and Engineering Specification Sensor L Series Chime Strobe chime strobe shall be a System Sensor L Series Model listed to UL 464 and UL for wall and ceiling installation The chime strobe shall comply with the Americans with Act requirements for visible signaling appliances flashing at 1 Hz over the strobe operating voltage range The strobe shall have field selectable candela settings including 30 75 95 110 135 185 for wall mounted units and 15 30 75 95 115 150 177 for ceiling units The strobe light shall consist of a xenon flash tube and associated system The chime shall have two audibility options and an option to switch a temporal three pattern and a non temporal continuous pattern These options are by a multiple position switch The chime strobe models shall operate between 32 and 120 Fahrenheit chime strobe shall mount to a standard 4 4 1 inch back box 4 inch octagon back box 2 4 17 back box or double gang back box A universal mounting plate be used for mounting ceiling and 4x4 wall products A separate mounting plate shall be for mounting wall 2x4 products The notification appliance circuit wiring shall terminate the mounting plate L Series chime strobe and the Sync Module MDL3 accessory if used shall be from a non coded notification appliance circuit output and shall operate on a nominal or 24 volts When used with the Sync Module MDL3 12 volt rated notification circuit outputs shall operate between 8.5 and 17.5 volts 24 volt rated notification circuit outputs shall operate between 16.5 and 33 volts If the notification are not UL 9th edition listed with the corresponding panel or power supply being then refer to the compatibility listing of the panel to determine maximum devices on a chime strobe shall be plug in and shall have the ability to check wiring continuity via a spring on the universal mounting plate The shorting spring shall also provide tamper via an open circuit if the device is removed All notification appliances shall be compatible
