CD100DH Housing for the CD100VC Instructions for the Innovair Duct Housing Overview The mounting should be in return air duct a location that allow easy for modifying calibrating the Box Preparation Remove the box cover by unscrewing the four screws For optimum sensing the three holes located the inlet tube must face the duct air flow If three inlet holes are facing the wrong simply turn the tube while making the box is in the correct orientation Tube Screw Knockout s Secure the inlet tube to the housing by tighten the large screw located in the center of the bracket Once the duct housing is secure pass the through the open conduit hole and the opening on the sensor mounting bracket Using a sharp pointed object punch through a knockout The duct housing is ready to mounted on the duct Installation Using the template provided mark the location the four mounting holes and one 1 1 4 hole inlet tubing on the duct On the duct drill or punch the four mounting and one 1 1 4 air inlet hole Mount the duct housing to the duct using four metal screws V erify the three holes on inlet tube are facing into the airflow Base 4 Using the four mounting screws provided the sensor mounting bracket to the stand off posts in the aspiration box During wire installation use caution while the wires through the box Strip the insulation approximately 1 4 and ensure exposed wire is free of loose strands Sensor Removal Remove the plastic cover Make the necessary wire connections by the pin designations on the terminal label Insert the wires into the terminal and seat the wire insulation flush the terminal blocks When wiring is check for any wiring that may be adjacent wires or terminal blocks For proper operation it is important to maintain airtight seal within the duct housing If any of were modified for wiring that the opening is properly sealed with or putty Sensor Installation The sensor can now be installed First mount top of the sensor to the top of the plastic plate and then firmly press the lower of the sensor into place Upon power up the LCD will read for approximately 15 seconds and 1 minute the sensor will start reading CO2 levels Complete the installation by fastening the lid of box and tightening the four plastic screws The sensor is hinged at the top and fastened at lower end To remove the sensor pull from bottom of the sensor and lift outward The fits snugly into place removal may a hard pull Sensor warrants its enclosed product to be free from defects in materials and under normal use and service for a period of 18 months from date of by the original owner System Sensor makes no other express warranty for this No agent representative dealer or employee of the Company has the authority increase or alter the obligations or limitations of this Warranty The Company of this Warranty shall be limited to the repair or replacement of any part of the which is found to be defective in materials or workmanship under normal use and during the 18 month period commencing with the date of purchase by the original After phoning System Sensor toll free number 800 SENSOR2 736 7672 for a Authorization number send defective units postage prepaid to System Sensor Service RA 3825 Ohio Avenue St Charles IL 60174 Please a note describing the malfunction and suspected cause of failure The company not be obligated to repair or replace units which are found to be defective because damage unreasonable use modifications or alterations occurring after the date of In no case shall the Company be liable for any consequential or incidental for breach of this or any other Warranty expressed or implied whatsoever if the loss or damage is caused by the limitation of incidental or consequential so the above limitation or exclusion may not apply to you This Warranty you specific legal rights and you may also have other rights and you may also other rights which may vary from state to state Sensor Ohio Avenue St Charles IL 60174 736 7672 Fax 630 377 6495 Infrared is a trademark of Engelhard Sensor Technologies is a registered trademark of Engelhard Sensor Technologies 62518B
