Wheelock Exceder LED3 horns, horn strobes, strobes, ceiling install sheet P85582

File Preview
File Preview
Click below to download for free

Text Preview

INSTALLATION INSTRUCTIONS EXCEDER LED3 CEILING MOUNT HORN HORN AND STROBES CLEAR AND AMBER LENS this product according to this instruction manual Please keep this instruction manual for future reference Wheelock Exceder LED3 LHNC3 horn LSTC3 strobe and LHSC3 horn strobe appliances are designed for easy installation All are for 24V operation The LHNC3 horn is also for 12V operation LSTC3 and LHSC3 are designed for ceiling mounting only may be mounted on the wall or ceiling Please read these instructions carefully before using this product Failure to comply with any of the following in cautions and warnings could result in improper application candela setting installation and or operation of these in an emergency situation which could result in property damage and serious injury or death to you and or others Wheelock Exceder LED3 Series meets NFPA 2016 20 millisecond light pulse duration code requirements In addition the Exceder LED3 product line has been UL ULC listed as compatible with all Fire Alarm Control Panels FACP and acces that have been determined to be compatible with Wheelock model RSS Strobe based products including the RSS CH E EH SA STH and Z Series The maximum number of LED3 devices per NAC is determined by dividing the maximum rating of the FACP NAC divided by the total appropriate current rating for the selected candela output of the LED3 devices with maximum of 105 LED3 devices per NAC Refer to FACP installation instructions for more detail The Wheelock Exceder LED3 strobes may be installed in the same notification zone and field of view with any RSS Strobe based product Characteristics Patterns Sound Output Power 1 Specifications LHSC3 UL 1971 ULC S526 16 LSTC3 A UL1638 ULC S526 16 UL 464 ULC S525 16 Use Only 0 C 49 C 32 F 120 F 93 R H line resistance 35 Code 3 field selectable 3 synchronized when using Cooper Wheelock sync protocol HI Low LO field selectable or FWR 24V Regulated 16 to 33V All models or FWR 12V Regulated 8 to 17.5V LHNC3 only Candela 30 75 95cd field selectable is an on axis rating where the following applies effective candela rating per UL1971 Amber strobes are not to be used as a visual public mode alarm notification appliance Exceder LED3 Strobes can provide a non synchronized strobe appliance when connected directly to a Fire Alarm Control FACP or provide a synchronized strobe appliance when used in conjunction with an FACP that incorporates the Cooper sync protocol a Dual Sync Module DSM or the Wheelock Power Supply The Code 3 temporal pattern 1 2 second on 1 2 second off 1 2 second on 1 2 second off 1 2 second on 1 1 2 off and is specified by ANSI and NFPA 72 for standard emergency evacuation signaling 2A LHNC3 and LHSC3 Sound Output dBA Per UL 464 3 at 12V and LHSC3 at 24V 2B LHNC3 and LHSC3 dBA Sound Output Per CAN ULC S525 16 at 12V and LHSC3 at 24V 3 2C ULC Directional Characteristics 35 Degrees horizontal 45 30 vertical 90 Degrees horizontal 90 vertical calculating the total currents use Tables 3 5 to determine the highest value of RMS current for an individual appliance then these values by the total number of appliances Be sure to add the currents for any other appliances including audible signal appliances powered by the same source and to include any required safety factors 3 LSTC3 and LSTC3 A Current Draw Amps 33.0 Volts Candela Settings cd 4 LHSC3 Horn Strobe Current Draw Amps Volts Candela Settings cd Continuous Code 3 Continuous Code 3 Continuous Code 3 Continuous Code 3 Branchport Ave Long Branch N J 07740 800 631 2148 www coopernotification comPN P85582BCopyright 2017 Cooper Wheelock Inc dba Cooper Notificationfirealarmresources com 5 LHNC3 Horn Current Draw Amps Volts Volts Settings Continuous Code 3 Continuous 3 Continuous Code 3 Continuous Code 3 Candela and Horn Setting will determine the current draw of the product These notification appliances are UL Listed as They are intended to be used with Fire Alarm Control Panels FACPs notification circuits are UL Listed as Refer to the FACP instructions or the Cooper Wheelock Strobe Compatibility Data PN P85328 for special application and strobe synchronization compatibility These appliances were tested to the regulated voltage limits of 16.0 33.0 Volts for 24 volt models and 8.0 17.5 Volts for 12 volt models filtered dc for the 12 volt range and either filtered dc or unfiltered dc for the 24 volt range voltage Do not apply voltage outside of this Check the minimum and maximum output of the power supply and standby battery and subtract the voltage drop from the circuit resistance to determine the applied voltage to the strobes The maximum wire impedance between strobes shall not exceed 35 Strobes are not designed to be used on coded systems in which the applied voltage is cycled on and off Make sure that the total rms current required by all appliances that are connected to the system primary and secondary power Notification Appliance Circuit NAC DSM sync module or Wheelock power supplies does not exceed the power sources rated or the current ratings of any fuses on the circuits to which these appliances are wired Overloading power sources or exceeding ratings could result in loss of power and failure to alert occupants during an emergency which could result in property damage and injury or death to you and or others AND MOUNTING BASE All strobe appliances have in out wiring terminals that accept two 12 to 18 American Wire Gauge AWG wires at each screw termi Strip leads 3 8 inches and connect to screw terminals Break all in out wire runs on supervised circuits to ensure integrity of circuit supervision as shown in Figure 2 The polarity shown in wiring diagrams is for the operation of the appliances The polarity is reversed by the FACP during supervision 2 Wire Connection Figure 1 LED Strobe Wiring Wiring method shall be in accordance with CSA C22.1 Canadian Electrical Code Part 1 Safety Standard for Electrical Section 32 Do not fully back out terminal screws AND MOUNTING SETTINGS The LHSC3 and LHNC3 are factory set for the most common application of High dB and Code 3 The LHSC3 and LSTC3 are fac set to 15 candela Candela factory settings are shown in Figure 4 Output Horizontal and Vertical Values 3 LHSC3 LSTC3 LSTC3 A Expected Light Output Figure 4 Horn Strobe Candela Selector Check that the installed product will have sufficient clearance and wiring room prior to installing backboxes and conduit espe if sheathed multiconductor cable or 3 4 inch conduit fittings are used the limits shown for the mounting option comply with the National Electrical Code NEC Cooper Wheelock recommends use of largest backbox option available and the use of approved stranded field wires whenever possible to provide additional wiring room for installation and minimum stress on the product from wiring Do not over tighten mounting screws Excessive torque can distort the base and may affect operation When using power tools to screw down the mounting plate to the electrical backbox ensure the torque is set to the lowest available OPTIONS Connect field wiring to c
