Wheelock AHWP horn install sheet P83641

Branchport Avenue Branch NJ 07740 631 2148 USA 397 5777 CANADA Thank you for using our products INSTALLATION INSTRUCTIONS AH WP INDOOR OUTDOOR AUDIBLE HORN APPLIANCES this product according to this instruction manual Please keep this instruction manual for future reference Notification AH WP Audible Horn Appliances are designed to provide a selectable continuous horn or code 3 tone when connected to the Fire Alarm Control Panel FACP or provide a synchronized code 3 horn when used in conjunction with a Sync Module SM Dual Module DSM or Wheelock Power Supplies The AH 24WP Appliance is UL Listed under UL Standard 464 for Audible Signal Appliances ULC Listed under Standard CAN ULC S525 07 for Audible Signaling Appliances They are listed for indoor and outdoor use and can be to a 4 backbox See Mounting Options Appliances can be field set to provide High HI dBA Medium MED dBA or Low LO dBA sound output AH WP models are designed for use with either filtered DC VDC or unfiltered Full Wave Rectified FWR input voltage All inputs are for compatibility with standard reverse polarity supervision of circuit wiring by a FACP The code 3 horn incorporates the temporal pattern 1 2 second on 1 2 second off 1 2 second on 1 2 second off 1 2 second on 1 1 2 off repeat specified by ANSI NFPA for standard emergency evacuation signaling The code 3 horn shall be used only for fire evacuation and not for any other purpose All CAUTIONS and WARNINGS are identified by the symbol All warnings are printed in bold capital letters PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT FAILURE TO COMPLY WITH ANY THE FOLLOWING INSTRUCTIONS CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION INSTALLATION OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION WHICH COULD RESULT IN PROPERTY DAMAGE AND INJURY OR DEATH TO YOU AND OR OTHERS THE AH WP APPLIANCE IS A FIRE ALARM DEVICE DO NOT PAINT 1 UL Listed Models and Ratings Voltage RMS Current AMPS 1a ULC Listed Models and Ratings Voltage RMS Current AMPS Horn 3 Horn 2 dBA Sound Output for 24VDC Models dBA Per UL 464 dBA Per CAN ULC S525 07 10 Feet 10 Feet models are UL and ULC Listed for indoor and outdoor use with a temperature range of 40 to 151 40 to 66 and maximum humidity 98 RH 2015 Cooper Wheelock Inc dba Cooper Notification All rights reserved R 1 of 4 3 ULC Directional Characteristics for AH 24WP degrees left and right degrees left and right degrees up and down degrees up and down CHECK THE MINIMUM AND MAXIMUM OUTPUT OF THE POWER SUPPLY AND STANDBY BATTERY AND SUBTRACT VOLTAGE DROP FROM THE CIRCUIT WIRING RESISTANCE TO DETERMINE THE APPLIED VOLTAGE TO THE SIGNALING FOR UL ULC APPLICATIONS THESE APPLIANCES WERE TESTED TO THE OPERATING VOLTAGE LIMITS OF 16.0 33.0 FOR 24V MODELS USING FILTERED DC OR UNFILTERED FULL WAVE RECTIFIED FWR DO NOT APPLY 80 AND 110 OF VOLTAGE VALUES FOR SYSTEM OPERATION MAKE SURE THAT THE TOTAL RMS CURRENT TOTAL AVERAGE CURRENT AND TOTAL PEAK CURRENT REQUIRED ALL APPLIANCES THAT ARE CONNECTED TO THE SYSTEM PRIMARY AND SECONDARY POWER SOURCES NAC CIRCUITS SM SYNC MODULES OR WHEELOCK POWER SUPPLIES DO NOT EXCEED THE POWER SOURCES RATED CAPACITY OR THE RATINGS OF ANY FUSES ON THE CIRCUITS TO WHICH THESE APPLIANCES ARE WIRED OVERLOADING POWER OR EXCEEDING FUSE RATINGS COULD RESULT IN LOSS OF POWER AND FAILURE TO ALERT OCCUPANTS DURING AN WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS calculating the total currents Use Table 1 or 1a to determine the highest value of Current for an individual AH Appliance across the operating voltage range of the AH Appliance then multiply these values by the total number of AH Appliances be sure to add the for any other appliances powered by the same source and include any required safety factors the peak current exceeds the power supplies peak capacity the output voltage provided by the power supplies may drop below the listed range of the appliances connected to the supply and the voltage may not recover in some types of power supplies For example an power supply that lacks filtering at its output stage either via lack of capacitance and or lack of battery backup across the output may this characteristic Audible Horn appliances are not designed to be used on coded systems in which the applied voltage is cycled on and off THE AUDIBLE HORN APPLIANCES MUST BE FIELD SET TO THE DESIRED TONE AND dBA SOUND OUTPUT LEVEL THEY ARE INSTALLED THIS IS DONE BY PROPERLY INSERTING A JUMPER PLUG IN ACCORDANCE WITH THESE INCORRECT SETTINGS WILL RESULT IN IMPROPER PERFORMANCE WHICH COULD RESULT IN PROPERTY AND SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS OUTPUT SPL SETTINGS 1 Showing Location of Jumper Plug J1 J1 setting is on Medium dB and Code 3 2 Plug Settings for High Medium Low dB Code 3 Horn and Continuous Horn Setting 3 needle nose pliers to pull and properly insert the jumper plug HORN jumper plug is needed for continuous horn setting However it is recommended that the jumper plug be retained in the unit for future use if as shown in Figure 2 The Audible Horn must be set for code 3 when used with the sync module Continuous horn operation without sync module R 2 of 4 INFORMATION PRECEDING APPLIANCE ALARM CONTROL PANEL FACP SYNC MODULE TO NEXT APPLIANCE OR OF LINE EOLR Figure 3 4 to Sync Module instruction sheet DSM P83177 and Wheelock Power Supplies for additional information 1 AH WP Appliances have in out wiring terminals that accept two 12 to 18 American Wire Gauge AWG wires at each screw terminal Strip 3 8 inches for connection to screw terminals Break all in out wire runs on supervised circuit supervision as shown in Figure 4 The polarity shown in the wiring diagrams is for the operation the appliances The polarity is reversed by the FACP during supervision Wiring method shall be in accordance with CSA C22.1 Canadian Electrical Code Part 1 Safety Standard for Electrical Installations 32 OPTIONS The following figures show the maximum number of field wires conductors that can enter the backbox used with each mounting If these limits are exceeded there may be insufficient space in the backbox to accommodate the field wires and stresses from the wires damage the product the limits shown for each mounting option comply with the National Electrical Code NEC Cooper Notification recommends use of the backbox option shown and the use of approved stranded field wires whenever possible to provide additional wiring room for easy and minimum stress on the product from wiring MOUNTING MOUNTING SQ X 2 1 8 BACKBOX RESISTANT TO BE MOUNTED WALL SURFACE CONDUIT ON TOP 8 32 SCREWS SCREWS NUMBER OF
