System Sensor FAAST 7100X Manual

I AND MAINTENANCE INSTRUCTIONS and 7100XA FAAST Alarm Aspiration Sensing Technology Characteristics Supply Voltage Reset Time Reset Contact Ratings Ratings Temperature Air Temperature Rating Environments 30 VDC monitor must be pulled low for a minimum of 100 msec sec 30VDC 0.5A 125VAC 0 to 100 38 Factory tested to 131 55 20 to 140 60 to 95 non condensing equipment is suitable for use in Class I Division 2 Groups A B C and D or non hazardous locations only Ohio Avenue St Charles Illinois 60174 Fax 630.377.6495 purpose of this document is to provide practical information for mount and connecting to FAAST XS For full product information which includes guidelines instructions for safe use and warranty and safety refer to the FAAST XS Comprehensive User Guide available at or by scanning the QR code INCLUDED WITH UNIT FAAST XS 7100X or 7100XA device Mounting bracket and hardware Installation and Maintenance Instructions USB interface cable PipeIQ software comprehensive manual and other helpful documents available at systemsensor com faast TO FAAST XS XS requires a valid configuration from PipeIQ in order to initialize The must be connected to a PC running PipeIQ with either the USB port or Ethernet port located inside the wiring cabinet Class 1 Div 2 RJ45 and USB Connectors are for maintenance use and shall not be used while in a Hazardous Location unless power has removed or the area is known to be non hazardous TO FAAST XS VIA USB In order to connect your computer to the FAAST XS using a USB con a USB driver must first be installed The driver installation occurs the installation of PipeIQ version 2.2 or later Once the driver is in connect to the device using the following steps Launch PipeIQ Download from www systemsensor com faast Create a new project and select FAAST XS device or open an existing project Expand the tree view in the left side navigation pane to reveal the device Right click on the device and select Device Select USB The USB combo box should already be populated with FAAST Select and enter the password the default password is COM Port Number then click Configuration TO FAAST XS VIA ETHERNET Device Address Mask Gateway 192.168.1.1 DNS DNS 0.0.0.0 YOUR PC PC will need to be sitting on the same local area network as the FAAST device in order to establish communication Change your PC IP address to by Open Area Connection settings and select Select Protocol Version 4 TCP IPv4 and then select Select the following IP address and enter 192.168.1.15 If the subnet does not automatically populate enter 255.255.255.0 into the subnet field Click OK and close out of the network menus Note Before changing your PC IP address be sure to take note of your IP is currently dynamically set or is a static IP address If your PC assigned a static IP address make note of all IP address and settings so that can change back to the proper settings after the FAAST has been configured USING PIPEIQ Launch PipeIQ Download from systemsensor com faast Create and save a new project or open an existing projectx Expand the tree view in the left side navigation pane to reveal the device Right click on the device and select Device Select Host IP and type in the device IP address default is 192.168.1.10 Select and enter the password the default password is word then click Upon connection a green dot will appear on the device icon in the tree equipment must be installed in accordance with all local and national and regulations INSTALLATION pipe layout is designed using the PipeIQ software package Refer to the Instruction Manual to design the pipe network All pipe must installed in accordance with local and national codes and regulations The network should be complete before proceeding with the physical and system installation UNIT INSTALLATION sure that there are no pipes or electrical wires within the wall before any mounting holes THE MOUNTING BRACKET typical mounting location for the FAAST XS unit is on the wall The unit is to the wall using the enclosed mounting bracket Figure 1 shows the mounting bracket For easier access to the FAAST XS unit it is preferred position the mounting bracket in an easily accessible location Place the mounting bracket on the wall in the desired location and use it as template to locate the necessary mounting holes Mark the hole locations and remove the bracket It is recommended to se Accessing your network setting in your PC control panel the bracket using both mounting holes Using a drill and the proper size bit for your mounting hardware drill the and nut on the mounting stud protruding through the mounting slot in Figure 1 Use appropriate fasteners to accommodate the mounting surface and FAAST THE AIR SAMPLING PIPE holes device weight Secure the bracket to the wall THE DETECTOR TO THE BRACKET the mounting bracket is attached the unit is ready to be secured onto bracket Perform the following procedure to mount the unit Before installing the unit onto the bracket remove the appropriate conduit from the top or left side of the unit to match the orientation of the wir Align the unit with the three mounting clips and the mounting stud on the side Locate the conduit openings around the wiring access door Push the unit down onto the mounting clips and secure it with the supplied 1 WALL MOUNTING BRACKET pipe network information and best practices can be found in the Installation Guide available for download at systemsensor com faast input and output ports are designed to accept nominal one inch pipe The input and output ports are tapered to provide fast easy pushfit of the sampling pipe to the unit Perform the following procedure connect the air sampling pipe to the unit Square off and de burr the end of the sampling pipe Ensure that the pipe is from any particles that might interfere with the pipe connection Remove the input plug from the input port being used either the top or bot of the unit Inset the air sampling pipe into the port ensuring a snug fit DO NOT glue pipes PIPE device should always be exhausted into the space that it is monitoring are some circumstances where it may be necessary to connect a pipe the exhaust port to divert the exhaust away from the location of the unit as little as 2ft of exhaust pipe also acts as a muffler for the fan ensur quieter operation Perform the following procedure to connect the exhaust to the unit Square off and de burr the end of the exhaust pipe Ensure that the pipe is from any particles that might interfere with the pipe connection Remove the plug from the exhaust port being used either the top or bottom Inset the air exhaust pipe into the port ensuring a snug fit DO NOT glue the unit pipes 1 4 in TPI Mounting Stud 2 MOUNTING SLOTS FOR MOUNTING STUDS working on the FAAST XS system notify all required authorities that system will be temporarily out of service Make sure all power is removed the system before opening the unit All wiring must be in accordance local codes CABLES the power ratings of the unit and any other connected products to deter the required wire sizes for each connection USAGE electrical conduit has been used for system wiring terminate the conduits the cable entry ports on the top of the unit using the appropriate conduit Run all wiring both power and alarm through the conduit and into the left of the unit enclosure
