System Sensor SC-6 Eng Specs

Product Six Supervised Control Module and Engineering Specifications six supervised control module shall be a System Sensor model number SC 6 control modules are intended for use in an intelligent fire alarm system and are for switching applications involving AC DC or audio which require wiring supervision module shall provide supervised monitoring of wiring to load devices that require an power supply or amplifier to operate such as horns strobes speakers or bells Upon from the control panel the SC 6 will disconnect the supervision and connect the power supply across the load device A common signaling line circuit SLC input is for all modules Each module shall have terminals for connection to an external supply for powering devices on its notification appliance circuit NAC shall be a short circuit protection for each module This is provided to protect the external supply against short circuit conditions on the NAC When an alarm condition occurs the which connects the external supply to the NAC shall not be allowed to close if a short circuit currently exists on the NAC In addition an algorithm shall be incorporated to find a when the module is active The device opens all circuits were a fault is detected analyzes them for fault condition and closes all circuits that are not shorted to identify affected NAC module shall have its own address A pair of rotary code switches shall be used to set the of the first module from 01 to 94 The remaining modules shall be automatically assigned the next five sequential addresses Because of the possibility of installation error systems that binary jumpers or dipswitches to set the module address are not acceptable Provisions are for disabling a maximum of three unused modules to release the addresses to be used The modules shall also store an internal identifying code that the control panel shall to identify the type of module Systems that require a special programmer to set the module including temporary connection at the panel are labor intensive and not acceptable module responds to regular polls from the system and reports its type and status module address shall have an associated LED that is controlled by the panel to indicate status Coded signals transmitted from the panel can cause the LED to blink latch on latch off Refer to the control panel technical documentation for module LED status operation power shall be provided by a separate supervised power loop from the main fire control panel or from a supervised UL listed remote power supply The module will use terminal blocks for easy wiring Wiring terminals shall be easily accessible for while installed UL 864 Control Units and Accessories for Fire Alarm Systems Agency Standards ULC S527 Control Units for Fire Alarm Systems NFPA 72 National Fire Alarm Code 2010
