Wheelock Eluxa blue lens strobes ceiling install sheet P85756-002

INSTALLATION INSTRUCTIONS ELUXA STROBE PRE WIRE PRE TEST MOUNT BLUE LENS this product according to this instruction manual Please keep this instruction manual for future reference Wheelock Eluxa ELSTC B multi candela strobes are designed for easy installation with a pre wire capable mounting plate All are for 24V operation ELSTC B is designed for ceiling mounting only Wheelock Eluxa Series meets NFPA 2016 20 millisecond light pulse duration code requirements In addition the Wheelock and LED3 product lines have been UL ULC listed as compatible with all Fire Alarm Control Panels FACP and accessories have been determined to be compatible with Wheelock model RSS Strobe based products including the RSS CH E EH SA STH and Z Series The maximum number of Eluxa devices per NAC is determined by dividing the maximum rating of the FACP NAC by the total current rating of one Eluxa device with a maximum of 105 Eluxa or LED3 devices per Refer to FACP installation instructions for more detail The Wheelock Eluxa Series and Exceder LED3 Series strobes may be in the same notification zone and field of view with any RSS Strobe based product Eluxa Strobes can provide a non synchronized strobe appliance when connected directly to a Fire Alarm Control Panel or provide a synchronized strobe appliance when used in conjunction with an FACP that incorporates the Cooper Wheelock protocol a Dual Sync Module DSM or the Wheelock Power Supply PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT FAILURE TO COMPLY ANY OF THE FOLLOWING INSTRUCTIONS CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICA CANDELA SETTING INSTALLATION AND OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS Do not change factory applied finishes NOT PAINT Ne pas modifiez les finitions appliqu en usine PAS PEINTURER 1 Specifications UL1638 ULC S526 16 Use Only 0 C 50 C 32 F 122 F 93 R H Characteristics line resistance 35 Power or FWR 24V Regulated 16 to 33V All models Candela 12 30 40 50 60cd field selectable is an on axis rating where the following applies effective candela rating per UL1971 BLUE STROBES ARE NOT TO BE USED AS A VISUAL PUBLIC MODE ALARM NOTIFICATION APPLIANCE 2 ELSTC B Strobe Current Draw Amps 24 volts Candela Settings cd Candela Setting will determine the current draw of the product Strobes will produce 1 flash per second over the Voltage range Strobes are not designed to be used on coded systems in which the applied voltage is cycled on and off When calculating the total currents use Tables 2 to determine the highest value of RMS current for an individual appliance then these values by the total number of appliances Be sure to add the currents for any other appliances including audible appliances powered by the same source and to include any required safety factors Make sure that the total rms current required by all appliances that are connected to the system primary and secondary power Notification Appliance Circuit NAC sync module DSM sync modules or Wheelock power supplies does not exceed power sources rated capacity or the current ratings of any fuses on the circuits to which these appliances are wired Refer to Module instruction sheets DSM P83177 or Wheelock Power Supplies for additional information Check the minimum and maximum output of the power supply and standby battery and subtract the voltage drop from the circuit resistance to determine the applied voltage to the strobes These appliances were tested to the regulated voltage limits of 16.0 33.0 Volts for 24 volt models using either filtered or unfiltered Do not apply voltage outside of this range These notification appliances are UL Listed as They are intended to be used with Fire Alarm Control Panels whose notification circuits are UL Listed as Refer to the FACP instructions or the Wheelock Strobe Compat Data Sheet P85328 for special application and strobe synchronization