System Sensor IM-10 EngSpec

Product Ten Input Monitor Module and Engineering Specifications ten input monitor module shall be a System Sensor model number IM 10 Addressable modules are intended for use in an intelligent fire alarm system and are intended to between a control panel and normally open contact devices such as pull stations contacts or flow switches A common signaling line circuit SLC input is used for all and the initiating device loops share a common supervisory supply and ground each monitor shall operate independently from the others Status conditions are as normal open or short module shall have its own address A pair of rotary code switches shall be used to set the of the first module from 01 to 90 The remaining modules shall be automatically assigned the next nine sequential addresses Because of the possibility of installation error systems use binary jumpers or dipswitches to set the module address are not acceptable Provisions included for disabling a maximum of two unused modules to release the addresses to be elsewhere The modules shall also store an internal identifying code that the control panel use to identify the type of module Systems that require a special programmer to set the address including temporary connection at the panel are labor intensive and not Each module responds to regular polls from the system and reports its type and module address shall have an associated green LED that is controlled by the panel to module status Coded signals transmitted from the panel can cause the LED to blink on or latch off Refer to the control panel technical documentation for module LED status IDC zone shall be wired for Class A Style D or Class B Style B operation The module use plug in terminal blocks for easy wiring Wiring terminals shall be easily accessible for while installed UL 864 Control Units and Accessories for Fire Alarm Systems Agency Standards ULC S527 Control Units for Fire Alarm Systems NFPA 72 National Fire Alarm Code 2010
