Wheelock Eluxa family brochure

Wheelock Eluxa next generation notification appliances Eluxa Eluxa Eaton best in class LED notification appliances A unit of illumination equal to 1 lumen per square meter Light of the sun and stars Bright light Eluxafirealarmresources com make safe sound work it comes to protecting life and property there no room compromise The leading solutions for life safety and mass from Eaton are designed to save lives In the most industrial and commercial environments we make safe sound work Because that what really matters specializes in the notification aspect of life safety This enables to focus on advancing technology in this critical market For nearly century our Wheelock product lines have stood for innovation trusted product line with proven experience Eaton offers many firsts From designing the industry first xenon fire alarm to developing the industry first LED strobes we our engineering expertise of 100 plus years of combined fire to perfect audible and visual appliance technology our new LED line Eluxa next generation life safety notification appliances compatible compact and energy efficient features a complete portfolio of indoor notification appliances a comprehensive range of low and high candela settings six settings in a single device Utilizing the latest advancements LED technology Eluxa features the industry lowest current across the full candela range providing the ultimate in energy Competitive models can draw up to 3 times the current an average circuit consumes 70 more current than Eluxa This substantially reduces overall power consumption for a greater number of appliances on the NAC and fewer supplies resulting in significant material and system cost addition Eluxa features a compact aesthetically pleasing design doesn detract from building d product line has been UL ULC listed as compatible with all fire control panels and accessories that have been determined be compatible with Wheelock RSS strobe based products and LED3 This means Eluxa devices are backward compatible one of the largest installed bases in the country It also meets 20 millisecond light pulse duration requirements of NFPA 72 By meeting this requirement the Eluxa product line has been by UL to allow mixing of Wheelock legacy xenon devices in the field of view on average 70 in NAC current draw inventory Up to 6 models in 1 appliance power supplies batteries lower installation lower maintenance costs Eluxafirealarmresources com horns horn strobes strobes current draw System cost savings is feature rich with six candela settings and three horn Continuous T3 T3 T4 in a single device which not reduces customers inventory but also is an industry first combining both fire alarm and carbon monoxide CO over same two wires Activation is accomplished through digital To reduce installation time Eluxa includes pre wire via a rigid mounting plate with hinged feature and no tools for setting changes The ELST strobe ELHS horn strobe and ELHN horn are for 24V operation ELHN is also suitable for applications efficient LED technology provides industry lowest current draw for a high and low candela device Fewer power supplies required smaller wire gage reduced runs UL ULC listed as compatible with all Fire Alarm Control Panels and accessories that have been determined to be with Wheelock RSS strobe based products and LED3 Ability to mix LED and xenon strobes in the same field of view Meets stringent synchronizing standards for strobes with DSM Sync Modules PS Power Supplies or products profile design One of the smallest most compact single gang designs Sleek modern aesthetics with no visible mounting screws lettering and amber and blue lens Field selectable settings Wall 15 30 75 110 135 185 cd Ceiling 15 30 75 110 150 177 cd Horn patterns 3 horn patterns Continuous T3 and T3 T4 Fire and CO signaling Mounting plate included with all models Convenient capture allows installers to easily hold the device while fastening the screw in place Pre wire pre test capability to check for wiring and ground faults to appliance installation Finger slide switches No tools needed for setting changes IN OUT screw terminals using 12 to 18 AWG wires Mounting options include ELSBB any single gang backbox and 4 square with adapter kit for wall models and LSPKBB C 4 square 1 1 2 or 2 1 8 and 4 Octagonal 1 or 2 1 8 for ceiling models approvals NFPA 72 2016 meets maximum light pulse duration of 20 ms UL 1971 UL 1638 UL 464 ULC S525 ULC S526 California State Fire Marshal CSFM ADA NFPA ANSI OSHA Eluxafirealarmresources com low frequency sounders and sounder strobes both fire alarm and CO code requirements for sleeping areas Eluxa low frequency sounder line not only organizations to meet sleeping room for both fire alarm and CO signaling it features both high and low candela settings 1 device Eluxa provides two different sound T3 for fire detection and T4 for CO The low frequency sounders can replace facility existing appliances utilizing the same pair of wires that are currently installed a simple retrofit to meet new codes for rooms Indoor wall and now ceiling models available ideal for hotels motels apartment buildings and assisted facilities horn patterns Continuous T3 and T3 T4 Fire and CO signaling in 1 device field selectable settings Wall 110 177 cd Ceiling 110 177 cd lettering ALERT CO no lettering design Smallest footprint with sleek modern aesthetics Mounting plate included with all models capture hinge allows installers to hold the device while fastening the single screw in place Finger slide switches No tools needed for changes Built in level adjustment feature and snap on cover wires IN OUT screw terminals using 12 to 18 Mounting options include ELSPKBB backboxes backboxes and 4 square backboxes wall models and LSPKBB C backboxes and square 2 1 8 deep backboxes for ceiling synchronization components Meet synchronizing standards with Wheelock Sync Modules or Power Supplies NFPA 72 2016 20 ms flash duration requirements UL 1971 UL 1638 UL 464 ULC S525 ULC California State Fire Marshal CSFM ADA NFPA ANSI OSHA Eluxafirealarmresources com high fidelity speakers and speaker strobes the industry widest frequency response range our speakers provide crisp clear voice messages concise and intelligible voice messages that communicate people should respond in an emergency are critical for life At Eaton we understand that you need a solution that not meets your customer intelligibility and reliability requirements also provides overall system cost savings for high fidelity sound output Wheelock Eluxa speaker not only features the widest frequency response range in the but also an advanced power saving LED technology with a range of high and low candela settings for indoor wall and ceiling applications With a response range of 300 to 8000 Hz ELSPK and ELSPST models provide leading intelligibility with clear voice messages ideal for emergency communications notification and voice evacuation Eluxa speaker strobes and speakers feature one of the smallest footprints and a sleek modern low profile design will please building owners It includes 5 field selectable tap 6 field selectable candela settings and convenient wall ceiling mounting options for both new and retrofit construction lens speaker strobes and special lettering are available Eluxafirealarmresources com fidelity sound output High intelligibility at minimum wattage across
