Wheelock Exceder LED3 high fidelity speakers wall data sheet

Technical Data TD450120EN LSPST3 LED3 High Fidelity Speaker Speakers Wheelock Exceder LED3 speaker strobes and speakers by feature high fidelity sound output and an advanced power LED technology for indoor wall mount applications With the frequency response range 300 to 8000 Hz in the industry series LSPK and LSPST3 feature leading intelligibility with crisp voice messages and tone signaling ideal for emergency mass notification voice evacuation and fire alarm and Compatible Exceder LED3 strobes meet the 20 millisecond light pulse requirements of the 2016 edition of NFPA 72 By meeting latest requirement xenon and LED devices can now be in the field of view With the Exceder LED3 line Eaton now offers full range of products with low and high candela settings ideal for retrofits and new construction Efficiency LED Technology high energy efficient technology leads the industry in lowest draw for the most popular candela settings which reduces power consumption and costs in fire alarm and emergency systems As the first notification appliances in the to utilize LED as the light source this breakthrough and optical design resulting in best in class efficiency enables and system cost savings allowing for a greater number appliances on the notification appliance circuit and fewer power Speaker strobe models feature a wide range of candela 15 30 75 110 cd on a single appliance Profile Design and Feature Set the industry smallest footprint the Exceder LED3 product line aesthetically pleasing to building owners as the low profile design not detract from the interior decor Installers will benefit from comprehensive feature list including low current draw dual 25 70 VRMS capability field selectable taps from 1 8 to watts and no tools needed for setting changes The low profile incorporates a speaker mounting plate for faster and easier Each model has a built in level adjustment feature and snap on grille cover All inputs employ IN OUT wiring terminals for installation using 12 to 18 AWG wiring and Synchronization Exceder LED3 High Fidelity speaker strobes and speakers appliances are UL Listed for indoor use under Standard Signaling Devices for the Hearing Impaired and Standard Speaker Appliances and ULC listed under CAN ULC S526 Signal Appliances Fire Alarm and under CAN ULC S541 Fire Alarm The appliances are Restriction of Hazardous RoHS compliant and contain no mercury or other substances addition the Wheelock Exceder LED3 product line has been UL listed as compatible with all Fire Alarm Control Panels FACP accessories that have been determined to be compatible with RSS strobe based products including the RSS CH E ET ST HS MT S8 SA STH and Z Series The listing also the ability to install the Exceder LED3 strobes in the same zone and field of view with any Wheelock RSS strobe July 2017firealarmresources com Data TD450120EN July 2016 High Fidelity Sound Output of 300 to 8000 Hz Energy Efficient runs Low Profile Design Select 15 30 75 110 cd Field Selectable Taps 1 8 watt up to 2 watts 25 or 70 VRMS operation Easy to Install High intelligibility at minimum wattage across a frequency Patented LED technology provides industry lowest current Fewer power supplies required smaller wire gage reduced Smallest footprint with sleek modern aesthetics Special Lettering Available 4 Field Selectable Settings in 1 Device Finger slide switches No tools needed for changes Built in level adjustment feature and snap on grille cover screw terminals using 12 to 18 wires Mounting Options include Exceder LSPKBB and 4 square 2 1 8 backboxes Strobe Synchronization Components Meet synchronizing standards with Wheelock DSM Sync PS Power Supplies or SAFEPATH products Ability to mix xenon and LED strobes in the same field of view Compliance NFPA 72 2016 20 ms flash duration requirements UL 1971 UL 1480 ULC S526 ULC S541 California State Fire Marshal CSFM Low frequency requirements of UL 464 520 Hz to meet 520 Hz tone requirements for sleeping areas ADA NFPA ANSI OSHA read these specifications and associated installation instruc before using specifying or installing this product Visit Eaton com for current installation instructions Notes Strobes are designed to flash at 1 flash per second minimum over Voltage Range Note that NFPA 72 specifies a rate of 1 to 2 flashes per second and ADA Guidelines specify flash rate of 1 to 3 flashes per second All candela ratings represent minimum effective Strobe intensity on UL 1971 LED3 High Fidelity Speaker Strobes Speakers 1 Wall Sptaktr SorNbt 2 Wall Sptaktr 1 Maximum RMS Currtno LED3 High Fidelity Series Strobes Max Current a Voltage VDC RMS current ratings are per UL maximum RMS method UL max current rating the maximum RMS current within the listed voltage range 16 33v for 24v For strobes the UL max current is usually at the minimum listed voltage for 24v units For audibles the max current is usually at the maximum voltage 33v for 24v units For unfiltered FWR ratings see installation www eaton comfirealarmresources com LED3 High Fidelity Speaker Strobes Speakers 2 UL ULC Lisotd MNdtls and Raoings Data TD450120EN July 2017 Speaker Speaker Strobe Reverberant dBA at 10 Feet watts watts watts watts watts dBA per CAN ULC S541 07 watts watts watts watts watts 3 SptcificaoiNn Ordtring InfNrmaoiNn Code Candela w DSM or Power Supplies Strobes 4 SptcificaoiNns Temperature Wire Connections indoor only Connections General voltage Output Rating Flash Rate Models Range Lettering Lettering Lettering Lettering or white textured UV stabilized colored impregnated engineered plastic Exceeds 94V 0 UL flammability rating Strobe 1.54 lbs 700g Speaker Backbox 44 lb 200g Emitting Diode LED in a rugged Lexan lens 6.1 x 4.56 W x 1.29 D LSPST 6.1 x 4.56 W x 1.4 D 32 to 122 0 to 50 and maximum humidity of 93 Strobes are for wall mount applications only Speakers can be used for wall or ceiling mount applications LSPKBB backboxes or to 4 square 2 1 8 deep backboxes through 18 AWG VRMS 1971 ULC S526 Selectable 15 30 75 110 candela output are designed to flash at 1 flash per second can be synchronized with Wheelock DSM Sync Modules PS Power Supplies or SAFEPATH products using patented sync protocol Hz to 8000 Hz www eaton comfirealarmresources com Data TD450120EN July 2017 and Engineers Specifications LED high fidelity speaker appliances shall be Wheelock LED3 series LSPK Speaker and LSPST3 Speaker for wall mount applications with a low profile design or equals The speakers shall be UL Listed under UL 1480 Fire Protective Service and speakers equipped with str
