Wheelock HS horns and horn strobes data sheet

Technical Data TD450154EN HS Horns and Horn Wheelock HS horn and horn strobe appliances are ideal choices retrofit applications as well as new installations The HS HS4 virtually all requirements for indoor wall and ceiling mount HS horns include a selectable continuous horn tone or temporal Code 3 with three selectable dBA settings for each tone options include the Wheelock patented MCW Multi Candela with field selectable candela settings of 15 30 75 110cd or for wall mount and 15 30 75 95cd or 115 177cd for ceiling HS4 horn and strobe inputs are electrically isolated to allow for operation of the strobe circuit and the horn circuit The and strobe may also be wired in parallel to operate on a single versatile horn and horn strobe appliances may be synchronized Wheelock DSM Sync Modules Wheelock Power Supplies or manufacturers panels incorporating the Wheelock Patented Protocol models are designed for maximum performance reliability cost effectiveness while meeting or exceeding the latest of NFPA 72 ANSI 117.1 UFC and UL Standards 1971 and as well as meeting ADA requirements concerning photosensitive February 2019 firealarmresources com Data TD450154EN February 2019 Approvals include UL Standard 1971 UL Standard 464 ULC S525 ULC California State Fire Marshal CSFM and Factory Mutual FM See by model in Specifications and Ordering Information ADA NFPA UFC ANSI compliant Complies with OSHA 29 Part 1910.165 Field Selectable Candela Settings Wall Mount 15 30 75 110cd or Multi Candela models and Ceiling Mount 15 30 75 95cd 115 177cd Selectable Continuous Horn or Temporal Code 3 T3 3 Selectable dBA settings of 90 95 99 dBA 4 Wire Horn Strobe Appliance allows for separate operation of the horn strobe circuit 24 VDC models with 16 to 33 VDC UL Voltage using filtered or unfiltered VRMS input voltage Mounts flush to standard 4 inch square or double gang boxes or surface to IOB backbox Synchronize using the Wheelock Sync Modules or panels with sync protocol Wheelock Patented Sync Protocol Fast installation with IN OUT screw terminals using 12 to 18 AWG wires read these specifications and associated installation instruc before using specifying or installing this product Visit Eaton com for current installation instructions 1 HS4 Horn Strobe Front Side Views 2 HS Horn Front Side Views Notes Strobes are designed to flash at 1 flash per second minimum over their Voltage Range Note that NFPA 72 specifies a flash rate of 1 2 flashes per second All candela ratings represent minimum effective Strobe intensity based UL 1971 HS Horn and Horn StrobesEATON www eaton comfirealarmresources com Data TD450154EN February 2019 1 Maximum RMS Current Voltage VDC Max Current a VDC 2 dBA Ratings Current for Horn Current Horn 3 Horn dBA at per UL 464 VDC dBA 10ft VDC VDC Max dBA dBA dBA 4 Specifications Temperature Connections General voltage Output Rating Flash Rate Models or white textured UV stabilized colored impregnated engineered plastic Exceeds 94V 0 UL flammability Strobe 0.66 lbs 03 kg Lexan 943A Horn 5.13 W x 5.13 H x 3.15 HS strobe 5.13 W x 5.13 H x 5.24 33.8 to 120.2 0 to 49 and maximum humidity of 93 through 18 AWG 33V DC or FWR 1971 are designed to flash at 1 flash per second can be synchronized with Wheelock DSM Sync Modules Power Supplies or SAFEPATH products Wheelock patented sync protocol RMS current ratings are per UL maximum RMS method UL max current rating is the maximum RMS current within the listed voltage range 16 33v for units For strobes the UL max current is usually at the minimum listed voltage 16v for 24v units For audibles the max current is usually at the listed voltage 33v for 24v units For unfiltered FWR ratings see installation instructions HS Horn and Horn StrobesEATON www eaton comfirealarmresources com Data TD450154EN February 2019 3 Specification Ordering Information Candela 75 on Axis and Engineers Specification audible visual notification appliance shall be Wheelock Series HS4 Horn and HS Horn Appliances or approved equals The Series HS4 and HS shall meet ad be listed for UL Standard 1971 Emergency Devices the Hearing Impaired for Indoor Fire Protection Service and Standard Fire Protective Signaling The horn strobe shall be listed for indoor use shall meet the requirement of FCC Part 15 Class B All inputs shall be with standard reverse polarity supervision of circuit wiring by the Alarm Control Panel FACP HS Horn and the audible of the HS4 appliance shall have a minimum of 3 field selectable settings for dBA levels and shall have a choice of or temporal Code 3 audible outputs strobe portion of the appliance shall produce a flash rate of one 1 per second over the Regulated Voltage Range and shall incorporate a flashtube enclosed in a rugged Lexan lens The horn strobe shall of low current design Where wall mount Multi Candela appliances are the strobe intensity shall have field selectable settings and shall rated per UL Standard 1971 for 15 30 75 110cd or 135 185cd The selector for selecting the candela setting shall be tamper resistant For information on mounting options refer to specification sheet TD450028EN Options b FM 1575 candela strobe shall be specified when 15 candela UL Standard Listing with 75 candela on axis is required Where ceiling mount multi appliances are specified the strobe intensity shall have field select settings and shall be rated per UL standard 1971 for 15 30 75 95cd or synchronization is required the appliance shall be compatible with DSM Sync Modules Wheelock Power Supplies or other manu panels incorporating the Wheelock Patented Sync Protocol The shall not drift out of synchronization at any time during operation the sync module or Power Supply fails to operate i e contacts remain the strobes shall revert to a non synchronized flash rate notification appliances shall be backward compatible ULC CSFM FM to continuous development of our products specifications and offerings are subject to change without notice in accordance with Cooper Inc dba Eaton standard terms and conditions ENCOURAGE AND SUPPORT NICET CERTIFICATION YEAR WARRANTY is a registered trademark All other trademarks are property of their respective owners Wheelock HS Horns and Horn StrobesEaton1000 Eaton BoulevardCleveland OH 44122United StatesEaton comEatonLife safety mass notification solutions273 Branchport Ave Long Branch NJ 07740www eaton com massnotification 2019 EatonAll Rights ReservedPrinted in USAPublication No TD450154ENFebruary 2019firealarmresources com
