Wheelock MT horn strobe install sheet P84155

INSTALLATION INSTRUCTIONS MT 121575W MULTITONE APPLIANCES 2 this product according to this instruction manual Please keep this instruction manual for future reference Multitone Strobe Appliances are UL Listed under Standard 1971 for Signaling Devices for the Hearing Impaired and Standard 464 for Audible Signaling Devices The Multitone is also ULC Listed under Standard CAN ULC S526 16 for Visual Signaling Devices and under Standard CAN ULC S525 16 for Audible Signaling Devices for Fire Alarm Sys The 15 75cd model strobe is listed at 15 candela under UL Standard 1971 and meets 75 candela intensity on axis with low current draw Models with amber red blue or green are UL Listed under Standard UL1638 Visual Signaling Appliance for Private Mode Emergency and General Utility Signaling The MCW strobe can provide 4 selectable candela 15 30 75 110 These Strobes can provide a non synchronized strobe appliance when connected directly to a Fire Alarm Control Panel FACP or provide a synchronized appliance when used in conjunction with a Dual Sync Module DSM or Wheelock power supplies The horn portion of the MT appliance can be field set to provide a synchro code 3 horn when used in conjunction with the Dual Sync Module DSM or Wheelock power supplies These models of the MT Series are listed for indoor use only and wall only with the backboxes specified in these instructions See wiring and mounting information The Strobe uses a xenon flashtube with solid state circuitry enclosed in a lens to provide maximum visibility and reliability for effective visible signaling Multitone can be field set to produce any one of eight commonly used alarm tones Sound can be field set to provide either HIGH HI dBA or STANDARD STD dBA sound output level Multitone Strobe models are designed for use with either filtered DC or unfiltered full wave rectified FWR input voltage The Multitone Strobe Appliances have separate input for alarm tone activation and strobe activation Shunt wires are provided to operate both the alarm tone and the strobe simultaneously on a single input circuit See Wiring All inputs are polarized for compatibility with standard reverse polarity supervision of circuit wiring by a fire alarm control panel FACP THIS APPLIANCE IS A ALARM DEVICE DO NOT PAINT PLEASE READ THESE INSTRUCTIONS CAREFULLY FAILURE TO COMPLY WITH ANY OF THE FOLLOWING INSTRUCTIONS CAUTIONS AND WARNINGS RESULT IN IMPROPER APPLICATION INSTALLATION AND OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION WHICH COULD RESULT IN DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS 1 UL ULC Listed Models and Ratings Voltage Range dBA Candela 10 ft Indicates Models with A amber R red B blue or G green lens 75cd on axis only Candela ratings in Table 1 are for clear lens Derate approximately 25 for amber lens 55 for green lens 70 for blue lens and 80 for red lens 2 UL ULC Current Ratings for MT Multitone Audible Appliances Description Horn Continuous Hz Modulated 0.07 Sec ON Repeat Time Horn 0.25 Sec ON 0.25 Sec OFF Repeat 3 Horn 3 Tone Whoop ANSI S3.41 Temporal Pattern Hz ANSI S3.41 Temporal Pattern Sweep 4.0 Sec ON 0.5 Sec OFF Repeat Sweep 1.0 Sec ON Repeat Hz 0.25 Sec ON Alternate RMS Current AMPS VDC FWR VDC FWR 3 Maximum RMS Current Amps for 24V Strobe SETTING MCW ULC Voltage 4 Maximum RMS Current Amps for 12V Strobe Candela VDC VRMS ULC Voltage 8.0 17.5VDC Branchport Ave Branch N J 07740 631 2148 Time 3 Horn 3 Tone Whoop 5 dBA Ratings at 10 Ft Reverberant Ratings Per UL 464 Anechoic Ratings Per CAN ULC S525 16 24VDC 12VDC 24VDC 12VDC is intended for Private Mode Emergency Use only USA Setting is intended for Dwelling Unit Use only Canada 6 ULC Directional Characteristics 35 Degrees horizontal 35 vertical 55 Degrees horizontal 55 vertical AND SETTINGS MT has in out wiring terminals that accept two 12 to 18 American Wire AWG wires at each screw terminal Strip leads 3 8 inches Break all in out wire runs on supervised circuits to assure integrity of supervision as shown in Figure 1 1 The polarity shown in the wiring diagrams is for operation of the appli The polarity is reversed by the FACP during supervision VISUAL AUDIBLE SW1 3 Horn and Strobe Operate in Unison and black wires are supplied Use Tables 2 3 and 4 to determine the highest value of Current for an individual Multitone strobe across the expected operating voltage range of the Multitone strobe strobe current from Table 3 or 4 to audible appliance current from Table 2 to obtain total current for each unit if the strobe and audible are wired to operate in unison on a single Be sure to add the currents for any other appliances including audible signaling appliances powered by the same source and include any required safety factors 2 Showing Location of SW1 The factory settings for MT models are HIGH dBA SW1 1 set on 1 HORN TONE SW1 POS 2 3 4 set on 1 1 1 Figure 4 Horn and Strobe Operate Independantly 2019 Cooper Wheelock Inc dba Cooper Notification All rights reserved Page 1firealarmresources com HERE FOR 1 HERE FOR 0 A SMALL SCREWDRIVER TO THE SWITCH POSITION 1 2 3 4 5 Switch SW1 Settings 7 dBA Sound Output Level Settings Level dBA dBA Settings SW1 POS 1 on 1 Factory Setting SW1 POS 1 on 0 The MT must be set for Code 3 horn when used with Wheelock sync protocol Refer to sheets for DSM or Wheelock power supplies for additional information Factory Setting Time Horn 3 Horn 3 Tone Whoop 8 Switch Settings 2 3 4 Strobes are not designed to be used on coded systems in which the applied voltage is cycled on and off The following figures show the maximum number of field wires conductors that can enter the backbox used with each mounting option If these limits are there may be insufficient space in the backbox to accommodate the field wires and stresses from the wires could damage the product the limits shown for each mounting option comply with the National Electrical Code Cooper Notificati
