Wheelock Eluxa surface backbox install sheet P85446

INSTRUCTIONS ELUXA SURFACE BACKBOX ELSBB ELUXA ADAPTOR ESB KIT this product according to this instruction manual Please keep this instruction manual for future reference Wheelock Eluxa Surface Backbox LSBB is UL and ULC listed to allow Wheelock Eluxa ELHN wall horn ELST strobe and ELHS appliances to be surface mounted The Adapter Kit EBS KIT allows the same appliances to be mounted to a standard single gang or 4 inch sq electrical back box ELSBB backbox and ESB KIT are UL and ULC Listed for indoor use only with the matching EL series appliances All CAUTIONS and WARNINGS are identified by the symbol All warnings are printed in bold capital letters PLEASE READ THESE INSTRUCTIONS CAREFULLY FAILURE TO COMPLY WITH ANY OF THE FOLLOWING CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION INSTALLATION AND OR OF THESE PRODUCTS IN AN EMERGENCY SITUATION WHICH COULD RESULT IN PROPERTY DAMAGE AND INJURY OR DEATH TO YOU AND OR OTHERS Do not change factory applied finishes NOT PAINT Ne pas modifiez les finitions appliqu en usine PAS PEINTURER method shall be in accordance with In the United States the National Electrical Code NFPA 70 and the National Fire Alarm and Signaling Code NFPA 72 In Canada CSA C22.1 Canadian Electrical Code Part I Safety Standard for Electrical Installations Section 32 PROCEDURES 1 ELSBB Surface Mount Branchport Ave Branch N J 07740 631 2148 2 Flush Mount on Single Gang Backbox 2 Applies to ESB KIT Flush Plate Please read the installation instructions provided with appliance before proceeding with the Use the 6 32 mounting screws supplied with the to mount Eluxa pre wire mounting plate over the plate to single gange backbox as shown in the 2 Install field wiring and appliance per the Eluxa appliance sheet 1 Applies to ELSBB Surface Backbox Please read the installation instructions provided with appliance before proceeding with the installation Use mounting screws supplied with this product to mount backbox as shown in the Figure 1 ELSBB has two 2 available 1 2 inch knockouts Remove the necessary conduit knock out s Install field wiring and appliance per the appliance instruction 3 Flush Mount on 4 Square Backbox 3 Applies to ESB KIT Flush Plate Please read the installation instructions provided with appliance before proceeding with the Flush mount single gang adaptor mud ring Eaton or equivalent to 4 square backbox using 8 32 screws Use the 6 32 mounting screws supplied with Eluxa to mount Eluxa pre wire mounting plate over the plate to single gang adaptor mud ring in Fig 3 Install field wiring and appliance per the Eluxa appliance sheet Check that the installed product will have sufficient clearance and wiring room prior to installing backboxes and especially if sheathed multiconductor cable or 3 4 inch conduit fittings are used P85446A Do not over tighten mounting screws Excessive torque can distort the base and may affect operation When using tools to screw down the mounting plate to the electrical backbox ensure the torque is set to the lowest setting available MATERIAL EXTRAPOLATED FROM THIS DOCUMENT OR FROM COOPER WHEELOCK MANUALS OR OTHER DOCUMENTS THE PRODUCT FOR USE IN PROMOTIONAL OR ADVERTISING CLAIMS OR FOR ANY OTHER USE INCLUDING OF THE PRODUCT S APPLICATION OPERATION INSTALLATION AND TESTING IS USED AT THE SOLE RISK OF USER AND COOPER WHEELOCK WILL NOT HAVE ANY LIABILITY FOR SUCH USE NO CASE WILL SELLER LIABILITY EXCEED THE PURCHASE PRICE PAID FOR A PRODUCT 2020 Cooper Wheelock Inc dba Cooper Notification 1
