Wheelock 31T horns data sheet

Technical Data TD450075EN AC horns Wheelock 31T 115 VAC horns are high performance horns are ideal alarm signals for life safety applications where sound output low current draw and dependable operation of critical concern 31T AC horn offers rugged vandal resistant construction with metal housings for the horn mechanism models include screw terminal inputs for in out field wiring September 2016 Supersedes June 2011Wheelock 31Tfirealarmresources com Data TD450075EN September 2016 benefits Resonant grille design for high sound output with low draw Each 31T is fully factory assembled to save installation time Screw terminal inputs for fast and secure in out field wiring or outdoor mounting options for semi flush or mounting Attractive red textured finish enhances appearance and durability Vandal resistant CAUTIONS and WARNINGS are identified by the symbol warnings are printed in bold capital letters WARNING READ THESE SPECIFICATIONS AND ASSOCIATED INSTALLATION CAREFULLY BEFORE USING SPECIFYING OR APPLYING PRODUCT FAILURE TO COMPLY WITH ANY OF THESE INSTRUCTIONS OR WARNINGS COULD RESULT IN IMPROPER APPLICATION AND OR OPERATION OF THESE PRODUCTS IN AN SITUATION WHICH COULD RESULT IN PROPERTY DAMAGE SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS compliances UL Standard 464 California State Fire Marshal CSFM 1 31T frNno and sidt vitws 1 SptcificaoiNns and Nrdtring infNrmaoiNne MB mNdtls Number Code Voltage VAC VAC Current dBA 10 ft Typical dBA at 10 feet is measured in an anechoic chamber with nominal voltage Refer to Data Sheet TD450028EN for mounting options and engineers specifications AC horns shall be Wheelock 31T 115 or approved equal Models shall be UL 464 Listed for Fire Protective Service and shall include a cast metal housing to protect the horn mechanism Sound output shall be 95 dBA minimum at 10 feet Mounting options shall include mounting in indoor or outdoor applications and semi flush in indoor applications All models shall have screw terminal inputs for in field wiring The finish shall be textured enamel to continuous development of our products specifications and offerings are subject to change without notice in accordance with Cooper Inc dba Eaton standard terms and conditions ENCOURAGE AND SUPPORT NICET CERTIFICATION WARRANTY is a registered trademark All other trademarks are property of their respective owners Eaton1000 Eaton BoulevardCleveland OH 44122United StatesEaton comEatonLife safety mass notification solutions273 Branchport Ave Long Branch NJ 07740www eaton com massnotification 2016 EatonAll Rights ReservedPrinted in USAPublication No TD450075ENSeptember 2016Wheelock 31Tfirealarmresources com
