Wheelock 43T bells data sheet

Description Wheelock 43T bells provide the durable operation and performance required for life safety alarm systems complete range of vibrating models is offered in 6 and 10 sizes 115 or 24 volt AC operation in indoor or outdoor installations models provide high sound output with low power consumption models are provided with screw terminal inputs for secure in out wiring Data TD450054EN AC bells April 2019 Supersedes September 2016Wheelock 43Tfirealarmresources com Data TD450054EN April 2019 benefits High sound output with low current draw 6 and 10 shell sizes in 115 or 24 AC models Semi flush mounting to standard 4 square backboxes or surface RFI suppression minimizes induced noise on alarm lines to Wheelocks surface backboxes Polarized for supervision of alarm lines with screw terminal inputs fast and secure in out field wiring of 12 to 18 AWG wire Attractive textured finish to enhance appearance and durability For combined audible bell and visual signaling convenient assemblies Series RSSP are available with multi candela single candela strobes See Data Sheet S0410 or Wheelock Products Catalog WARNING READ THESE SPECIFICATIONS AND ASSOCIATED INSTALLATION CAREFULLY BEFORE USING SPECIFYING OR APPLYING PRODUCT FAILURE TO COMPLY WITH ANY OF THESE INSTRUCTIONS OR WARNINGS COULD RESULT IN IMPROPER APPLICATION AND OR OPERATION OF THESE PRODUCTS IN AN SITUATION WHICH COULD RESULT IN PROPERTY DAMAGE SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS compliances Approvals include UL Standard 464 CAN ULC S525 Factory FM and California State Fire Marshal CSFM Complies with OSHA 29 Part 1910.165 1 SptcificaoiNns and Nrdtring infNrmaoiNne MB mNdtls CAUTIONS and WARNINGS are identified by the symbol warnings are printed in bold capital letters 1 43T G10 frNno and sidt vitws 2 43T G6 frNno and sidt vitws code size number Refer to data sheet TD450028EN for mounting options voltage VAC VAC VAC VAC VAC VAC VAC VAC current 10 ft Typical dBA at 10 feet is measured in an anechoic chamber All models are provided with in out screw terminals optionsa E J K N O P R S Each bell mechanism is adjusted to operate only with the shell provided Do not mix shells and mechanisms during installation products must be used within their published specifications and must be PROPERLY specified applied installed operated and operationally tested in accordance with their installation instructions at the time of installation and at least twice a year or often and in accordance with local state and federal codes regulations and laws Specification application installation operation and testing must be performed by qualified personnel for proper operation in accordance with all of the latest National Fire Association NFPA Underwriters Laboratories UL National Electrical Code NEC Occupational Safety and Health Administration local state county province district federal and other applicable building and fire standards guidelines regulations laws and including but not limited to all appendices and amendments and the requirements of the local authority having jurisdiction AHJ www eaton comWHEELOCK 43Tfirealarmresources com Data TD450054EN April 2019 and engineers specifications alarm signals shall be Wheelock 43T bells or approved equal They shall be UL Listed for Fire Protective Service with models vibrating operation and optional steel shells from 6 to 10 diameter Sound output at 10 feet shall range up to 88 dBA The bells semi flush mount to standard 4 square backboxes or surface mount to Wheelock indoor BB backbox or outdoor WBB backbox bell models shall be polarized for line supervision and shall have screw terminals for in out field wiring The finish on all models shall textured enamel to continuous development of our products specifications and offerings are subject to change without notice in accordance with Wheelock Inc dba Eaton standard terms and conditions ENCOURAGE AND SUPPORT NICET CERTIFICATION WARRANTY is a registered trademark All other trademarks are property of their respective owners Eaton1000 Eaton BoulevardCleveland OH 44122United StatesEaton comEatonLife safety mass notification solutions273 Branchport Ave Long Branch NJ 07740www eaton com massnotification 2019 EatonAll Rights ReservedPrinted in USAPublication No TD450054ENApril 2019WHEELOCK 43Tfirealarmresources com
