Technical Data TD450030EN ET 1010 ET 1080 vandal speakers speaker strobes Wheelock ET Vandal Resistant speakers and speaker strobes a full range of rugged high performance combinations designed to meet the critical needs of the life safety for voice and tone signaling Available in compact pleasing package styles each ET model covers both 25 70 volt audio systems and has multiple wattage taps from 1 8 to watts Their high efficiency design provides improved voice clarity higher sound output for typical low frequency fire evacuation such as the whoop and Code 3 Speaker Strobes are designed to meet the latest requirements NFPA 72 National Fire Alarm Code ANSI 117.1 American Standard of Accessible and Usable Buildings and Facilities UL Standard 1971 Standard for Signaling Devices for the Impaired and UL Standard 1480 Speakers for Fire Signaling Systems ET80 Speaker Strobes are UL Listed for indoor use wall under Standards 1971 and 1480 for Speaker Appliances incorporate a Lexan lens to provide maximum reliability for visible signaling The ET80 24MCW FR ULC model is listed under ULC Strobe options include Multi candela strobes with field selectable 15 30 75 110 or MCWH strobes field selectable 135 185 candela Single candela 1575 strobes 15cd with 75 cd on axis are also available Speaker Strobes when used with Wheelock DSM Sync or Wheelock Power Supplies produce synchronized flashes for compliance with ADA guidelines concerning epilepsy speakers are listed for indoor outdoor use with a range of 40 to 66 40 to 150 and maximum of 98 R ET 1080 X ULC D uses a dedicated surface back box part OSB R for red devices and OSB W for white include CAN ULC S541 January 2022Supersedes November 2020 firealarmresources com Data TD450030EN January 2022 Approvals Include UL Standard 1480 UL Standard 1971 California Fire Marshal CSFM New York City MEA Chicago BFP and FCC Part 15 Complies with OSHA 29 Part 1910.165 Designed to meet or exceed NFPA ANSI Standards and ADA Guidelines High efficiency speakers designed for maximum output at wattage across 400 to 4000 Hz frequency range Hz for ULC Model ET80 Field selectable taps for 25 or 70 VRMS operation from 1 8 watt to 8 watts in 3 dB steps ET80 Speaker Strobe models available with Multi candela strobes 15 30 75 110cd and 135 185cd or single candela strobes 15cd with 75cd on axis All strobe inputs are compatible with standard reverse polarity supervision of circuit wiring by an alarm panel Attractive package styles for flush or surface mounting to low cost backboxes ET 1010 models UL Listed for outdoor use with Wheelock WBB backbox ET 1080 X ULC D speakers are listed for indoor outdoor use with a range of 40 to 66 40 to 150 and maximum of 98 R Approvals include CAN ULC S541 ET 1080 X ULC D uses a dedicated surface mount back box part for red devices and OSB W for white Vandal resistant die cast grilles Sealed back speaker construction for extra protection and audibility wring Fast installation with IN OUT screw terminals using 12 to 18 Compliance with RFI limits in FCC Part 15 Class for with sensitive detection and communication circuits Audio inputs include a 10 uF blocking capacitor for compatibility DC supervision of Speaker Notification Appliance Circuits read these specifications and associated installation instruc before using specifying or installing this product Visit Eaton com for current installation instructions 1 ET 1010 Speaker Front Side Views 2 ET80 Speaker Strobe Front Side Views ET80 and ET 1010EATON www eaton comfirealarmresources com Data TD450030EN January 2022 Notes Strobes are designed to flash at 1 flash per second minimum over Voltage Range Note that NFPA 72 specifies a rate of 1 to 2 flashes per second and ADA Guidelines specify flash rate of 1 to 3 flashes per second A 10 uF blocking capacitor for DC supervision of speaker NAC by the Voice System is factory wired in series with the speaker input dBA is rated per UL Standard 1480 All candela ratings represent minimum effective Strobe intensity dBA at 10 Feet ET 1080 and ET80 24MCW on UL Standard 1971 Voltage Range is the newest terminology used by to identify the voltage range Prior to this change UL used the Voltage Range dBA at 10 feet ET 1010 dBA dBA UL model only ULC model not listed for use with 1 8 watt tap setting Maxb current UL models 135cd VDC UL max current rating is the maximum RMS current within the listed voltage 16 33v for 24v units For strobes the UL max current is usually at the mini listed voltage 16v for 24v units For audibles the max current is usually at maximum listed voltage 33v for 24v units For unfiltered FWR ratings see instructions and ordering information number Mounting Refer to data sheet TD450028EN for mounting options approvals FM BFP ULC MEA ET80 and ET 1010EATON www eaton comfirealarmresources com Data TD450030EN January 2022 and engineers specifications speaker appliances shall be Wheelock ET 1010 ET 1080 or ET80 resistant speakers and speaker strobes or equivalent The shall be UL Listed under Standard 1480 for Fire Protective and speakers equipped with strobes shall be listed under UL 1971 for Signaling Devices for the Hearing Impaired ET 1010 shall be Listed for outdoor use under UL Standard 1480 All shall include both 25 and 70 volt VRMS inputs with field power taps from 1 8 to 8 watts with listed sound output to 96 dB for speakers or speaker strobes Strobes shall be listed 16 33 VDC input using filtered power or unfiltered power All shall have provisions for standard NAC supervision and IN field wiring using terminals that accept 12 to 18 AWG wiring strobes versions shall incorporate circuitry for synchronized flash and shall be designed for compatibility with Wheelock Sync Modules and Wheelock power supplies UL Standard 1971 Listed strobe appliances shall be verified to FCC Part 15 Class Strobe activation shall be via indepen input from the speaker notification appliance circuit combination speaker strobe appliances may be installed indoors surface or flush mounted They shall mount to standard electrical requiring no additional trimplate or adapter All appliances be vandal resistant die cast metal finished in a textured red or color speaker strobe appliances shall incorporate a Xenon enclosed in a rugged Lexan lens or equivalent with solid circuitry Strobes shall meet UL Standard 1971 and produce a rate of one 1 flash per second minimum over the listed input 16VDC 33VDC range Multi candela strobe intensity shall be per UL Standard
