare wire end under the clamping plate tighten the clamping plate screw Use the strip gauges molded into the and underside of the base for ease of wiring to terminals 1 and 4 and terminals 6 through 14 respectively zone wiring of the detector base should be checked before installing the detector heads The base contains a built in shorting spring to make possible After the detector base is wired and mounted to an electrical position the shorting spring against terminal 3 This temporary connec energizes the supervisory relay and permits the wiring of the loop to for continuity all detector bases have been mounted wired and the wiring checked the detector heads The shorting spring in the base automatically disen when the detector head is removed from the base DO NOT remove the spring since it reengages as the detector head is turned into the base the circuit fEATURE detector base can be made tamper resistant so it cannot be removed TAB AT DOTTED LINE BY TOWARD CENTER OF BASE the use of a tool To make the base tamper resistant simply break off tab on the base see Figure 4A before installing the detector LEVER remove the detector from the base after it has been made tamper resistant a small screwdriver please see Figure 4B into the small hole and press plastic lever away from the detector Rotate the detector counterclockwise remove Head removal after activating the tamper resistance feature first re removal of the decorative ring 4A ACTIVATINg TAMpER RESISTANCE fEATURE LEVER TAB AT DOTTED LINE BY TOWARD CENTER OF BASE 4B REMOVINg DETECTOR hEAD fROM BASE SMALL BLADED SCREWDRIVER TO PUSH LEVER IN DIRECTION OF ARROW refer to insert for the Limitations of Fire Alarm Systems LIMITED WARRANTy Sensor warrants its enclosed smoke detector base to be free from defects in ma and workmanship under normal use and service for a period of three years from of manufacture System Sensor makes no other express warranty for this smoke base No agent representative dealer or employee of the Company has the au to increase or alter the obligations or limitations of this Warranty The Company of this Warranty shall be limited to the repair or replacement of any part of the detector base which is found to be defective in materials or workmanship under use and service during the three year period commencing with the date of manu After phoning System Sensor toll free number 800 SENSOR2 736 7672 for a Authorization number send defective units postage prepaid to System Sensor Department RA 3825 Ohio Avenue St Charles IL 60174 Please a note describing the malfunction and suspected cause of failure The Company not be obligated to repair or replace units which are found to be defective because damage unreasonable use modifications or alterations occurring after the date of In no case shall the Company be liable for any consequential or incidental for breach of this or any other Warranty expressed or implied whatsoever even the loss or damage is caused by the Company negligence or fault Some states do not the exclusion or limitation of incidental or
