System Sensor BEAMSMK Manual

INSTALLATION AND MAINTENANCE INSTRUCTIONS mounting kit for use with Projected Beam Smoke Detectors This manual should be left with the owner user of this equipment DESCRIPTION BEAMSMK allows reflected beam detectors to be mounted when surface is used This kit must be used when mounting the transmitter receiver with the multi mount kit BEAMMMK Ohio Avenue St Charles Illinois 60174 FAX 630 377 6495 1 DRILL CENTER LOCATIONS kit includes the following parts surface mount box screws Description INSTRUCTIONS Read the installation instructions of the beam detector to determine the number of wires to be used Drill the appropriate holes to mount the surface box to the wall using drill centers on the backside of the surface mount box see Figure 1 locations other than those provided by the drill centers are also ac If the surface mount box is to be mounted over a recessed junction box backside of the box may be removed by scoring the insert with a sharp and then carefully breaking the insert out see Figure 1 Drill the appropriate holes for the conduit using the drill centers provided all four sides of the surface mount box see Figure 1 Conduit sizes of or are acceptable Mount the surface mount box to the appropriate location on the wall us the mounting holes drilled out in the previous step For proper operation of the beam detector the surface mount box must securely mounted to ensure no subsequent movement of the beam detec will occur after the installation is completed See Placement and sections of the beam detector manual for further details For proper operation of the beam detector the surface mount box must mounted to ensure there is line of sight between the transmitter receiver and the reflector See Placement and Mounting sections of the detector manual for further details Pull wiring and conduit through the drilled hole s Attach nut s not to conduit fitting and tighten Be sure to leave enough wire to the transmitter receiver unit when attached to the base Attach the transmitter receiver unit securely to the base using the four plied 8 32 screws Complete the installation of the transmitter receiver unit using the in included with the beam detector Test the system as indicated in the beam detector instructions System Sensor 06 10
