INSTALLATION AND MAINTENANCE INSTRUCTIONS Advance Plate use with models WTP and WTPW Temperature Rating F to 151 F 40 C to 66 C NEMA 3R IP22 rating requirements PRODUCT Strobe FROM WALL Including Strobe Lens Including Horn 3825 Ohio Avenue St Charles Illinois 60174 FAX 630 377 6495 This product may only be installed in conjunction with an outdoor SpectrAlert Advance Horn Strobe or Horn Strobe HRK R SRK R SRHK R SWK R SWHK R P2RK R P2RHK R P2WK R P2WHK R P4RK R HRK SRK SRK P SRHK SRHK P SWK SWK P SWHK P P2RK P2RK P P2RHK P2RHK P P2WK P2WK P P2WHK P2WHK P P4RK P4WK R models ship minus the outdoor back box stan outdoor and P models ship with an outdoor back box which is not needed when using the weatherproof plate This manual shall be left with the owner user of this equipment This product meets NEMA 3R for indoor or outdoor use to provide a of protection against falling dirt rain sleet or snow and that will be by the external formation of ice on the enclosure DESCRIPTION installation with SpectrAlert Advance outdoor or outdoor replacement horns strobes and horn strobes This accessory plate allows an outdoor to be flush mounted on a number of different surfaces including brick tile concrete and masonry brick The weatherproof plate is offered red and white The weatherproof plate is sold separately from the device 1 WTP AND DEVICE MOUNTING PLATE ASSEMBLY The WTP series of products may be used indoors or outdoors They be installed using the proper SpectrAlert Advance K series product not attempt to use weatherproof plates with devices other than those for use with this product Attach device mounting plate to WTP The WTP is compatible with and 2x4x1 1 2 back boxes Place the device mounting plate on the WTP See Fig 1 and secure the four 6 32 x 3 8 pan head screws A Secure the WTP and device mounting plate assembly to the back box Fig 2 using the two 8 32x2 pan head screws when using a back box B When using the 2x4 back box See Fig 3 secure WTP assembly using the two 6 32x2 pan head screws C Tighten screws until the WTP assembly contacts the wall surface It is the responsibility of the installer to make sure that all openings and are sealed properly An outdoor rated silicon caulk not may be applied around the WTP to fill in around grout tiles or surfaces Connect field wiring to terminals Please follow instruction manual sup with the device Attach the device to the mounting plate by hooking the tabs on the de housing into the grooves on the mounting plate Then swing prod into position to engage the pins on the device with the terminals the mounting plate Make sure that the tabs on the back are fully with the mounting plate Secure the device to the WTP See Fig 4 by tightening the single mount screw D attached to the front of the device housing For tamper the captivated screw may be replaced with the Torx screw with the device 2 ASSEMBLY ATTACHMENT TO 4X4 BACK BOX 3 ASSEMBLY ATTACHMENT TO 2X4 BACK BOX 4 INSTALLED DEVICE AND WTP refer to insert for the Limitations of Fire Alarm Systems LIMITED WARRANTY Sensor warrants its enclosed product to be free from defects in materials and under normal use and service for a period of three years from date of System Sensor makes no other express warranty for this product No representative dealer or employee of the Company has the authority to increase alter the obligations or limitations of this Warranty The Company obligation of this shall be limited to the replacement of any part of the product which is found be defective in materials or workmanship under normal use and service during the year period commencing with the date of manufacture After phoning System toll free number 800 SENSOR2 736 7672 for a Return Authorization number defective units postage prepaid to Honeywell 12220 Rojas Drive Suite 700 El Paso 79936 USA Please include a note describing the malfunction and suspected cause failure The Company shall not be obligated to replace units which are found to be because of damage unreasonable use modifications or alterations occurring the date of manufacture In no case shall the Company be liable for any consequen or incidental damages for breach of this or any other Warranty expressed or implied even if the loss or damage is caused by the Company negligence or fault states do not allow the exclusion or limitation of incidental or consequential dam so the above limitation or exclusion may not apply to you This Warranty gives you legal rights and you may also have other rights which vary from state to state System Sensor 06 10
