Wheelock Exceder LED3 speaker wall install sheet P85350-002

INSTALLATION INSTRUCTIONS LED WALL MOUNT HIGH FIDELITY AND SPEAKER STROBES AND CLEAR LENS this product according to this instruction manual Please keep this instruction manual for future reference Wheelock Exceder LED LSPST Series High Fidelity Multi Candela Speaker Strobes are UL Listed under Standard 1971 for Signaling for the Hearing Impaired UL Standard 1480 for Speaker Appliances and ULC Listed under Standard CAN ULC S541 07 and CAN for indoor Fire Protective Service The Speaker Strobes with Amber lens are UL Listed under Standard 1638 Visual Signalling for Private Mode Emergency General Utility Signaling and ULC S526 07 Amber lens strobe appliances also comply with the polar requirements in the UL Standard 1971 for Indoor Fire Protection Service and NFPA 72 for Mass Notification Systems Wheelock Exceder LED LSPST Series High Fidelity Multi Candela Speaker Strobes are designed for multiple power requirements with dBA output at each power tap Series LSPK High Fidelity Speakers are UL Listed under UL Standard 1480 and ULC Listed under CAN ULC S541 07 for Speaker Appliances All models offer a choice of field selectable taps 1 8W to 2W for either 25.0 VRMS or VRMS audio systems LSPST LSPK series speakers are UL rated to meet the NFPA 72 requirement for 520Hz signals in sleeping areas used in conjunction with Wheelock Safepath products see SP40S manual for more details design incorporates a high efficiency speaker for maximum output at minimum power across a frequency range of 300 8000Hz The Strobes can provide non synchronized strobe operation when connected directly to a Fire Alarm Control Panel FACP or provide strobe operation when used in conjunction with a Dual Sync Module DSM or Wheelock Power Supplies All models are for indoor use only with the backboxes specified in these instructions see Mounting Options All Canadian Installations should be in accordance with the Canadian Standard for the Installation of Fire Alarm Systems CAN and Canadian Electrical Code Part 1 Final acceptance is subject to Authorities Having Jurisdiction This appliance is a ALARM DEVICE DO NOT PAINT Please read these instructions carefully Failure to comply with any of the following instructions cautions and warn could result in improper application installation and or operation of these products in an emergency situation which could in property damage and serious injury or death to you and or others 1 UL ULC Listed Models and Ratings Strobes will produce 1 flash per second over the Voltage range All models are Listed for indoor use with a temperature range of 32 to 120 0 to 49 and maximum humidity of 93 RH effect of shipping and storage temperatures shall not adversely affect the performance of the appliance when it is stored in the cartons and is not subjected to misuse or abuse dBA is rated per UL Standard 1480 and ULC Standard ULC S541 07 for Speaker Appliances Frequency range of speakers is 300 These appliances were tested to the operating voltage limits of 16 33 volts using Filtered DC or unfiltered Full Wave Rectified FWR not apply 80 and 110 of these voltage values for system operation Check the minimum and maximum output of the power supply and standby battery and subtract the voltage drop from the circuit resistance to determine the applied voltage to the strobes 2 Current Ratings for Strobe Only RMS Current AMPS Range Voltage Candela setting will determine the current draw of the product 3 ULC Directional Characteristics 75 degrees horizontal 70 degrees vertical 90 degrees horizontal 90 degrees vertical The maximum wire impedance between strobes shall not exceed 35 OHMS Speaker Strobes are not designed to be used on coded systems in which the applied voltage is cycled on and off Make sure that the total RMS current required by all appliances that are connected to the system primary and secondary power NAC Circuits DSM Sync Modules or Cooper Wheelock Power Supplies do not exceed the power sources rated capacity or the ratings of any fuses on the circuits to which these appliances are wired Overloading power sources or exceeding fuse ratings could result in loss of power and failure to alert occupants dur an emergency calculating the total currents use Table 2 to determine the highest value of Current for an individual strobe across the operating voltage range of the strobe then multiply these values by the total number of strobes be sure to add the currents for other appliances including audible signaling appliances powered by the same source and include any required safety factors the peak current exceeds the power supplies peak capacity the output voltage provided by the power supplies may drop below the voltage range of the appliances connected to the supply and the voltage may not recover in some types of power supplies For ex an auxiliary power supply that lacks filtering at its output stage either via lack of capacitance and or lack of battery backup across output may exhibit this characteristic INFORMATION 1.5 blocking capacitor for DC supervision of audio lines by the FACP is factory wired in series with the speaker input Supervision must not exceed 33 volts DC LSPST Speaker Strobe models have in out wiring terminals that accept two 12 to 18 American Wire Gauge AWG wires at each terminal Strip leads 3 8 inches and connect to screw terminals Break all in out wire runs on supervised circuits to assure integrity of circuit supervision as shown in Figure 2 The polarity shown in wiring diagrams is for operation of the appliances Connect speaker wires to common and positive of terminal block and select the power tap terminal for 1 8W 1 4W 1 2W 1W or 2W or 70V as required see Figures 1 2 3,4 and Table 4 Each doubling of rated Watts increases sound output by 3 dBA Using the slide switch shown in Figure 3 select voltage and wattage as shown in Table 4 below Each letter corresponds to a position of the The following figures show the maximum number of field wires conductors that can enter the backbox used with each mounting option If limits are exceeded there may be insufficient space in the backbox to accommodate the field wires and stresses from the wires could damage the 1 Strobe Wiring 2 Wire Connection signaling appliance to backbox using mounting screws provided Check electrical ratings specified in Tables 1 and 2 as appropriate to ensure proper electrical input Ensure the speaker wiring is to speaker terminals only and strobe wiring is connected to strobe terminals only Ensure the wiring at the FACP is correct Wiring method shall be in accordance with CSA C22.1 Canadian Electrical Code Part 1 Safety Standard for Electrical Installa Section 32 Improper electrical input can damage the product or cause it to malfunction The speaker strobe appliances must be set to the desired dBA sound output level before they are installed This is done by setting the slide switch in accordance with these instructions Incorrect settings will result in improper performance Factory setting is F 70V 1 2 W at 10 Feet Rated Watts Per UL 1480 dBA CAN ULC S541 07 located on the printed circuit board to Sync Module instruction sheets DSM P83177 or Wheelock Power Supplies for additional information Branchport Ave Long Branch N J 07740 800 631 2148 www coopernotification comPN P85350 002BCopyright 2015 Cooper Wheelock Inc dba Cooper Notificationfirealarmresources com Slide the Switch Indicator selection switch to the desired tap setting The LSPST comes pre set at 15cd The candela select switch must be field set to the required candela intensity before installation When changing the setting of candela select switch make certain that it clicks in place After changing the candela setting the appliance must be retested to verify operation Improper setting of the candela select switch may result in operation at the wrong candela 3 Speaker Selector Switch Setting Figure 4 Strobe Candels indicator the signaling appliance 4 Speaker Voltage and Wattage Connection