compatibility 1 ELSTC B Expected Light Output WHEN INSTALLING STROBES IN AN OPEN OFFICE OR OTHER AREAS CONTAINING PARTITIONS OR OTHER OBSTRUCTIONS SPECIAL ATTENTION SHOULD BE GIVEN TO THE LOCATION OF THE STROBES SO THAT OPERATING EFFECT CAN BE SEEN BY ALL INTENDED VIEWERS WITH THE INTENSITY NUMBER AND TYPE OF BEING SUFFICIENT TO MAKE SURE THAT THE INTENDED VIEWER IS ALERTED BY PROPER ILLUMINATION OF THE VIEWER ORIENTATION A SMALL POSSIBILITY EXISTS THAT THE USE OF MULTIPLE STROBES WITHIN A PERSON FIELD OF UNDER CERTAIN CIRCUMSTANCES MIGHT INDUCE A PHOTO SENSITIVE RESPONSE IN PERSONS WITH EPILEPSY REFLECTIONS IN A GLASS OR MIRRORED SURFACE MIGHT ALSO INDUCE SUCH A RESPONSE TO MINIMIZE POSSIBLE HAZARD COOPER WHEELOCK STRONGLY RECOMMENDS THAT THE STROBES INSTALLED SHOULD PRESENT A COMPOSITE FLASH RATE IN THE FIELD OF VIEW WHICH EXCEEDS FIVE 5 HZ AT THE OPERAT VOLTAGE OF THE STROBES COOPER WHEELOCK ALSO STRONGLY RECOMMENDS THAT THE INTENSITY AND FLASH RATE OF INSTALLED STROBES COMPLY WITH LEVELS ESTABLISHED BY APPLICABLE LAWS REGULATIONS CODES AND GUIDELINES NFPA 72 ANSI 117.1 conform to ADAAG Equivalent Facilitation Guidelines in using fewer higher intensity strobes within the protected area SETTINGS AND MOUNTING All strobe appliances have in out wiring terminals that accept two 12 to 18 American Wire Gauge AWG wires at each screw Strip leads 3 8 inches and connect to screw terminals Do not fully back out terminal screws Break all in out wire runs on supervised circuits to ensure integrity of circuit supervision as shown in Figure 3 The polarity shown in 2 the wiring diagram is for the operation of the appliances The polarity is reversed by the FACP during supervision PRECEDING FACP SYNC MODULE NEXT SIGNAL END OF LINE EOLR 2 Strobe NAC Wiring 3 Wire Connection Branchport Ave Long Branch N J 07740 800 631 2148 www coopernotification comP85756 002ACopyright 2020 Cooper Wheelock Inc dba Cooper Notification All rights reserved firealarmresources com SCREW DRIVER INTO PUSH IN TO RELEASE AND LIFT UP TO REMOVE COVER PRESS IN LIFT Up OFF WHEN 3 4 IS USED METAL STRAP WOOD SCREW 4 Horn Strobe Settings 5 Removing the Cover OPTIONS BACKBOX BACKBOX TAB Figure 6 Surface Back box A Surface Mount with Box B Flush Mount with x 2 1 8 Back Box C Flush Mount with Back Box SQUARE BACKBOX SCREW 2 THREAD CUTTING SCREW THREAD CUTTING SCREW Final acceptance is subject to Authorities Having Jurisdiction method shall be in accordance with In the United States the National Electrical Code NFPA 70 and the National Fire Alarm and Signaling Code NFPA 72 In Canada CSA C22.1 Canadian Electrical Code Part I Safety Standard for Electrical Installations Section 32 Do not over tighten mounting screws Excessive torque can distort the base and may affect operation When power tools to screw down the mounting plate to the electrical backbox ensure the torque is set to the lowest setting WARNING OVERLOADING POWER SOURCES OR EXCEEDING FUSE RATINGS COULD RESULT IN LOSS OF POWER FAILURE TO ALERT OCCUPANTS DURING AN EMERGENCY WHICH COULD RESULT IN PROPERTY DAMAGE AND INJURY OR DEATH TO YOU AND OR OTHERS Check the installation instructions of the manufacturers of other equipment used in the system for any or restrictions on wiring and or locating Notification Appliance Circuits NAC and notification appliances Some communication circuits and or audio circuits for example may require special precautions to assure immunity from noise e g audio crosstalk This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to part 15 of the Rules These limits are designed to provide reasonable protection against harmful interference when the equipment is operated a commercial environment This equipment generates uses and can radiate radio frequency energy and if not installed and used accordance with the instruction manual may cause harmful interference to radio communications Operation of this equipment in residential area is likely to caus
