Wheelock E50H & E60H speakers data sheet

Technical Data TD450017EN E50H E60H High Fidelity Speaker Strobes Wheelock E50H Wall and E60H Ceiling Speakers and Speaker are designed for high fidelity sound output for indoor With the widest frequency response range 300 8000 Hz in the industry the EH product line features leading with crisp clear voice messages and tone signaling for emergency communications mass notification and voice a sleek aesthetic appearance the wall and ceiling feature dual voltage 25 70 VRMS capability and taps from 1 8 to 2 watts For faster and easier the low profile design incorporates a speaker mounting and each model has a built in level adjustment feature and cover with no visible mounting screws visible signaling to meet the hearing impaired the Series EH Strobe models incorporate the low current draw of the RSS options for wall mount models include Wheelock patented multi candela strobe with field selectable candela settings 15 30 75 110cd or the high intensity MCWH strobe with field 135 185cd mount models are available in Wheelock patented MCC ceiling strobe with field selectable intensities of or the high intensity MCCH strobe with field 115 177cd strobe portion of all Series EH Speaker Strobes may be when used in conjunction with the Wheelock DSM Modules Wheelock Power Supplies or other manufacturers incorporating the Wheelock Patented Sync Protocol synchronized strobes offer an easy way to comply with recommendations concerning photosensitive epilepsy EH Speaker Strobes are UL Listed for indoor use under 1971 Signaling Devices for the Hearing Impaired and 1480 Speaker Appliances and ULC listed under CAN Visual audible Signal Appliances Fire Alarm and under Speakers Fire Alarm All inputs employ IN OUT terminals for fast installation using 12 to 18 AWG wiring options for the Series EH Speakers and Speaker Strobes are and white January 2016Supersedes January 2015 firealarmresources com Data TD450017EN December 2015 High Fidelity Sound Output Efficient design for high intelligibility at minimum wattage a frequency range of 300 to 8000 HZ 6 Field Selectable Settings in 1 Device Wall mount models are available with Field Selectable Candela of 15 30 75 110cd or 135 185cd Multi Candela models 1575cd Single Candela model Ceiling mount models are available with field selectable candela of 15 30 75 95cd or 115 177cd Multi candela models Field Selectable Taps 1 8 watt up to 2 watts 25 or 70 VRMS operation Easy to Install Low profile design incorporates speaker mounting plate for and easier installation Snap on grille cover with no visible mounting screws Quick installation with IN OUT screw terminals using 12 to AWG wires 4 square backbox prevents wire damage Series E50H No extension ring required Series E60H Optional Extender E60 Ext is available for to 4 square backboxes Strobe Synchronization Components Meet synchronizing standards with Wheelock DSM Sync PS 6 8 Power Supplies or SAFEPATH products Compliance UL 1971 UL 1480 ULC S526 ULC S541 Low frequency requirements of UL 464 520 Hz to meet 520 Hz tone requirements for sleeping areas California State Fire Marshal CSFM ADA NFPA ANSI OSHA FCC Part 15 ICES read these specifications and associated installation instruc before using specifying or installing this product Visit Eaton com for current installation instructions 1 E50H top and E60H bottom Speakers Front Side Views 2 E50H top and E60H bottom Speaker Strobes Front Side Views Notes Strobes are designed to flash at 1 flash per second minimum over Voltage Range Note that NFPA 72 specifies a rate of 1 to 2 flashes per second and ADA Guidelines specify flash rate of 1 to 3 flashes per second All candela ratings represent minimum effective Strobe intensity on UL 1971 E50H E60H High Fidelity Speakers Speaker StrobesEATON www eaton comfirealarmresources com Data TD450017EN December 2015 1 Maximum RMS Current Voltage VDC 2 UL Listed Models and Ratings Max Current a 24MCWH 24MCCH Speaker Strobe Speaker Speaker Strobe Reverberant dBA at 10 Feet b watts watts watts watts watts 3 Specification Ordering Information Candela w DSM or Power Supplies Lettering Lettering Lettering Lettering Lettering Lettering AA AA AA BB BB BB BB BB BB BB BB or white textured UV stabilized colored impregnated engineered plastic Exceeds 94V 0 UL flammability rating Speaker x xx lbs xxg E50H Speaker Strobe x xx lbs xxg E60H Speaker x xx lbs xxg E60H Speaker Strobe x xx xxg Speaker 5 W x 5 H x 1.47 E50H Speaker Strobe 5 W x 6.74 H x 2.58 E60H Speaker 7.38 Diameter x D E60H Speaker Strobe 7.38 Diameter x 3.02 D 33.8 to 120.2 0 to 49 and maximum humidity of 93 square backbox prevents wire damage Series E50H No extension ring required Series E60H Optional Extender Ext is available for mounting to 4 square backboxes through 18 AWG VRMS 1971 ULC S526 are designed to flash at 1 flash per second can be synchronized with Wheelock DSM Sync Modules Power Supplies or SAFEPATH products using patented sync protocol Hz to 8000 Hz Range RMS current ratings are per UL maximum RMS method UL max current rating is the maximum RMS current within the listed voltage range 16 33v for 24v units For the UL max current is usually at the minimum listed voltage 16v for 24v units For audibles the max current is usually at the maximum listed voltage 33v for units For unfiltered FWR ratings see installation instructions dBA ratings are based on testing under UL Standard 1480 1 8 watt tap is for private mode only E60 EXT is an attractive extender ring that mounts behind the speaker to permit mounting to a 4 square x 2 1 8 deep electrical box without need for an extension on the box Strobes Ring d d 4 Specifications Temperature Wire Connections indoor only Connections General voltage Output Rating Flash Rate Models E50H E60H High Fidelity Speakers Speaker StrobesEATON www eaton comfirealarmresources com Data TD450017EN January 2016 and Engineers Specifications E50H The speaker appliances shall be Wheelock E50H Fidelity Speakers and the High Fidelity Speaker Strobe appli shall be Wheelock E50H Speaker Strobes or approved equals speakers shall be UL Listed under UL 1480 for Fire Protective and speakers equipped with strobes shall be listed under UL for Emergency Devices for the Hearing Impaired In addition strobes shall be certified
