Branchport Avenue Branch NJ 07740 631 2148 Thank you for using our products INSTRUCTIONS AUDIBLE STROBE AND SPEAKER STROBE APPLIANCE ENCLOSURE this product according to this instruction manual Please keep this instruction manual for future reference Audible Strobe and Speaker Strobe Appliance Enclosure Model EWR is designed to be used with Wheelock Series Notification Strobe Appliance Series AS Audible Strobe Appliance and Series E or ET Speaker Strobes The EWR enclosure is listed for a temperature range from 0 C 32 F to 49 C 120 F See Tables 1 and 2 for UL listed candela cd and sound level dBA ratings of Series NS AS E and ET Strobes when using the EWR Enclosure All CAUTIONS and WARNINGS are identified by the symbol All warnings are printed in bold capital letters PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT FAILURE COMPLY WITH ANY OF THE FOLLOWING INSTRUCTIONS CAUTIONS AND WARNINGS COULD RESULT IN APPLICATION INSTALLATION AND OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU OTHERS DO NOT USE THE EWR ENCLOSURE IN INSTALLATIONS WHERE TEMPERATURES MAY FALL OF THE UL LISTED TEMPERATURE 0 C 32 F TO 49 C 120 F RANGE AS DAMAGE TO OR OF NOTIFICATION APPLIANCE MAY RESULT SERIES NS AND AS SET ON CODE 3 TONE WITH MED OR LOW dBA DO NOT MEET THE 75 dBA UL REVERBERANT SOUND LEVEL REQUIRED FOR PUBLIC MODE FIRE PROTECTION SERVICE BY IN TABLE 1 MODELS WITH SETTINGS WHICH PRODUCE LESS THAN 75 dBA MAY NOT BE THIS SETTING IS ACCEPTABLE ONLY FOR GENERAL SIGNALING NON FIRE ALARM USE USE THE dBA SETTING WITH THIS TONE FOR PUBLIC MODE SERVICE DO NOT SET THE MULTI CANDELA STROBE APPLIANCE ON THE 15cd SELECTION THE LIGHT OUTPUT RATING FOR THE 15cd SELECTION WILL NOT MEET THE MINIMUM OF NFPA 72 USE SETTINGS OF 30cd OR HIGHER 1 UL Candela and Sound Pressure Ratings for the Series NS Notification Strobe and Series AS Audible Strobe when using EWR Series Number EWR Number Horn 3 Horn at 24VDC to Series NS NS4 24MCW P83983 P83984 Series AS 24MCW P83947 and AS 24MCC P84395 Installation for additional information Refer to Series NS P83518 and Series AS P83509 P83609 Installation Instructions for additional information 2003 Wheelock Inc All rights reserved E 1 of 4 Series at 10 Feet Number EWR Refer to Series E70 90 24MCW P83934 ET70 90 24MCW P83933 E90 24MCC P84398 and ET90 24MCC P84396 Instructions for additional information Refer to Series E P83566 and ET P83567 Installation Instructions for additional information Number Strobe 24100C INFORMATION Centerline Threaded mounting bosses Mounting tabs the 4 external mounting tabs into enclosure slots as Using enclosure assembly as template place against surface with centerline 80 inches above floormark drill 4 1 4 inch diameter holes 1 inch deep 10 12 x 1 inch plastic anchors 10 x 1 1inch screws retaining clips 8 32 x 3 8 inch socket head screws Drain screen Neoprene gasket Cover clear solid AFTER ALL INSTALLATION PROCEDURES HAVE COMPLETED INSTALL GASKET IN ENCLOSURE NOW PLACE COVER GROOVE AND THE FOUR 4 CLIPS IN THE SLOT CLOSEST EDGE OF COVER TIGHTEN THE FOUR 4 8 32 SCREWS USING A 3 32 ALLEN WRENCH E 2 of 4 IN SQUARE FLUSH BACKBOX MOUNTING INSTRUCTIONS INSTALATION ENTRY HOLE BE FIELD DRILLED DRILL A PILOT HOLE MAXIMUM 1 2 VIEW Figure A is typical of a in Rain tight conduit hub with neoprene o ring threaded rigid conduit and imc O Z GEDNEY CHM 75 or equivalent Figure B is typical of a in female adapter Carlton E942 or equivalent Figure C is typical of a in 1 2 in reduce bushing Appleton RB series or Figure D is typical of a galvanized in conduit nipple Figure E is typical of a in conduit lock nut Figure F is typical of a 4 in X 2 in Deep Square Backbox 9RACO190 or FOR AREAS WITH WASHDOWNS OFF BLOCKS 4 MOUNTING 4 INSTRUCTIONS FOR AND COVER Rinse with water to remove abrasive and dirt Wash with soap or mild detergent using soft cloth do not scrub Rinse once more than dry with a soft Rinse with water to remove abrasive or chamois and dirt Wash with soap or mild detergent using soft cloth do not scrub Rinse once more than dry with a soft or chamois remove grease or wet paint rub gently a cloth wetted thoroughly with naptha wash and rinse DO NOT USE BLADES FAILURE TO FOLLOW THE INSTALLATION INSTRUCTIONS OR TO SUBSTITUTE ELECTRICAL CONDUIT FITTINGS THAT DO NO COMPLY WITH CURRENT PRACTICES ADAPTED BY NEC NFPA AND CODES MAY RESULT IN LOSS OF PROTECTION FROM WATER OR DUST IN ALL AREAS WHERE FREQUENT WASH DOWNS OCCUR STAND OFF BLOCK MUST BE MATERIAL EXTRAPOLATED FROM THIS DOCUMENT OR FROM WHEELOCK MANUALS OR OTHER DESCRIBING THE PRODUCT FOR USE IN PROMOTIONAL OR ADVERTISING CLAIMS OR FOR OTHER USE INCLUDING DESCRIPTION OF THE PRODUCT APPLICATION OPERATION INSTALLATION TESTING IS USED AT THE SOLE RISK OF THE USER AND WHEELOCK WILL NOT HAVE ANY LIABILITY SUCH USE E 3 of 4 Warranty products must be used within their published specifications and must be PROPERLY specified applied installed operated and operationally tested in accordance with these instructions at the time of installation and at least twice a year or more and in accordance with local state and federal codes regulations and laws Specification application installation operation and testing must be performed by qualified personnel for proper operation in accordance with all of the latest National Protection Association NFPA Underwriters Laboratories UL Underwriters Labo
