PagePac 1 GENERATOR Multi Tone Generator MTG is a compact versatile generator as well as a Night Bell for a Telephone Six different information tones plus Night Bell are each of which are priority sensitive and individually The Multi Tone Generator utilizes most paging for all page all call applications If the host telephone system does not have a page then a Loop Start Trunk Adapter can be used from the J2 connector to the Loop Start Trunk Night bell activation by a ringing voltage and or AC or DC voltages 6 information tones initiated by contact closures Compatible with most paging equipment Tone level adjustment Quick installation with keyboard style terminal strip and modular jacks Interfaces to mechanical or electronic time clocks for 7 sec tone alarm Comes with its own 12 VAC power supply that plugs into any 120 VAC 60 Hz outlet CSA NRTL Certified Desk Shelf or Wall mountable 5.5 x 4.5 x 2.0 x 11.4cm x 5.1cm 2.0 lbs 0.9 kg Temperature Humidity to 50 14 to 104 to 95 Requirements Nominal 12VAC at 60 Hz The AC power is provided by a 12 VAC wall plug type external transformer with the MTG The AC input power may vary from 95V to 1130V at the wall plug MTG is CSA NTRL certified Manuals Online Manuals Online Multi Tone Generator produces five different tones by contact closure The sixth tone time clock port is activated by making or breaking contacts see Table 1 Requested tones are switched as by the appropriate contact closure onto the paging audio path and provides a contact closure turn on the connected paging equipment for the duration of the tone request J5 LEVEL IN OUT 1 Rear View of Multi Tone Generator 1 Audio Information Tone Siren Siren changes in frequency from 560 Hz to 1050 and back at a rate of 5 times per second changes in frequency from 560 Hz to 1050 and back at a rate of once every 3 seconds Warble changes in frequency from 560 Hz to 1050 at a rate of 2 times per second Pulse frequency of 500 Hz interrupted 5 times per for a period of 30 milliseconds Tone steady tone with a frequency of 680 Hz Pulse pulses same as priority 4 for a duration of 7 upon receipt of an external closing or contact Bell between a frequency of 800 Hz and 1200 at a rate of 20 times per second Signal An audio input signal PIN 10 PIN 9 PIN 8 PIN 7 PIN 6 PIN 5 PIN 1 3 Manuals Online Manuals Online Bell Functions MTG Night Bell function is activated through J1 Pins 1 2 and 3 connector Night Bell If the signal is a nominal 70 Vac 20 cycle ringer voltage use Pins 2 3 The night bell can also be by a key system generating 10 to 30 volts AC at 60 cycles or it can be driven by 24 to 48 Vdc polarity on Pins 1 2 customer owned phone system audio and control lines are attached to J2 Page Input and are unchanged through the MTG to J3 Page Tone Output when it is in the inactive Tones Night Off state This mode is referred to as Through The MTG when accessed will disconnect from J3 and connect the MTG audio and control lines to J3 2 Connectors and Pin Identification J1 10 Pin connector J2 J3 J4 and J5 Quad RJ11 type connectors 10 9 8 7 6 5 4 3 2 1 6 5 4 3 2 1 6 5 4 3 2 1 Siren Siren Warble Pulse Tone Pulse Bell Signal for Night Bell input for Night Bell trigger Page Input Interface to J3 Pin 6 In Audio In Audio In 1 In to J3 Pin 1 Page Amplifier Output Interface to J2 Pin 6 1 Out Out Out Out to J2 Pin 1 Manuals Online Manuals Online 2 Connectors and Pin Identification Continued Throughout Interface to J5 Pin 6 1 In to Tone Request Relay Contacts In to Tone Request Relay Contacts In In to J5 Pin 1 Throughout Interface to J4 Pin 6 1 Out Disconnected by Tone Request J4 Pin 4 Out Disconnected by Tone Request Out to J4 Pin 1 6 5 4 3 2 1 6 5 4 3 2 1 Clock Functions MTG Time Clock Timed Pulse function is activated by momentary make and or break contact transition from N O to N C and N C to N O Time Clock Timed Pulse function can be activated from a mechanical or electronic time clock and respond to both the on and off time trip points A single transition will produce a seven second beep An interval greater than 15 seconds is required between activations to allow for proper reset of clock activated tone circuit of the MTG differs depending on how the MTG will be used There are two different proce for installing the MTG with night bell service when the host telephone system supplies an AC generator or when the host telephone system supplies 24 48 volts DC In addition installation are included for interfacing the MTG to PagePac paging products Manuals Online Manuals Online Tone or Night Bell Service Host Telephone System Supplies a Contact Figure 2 Connect one lead either lead of the contact closure from the host phone system to the Return 4 at connector J1 on the back panel of the MTG Connect the other lead of the contact closure to one of the desired tone terminals 6 10 at connector on the MTG rear panel or to the Timed Pulse Night Terminal 5 Refer to Table 1 for a list of infor tones and their priorities The output of the MTG is provided at connector J3 which is a modular jack Use the red green pair of of a half modular cord to connect from J3 to the Music In port of the paging equipment the customer is already providing background music it must be disconnected from the paging and run through the MTG Make these connections through another half modular cord to the J2 jack Background Music BGM can then be provided from J3 to the Music In port the paging equipment Plug the AC power cord with attached power supply into a nearby 110 Volt Ac 60 Hz outlet The on the MTG rear panel will light OWNED MUSIC SOURCE ED R EEN MODULAR CORD GENERATOR W ER J3 J5 NE LEVEL IN A X S S T T HTBELL E PUT O U TPU T E TO N E IN O U T MODULAR CORD CLOSURE PAGING EQUIPMENT IN PORT TELEPHONE 2 Night Bell Contact Closure Activation Manuals Online Manuals Online Bell Service Host Telephone Provides 90 to 105 Volt AC Ringing Generator Figure 3 Connect the Night Bell source of the Ringing Generator from the host phone system to the MTG at J1 across terminals 2 and 3 The output of the MTG is provided at connector J3 which is a modular jack Use the red green pair of of a half modular cord to connect from J3 to the Music In port of the paging equipment If the is already providing background music then it must be disconnected from the paging equip and run through the MTG Make these connections through anot
