System Sensor SAA WTP-SP and WTP-SPW Manual

INSTALLATION AND MAINTENANCE INSTRUCTIONS Advance Plate use with models WTP SP WTP SPW Temperature Rating F to 151 F 40 C to 66 C NEMA 3R IP22 rating requirements PRODUCT Strobe FROM WALL Including Speaker and Lens Including Speaker 3825 Ohio Avenue St Charles Illinois 60174 FAX 630 377 6495 This product may only be installed in conjunction with an outdoor SpectrAlert Advance Speaker or Speaker Strobe SPRK R SPSRK R SPWK R SPSWK R SPWK SPRK SPSWK SPSWK P SPSRK SPSRK P R models ship minus the outdoor back box standard and P models ship with an outdoor back box which is not needed when using the weatherproof plate This manual shall be left with the owner user of this equipment This product meets NEMA 3R for indoor or outdoor use to provide a of protection against falling dirt rain sleet or snow and that will be by the external formation of ice on the enclosure 1 WTP SP AND DEVICE MOUNTING PLATE ASSEMBLY AND AT TO BACK BOX DESCRIPTION installation with SpectrAlert Advance outdoor or outdoor replacement R and speaker strobes This accessory plate allows an outdoor unit to flush mounted on a number of different surfaces including brick ceramic concrete and masonry brick The weatherproof plate is offered in red and and is sold separately from the device The WTP SP series of products may be used indoors or outdoors They be installed using the proper SpectrAlert Advance K series product not attempt to use weatherproof plates with devices other than those for use with this product Attach device mounting plate to the WTP SP as shown in Fig 1 The is compatible with 4x4x2 1 8 back boxes Check orientation of the back box to the WTP SP plate and observe holes will be used for mounting to the back box Place Well Nuts A into the two holes that will NOT be used in the WTP SP to the back box See Fig 1 Place the device mounting plate on the WTP SP and secure using the 8 32 x pan head screws B into the Well Nuts Secure the WTP SP and device mounting plate assembly to the back C using the two 8 32 x 2 pan head screws Tighten screws until the WTP SP assembly contacts the wall surface It is the responsibility of the installer to make sure that all openings and are sealed properly An outdoor rated silicon caulk not may be applied around the WTP SP to fill in around grout lines uneven surfaces Connect field wiring to terminals Please follow instruction manual sup with the device Attach the device to the mounting plate by hooking the tabs on the de housing into the grooves on the mounting plate Then swing prod into position to engage the pins on the device with the terminals the mounting plate Make sure that the tabs on the back are fully with the mounting plate Secure the device to the WTP SP See Fig 2 using the four 8 32 x 3 8 head screws D 2 DEVICE AND WTP SP ASSEMBLY refer to insert for the Limitations of Fire Alarm Systems LIMITED WARRANTY Sensor warrants its enclosed product to be free from defects in materials and under normal use and service for a period of three years from date of System Sensor makes no other express warranty for this product No representative dealer or employee of the Company has the authority to increase alter the obligations or limitations of this Warranty The Company obligation of this shall be limited to the replacement of any part of the product which is found be defective in materials or workmanship under normal use and service during the year period commencing with the date of manufacture After phoning System toll free number 800 SENSOR2 736 7672 for a Return Authorization number defective units postage prepaid to Honeywell 12220 Rojas Drive Suite 700 El Paso 79936 USA Please include a note describing the malfunction and suspected cause failure The Company shall not be obligated to replace units which are found to be because of damage unreasonable use modifications or alterations occurring the date of manufacture In no case shall the Company be liable for any consequen or incidental damages for breach of this or any other Warranty expressed or implied even if the loss or damage is caused by the Company negligence or fault states do not allow the exclusion or limitation of incidental or consequential dam so the above limitation or exclusion may not apply to you This Warranty gives you legal rights and you may also have other rights which vary from state to state System Sensor 06 10
