Wheelock ASWP horn strobe install sheet P84820

INSTALLATION INSTRUCTIONS ASWP AUDIBLE STROBE WEATHERPROOF WALL CEILING MOUNT VERSION this product according to this instruction manual Please keep this instruction manual for future reference ASWP appliance is the industry first 2 wire horn strobe alarm appliance that provides a selectable continuous or Code 3 horn tone continuous strobe when connected directly to the Fire Alarm Control Panel FACP or provides a synchronized Code 3 horn tone and strobe when used in conjunction with a Sync Module SM Dual Sync Module DSM or Cooper Wheelock power supplies Cooper Wheelock Multi High Candela ASWP 24MCWH and ASWP 24MCCH appliances provide two selectable settings or 115 177 respectively The ASWP Appliances are UL Listed under Standard 464 for Audible Signal Appliances and Standard for Visual Signaling Appliances Private Mode Use All ASWP models are suitable for outdoor use For outdoor application the must be mounted to the Weatherproof Backbox WPBB All ASWP models are UL Listed to Standard 1971 for Signaling Devices for Hearing Impaired when installed indoors These appliances are also ULC Listed under Standard CAN ULC S526 07 for Visual Signal Appliances and Standard CAN ULC S525 07 for Audible Signaling Appliances The ASWP uses a Xenon flashtube with solid state enclosed in a polycarbonate lens to provide maximum visibility and reliability for effective visible signaling ASWP appliance can be field set to provide high HI dBA medium MED dBA or low LO dBA sound output strobe is designed for use with either filtered DC VDC or unfiltered full wave rectified FWR input voltage All inputs are polarized for with standard reverse polarity supervision of circuit wiring by a FACP The Code 3 temporal pattern second on second off second on second off second on 1 off and repeat is speci by ANSI and NFPA 72 for standard emergency evacuation signaling The Code 3 Horn should be used only for fire evacuation and not for any other purpose All Canadian installations should be in accordance with the Canadian Standard for the Installation of Fire Alarm Systems CAN and the Canadian Electrical Code Part 1 Final acceptance is subject to Authorities Having Jurisdiction AHJ Please read these instructions carefully before using this product Failure to comply with any of the following instruc cautions and warnings could result in improper application installation and or operation of these products in an emergency which could result in property damage and serious injury or death to you and or others Not recommended for use at refrigerator freezer door entrances or other area with persistent condensation 1A UL ULC Models and Ratings UL Ratings 1 Cold Ambient 1 RMS Current w Hi dBA RMS Current w Med dBA RMS Current w Low dBA 1B Maximum RMS Current Note 1 UL1638 is an on axis rating where the following applies WARNING not to be used as a visual public model alarm notifi appliance Use UL1971 and ULC S526 ratings for all public mode applications 2A UL ULC dBA Sound Output at 10 Feet Per UL 464 dBA Per CAN ULC S525 07 3 Horn 91 97 91 97 2B ULC Directional Characteristics per CAN ULC S525 07 101dB Reference 90 degrees Axis Axis Reference 90 degrees 102dB degrees degrees degrees degrees degrees degrees Strobe produces 1 flash per second over the Regulated Voltage range These models meet the required light distribution patterns defined in UL1638 ULC S526 07 and UL 1971 All models are listed for indoor and outdoor use UL 1971 is tested from a temperature range of 32 to 120 0 to 49 UL is tested from a temperature range of 40 to 150 40 to 66 with a maximum humidity of 98 2 RH The effect shipping and storage temperatures shall not adversely affect the performance of the appliances when it is stored in the original and is not subjected to misuse or abuse Strobes are not designed to be used on coded systems in which the applied voltage is cycled on and off calculating the total current Use Table 1A to determine the highest value of RMS Current for an individual ASWP Appliance then the value by the total number of ASWP Appliances Add the currents for any other appliances powered by the same source and any required safety factors The maximum number of strobes on a single notification appliance circuit shall not exceed 50 Candela setting will determine the current draw of the product These appliances were tested to the regulated voltage limits of 16 33 Volts for 24V models using filtered DC or unfil full wave rectified voltage Do not apply voltage outside of this range Check the minimum and maximum output of the power supply and standby battery and subtract the voltage drop from circuit wiring resistance to determine the applied voltage to the strobes The maximum wire impedance between strobes shall exceed 35 ohms Make sure that the total RMS current required by all appliances that are connected to the system primary and second power sources notification appliance circuits SM DSM sync modules or Cooper Wheelock power supplies does not exceed power sources rated capacity or the current ratings of any fuses on the circuits to which these appliances are wired Overload power sources or exceeding fuse ratings could result in loss of power and failure to alert occupants during an emergency which result in property damage and serious injury or death to you and or others Branchport Ave Long Branch N J 07740 800 631 2148 www coopernotification comPN P84820JCopyright 2013 Cooper Wheelock Inc dba Cooper Notificationfirealarmresources com AND SOUND OUTPUT SPL SETTINGS set the candela slide the switch to the desired setting The setting in indicated by the pointer and label visible on the bottom of the lens If the ASWP housing does not properly contact the gasket on the WPBB backbox moisture may seep into the ASWP used in an outdoor application and this could result in improper operation of the product the limits shown for each mounting option comply with the National Electrical Code NEC Cooper Notification recommends use the largest backbox option shown and the use of approved stranded field wires whenever possible to provide additional wiring room easy installation and minimum stress on the product from wiring CANDELA POINTER VIEW CANDELA POINTER VIEW 3 2 Showing Location of the Plug 1 setting is on medium dB and Code 3 ASWP MCWH comes preset at 185cd ASWP MCCH comes preset at 177cd The candela select switch must be field set to the required candela intensity before installation When changing the of the candela select switch make certain it clicks in place After changing the candela setting the appliance must be to verify proper operation Improper setting of the candela select switch may result in operation at the wrong candela could result in property damage and serious injury or death to you and or others The audible strobe appliances must be field set to the desired tone and dBA sound output level before they are This is done by properly inserting jumper plugs in accordance with these instructions Incorrect settings will result in performance which could result in property damage and serious injury or death to you and or others needle nose pliers to pull and properly set the jumper plugs No jumper plug is needed for continuous horn setting However it is that the jumper plug be retained in the unit for future use if needed as shown in Figure 4 SET ON HIGH dB SET ON MED dB SET ON LOW dB
