System Sensor CO1224

CO1224 Monoxide Sensor CO1224 provides early warning when electrochemical sensing technology accurately carbon monoxide levels in the air monoxide is an odorless colorless tasteless and highly gas that is produced when fuels such as wood gasoline and oil are burned with insufficient air The majority of and commercial fatalities caused from these fuels come heating systems power tools and charcoal grills carbon monoxide is detected the CO1224 will alert residents sounding and flashing a temp 4 signal alarm Protection is 24 7 by a central station regardless of whether residents away from home sleeping or already suffering from the effects CO CO1224 is specifically designed for system operation This means detector is fully listed to UL 2075 offering a code required relay which sends a sensor failure or end of life signal to control panel and the central station as well as SEMS type Philips head screws which provide a quicker and more wiring connection and code required wiring supervision the CO1224 offers a low current draw allowing more detectors be connected to the panel without having to purchase a more panel or an extra power supply the CO1224 is a 12 24 VDC detector it will operate on most security or fire alarm control panels compliance with UL 2075 code required trouble relay supervision with SEMS terminals six year end of life timer VDC current draw of 20mA in standby and 40mA in alarm mounting for wall and ceiling sensing technology Listings Specifications monoxide detector shall be a System Sensor model number CO1224 listed to Underwriters Laboratories UL 2075 for Gas and Vapor Detectors and The detector shall be equipped with a sounder and a trouble relay The detector base shall be able to mount to a single gang electrical box or direct mount to the wall or ceiling Wiring connections shall be made by means of SEMS screws The detector shall provide dual color LED indication which to indicate normal standby alarm or end of life When the sensor supervision is in a trouble condition the detector shall send a trouble signal to the When the detector gives a trouble or end of life signal the detector shall be replaced Specifications Voltage Signal Current Current Contact Ratings Contact Ratings Specifications Weight Temperature Range Humidity Range Terminals 5.1 Width 3.3 Height 1.3 oz 40 C 32 104 F 90 RH 22 AWG back box surface mount to wall or ceiling VDC dB in alarm mA mA 75 mA test A 30 VDC A 30 VDC Modes 1 minute in 4 in 4 Feature Feature Timer Information No volt 4 wire system monitored carbon monoxide detector Pushing the Test Hush button will silence the for 5 minutes When the detector is in a trouble condition it send a trouble signal to the panel After the sensor inside the detector has reached end of its useful life a trouble signal will be to the panel This will indicate that it is time replace the detector An electrochemical monoxide detector lifespan is six years and the detector must replaced by the date marked on the inside of product Ohio Avenue St Charles IL 60174 800 SENSOR2 Fax 630 377 6495 System Sensor specifications subject to change without notice Visit systemsensor com for product information including the latest version of this data sheet 3 07 1772
