Wheelock RSS strobe wall install sheet P83911

File Preview
File Preview
Click below to download for free

File Data

Name wheelock-rss-strobe-wall-install-sheet-p83911-9742635108.pdf
Type PDF
Size 735.32 KB
Downloads

Text Preview

Branchport Ave Branch N J 07740 631 2148 US 397 5777 CANADA Thank you for using our products SERIES RSS AND RSSP MULTI CANDELA STROBE APPLIANCES INSTALLATION INSTRUCTIONS MOUNT VERSIONS this product according to this instruction manual Please keep this instruction manual for future reference Notification Series RSS and RSSP Multi Candela Strobes can provide a non synchronized strobe appliance when connected directly to a fire alarm control FACP or provide a synchronized strobe appliance when used in conjunction with a Sync Module SM Dual Sync Module DSM or a Cooper Notification supply utilizing the Cooper Notification sync protocol The Series RSS and RSSP Multi Candela Strobe Appliances are UL Listed under Standard 1971 Devices for the Hearing Impaired for indoor Fire Protection Service and ULC Listed under Standard CAN ULC S526 07 for indoor Fire Protective The Multi Candela Strobe provides four selectable light output intensities in one unit These strobes are listed for wall mount only with the backboxes in these instructions see mounting options RSS models have an integrated strobe mounting plate that can be mounted to a single gang double gang 4 100mm European backbox or SHBB surface backbox The strobes use a xenon flashtube with solid state circuitry enclosed in a polycarbonate lens to maximum visibility and reliability for effective visible signaling All inputs are polarized for compatibility with standard reverse polarity supervision of wiring by the Fire Alarm Control FACP All Canadian installations should be in accordance with the Canadian Standard for the Installation of Fire Alarm Systems CAN ULC S524 and Canadian Code Part 1 Final acceptance is subject to the authority having jurisdiction AHJ PLEASE READ THESE INSTRUCTIONS CAREFULLY FAILURE TO COMPLY WITH ANY OF THE FOLLOWING CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION CANDELA SETTING INSTALLATION AND OR OF THESE PRODUCTS IN AN EMERGENCY SITUATION WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS OR DEATH TO YOU AND OR OTHERS 1 UL ULC Ratings at 10 Feet Range Per UL 1971 Range Per 2 Audibles Speakers for RSSP Strobe Plate MT MT4 NH ET70 E70 Appliances Bells Strobes will produce 1 flash per second over the Regulated Voltage range These strobes meet the required light distribution patterns defined in UL 1971 and ULC S526 07 All models are listed by UL ULC for indoor use with a temperature range of 32 to 120 0 to 49 and maximum humidity of 93 2 RH The of shipping and storage temperatures shall not adversely affect the performance of the appliance when it is stored in the original cartons and is not to misuse or abuse CANDELA SETTING WILL DETERMINE THE CURRENT DRAW OF THE PRODUCT 3 Current Ratings AMPS RMS Current calculating the total currents use Table 3 to determine the highest value of RMS current for an individual strobe then multiply these values by the total number strobes Be sure to add the currents for any other appliances including audible signaling appliances powered by the same source and to include any required factors The maximum number of strobes on a single notification appliance circuit shall not exceed 50 2009 Cooper Wheelock Inc dba Cooper Notification All rights reserved Y 1 of 5 These notification appliances are UL Listed as They are intended to be used with FACPs whose notification circuits are UL Listed as These appliances shall not be used on UL Listed Application notification circuits unless the appliances are identified to be compatible in the instructions of the FACP or unless the FACP is identified to be compatible in this instruction manual THESE APPLIANCES WERE TESTED TO THE REGULATED VOLTAGE LIMITS OF 16.0 33.0 VOLTS FOR 24V MODELS USING DC OR UNFILTERED FULL WAVE RECTIFIED VOLTAGE DO NOT APPLY VOLTAGE OUTSIDE OF THIS RANGE CHECK THE MINIMUM AND MAXIMUM OUTPUT OF THE POWER SUPPLY AND STANDBY BATTERY AND SUBTRACT THE DROP FROM THE CIRCUIT WIRING RESISTANCE TO DETERMINE THE APPPLIED VOLTAGE TO THE STROBES THE WIRE IMPEDANCE BETWEEN STROBES SHALL NOT EXCEED 35 OHMS Strobes are not designed to be used on coded systems in which the applied voltage is cycled on and off MAKE SURE THAT THE TOTAL RMS CURRENT REQUIRED BY ALL APPLIANCES THAT ARE CONNECTED TO THE PRIMARY AND SECONDARY POWER SOURCES NOTIFICATION APPLICIANCE CIRCUITS SM DSM SYNC MODULES OR NOTIFICATION POWER SUPPLIES DOES NOT EXCEED THE POWER SOURCES RATED CAPACITY OR THE CURRENT RATINGS ANY FUSES ON THE CIRCUITS TO WHICH THESE APPLIANCES ARE WIRED OVERLOADING POWER SOURCES OR EXCEEDING FUSE COULD RESULT IN LOSS OF POWER AND FAILURE TO ALERT OCCUPANTS DURING AN EMERGENCY WHICH COULD RESULT PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND OR OTHERS in deg 4A UL Light Output Horizontal Plane Min 15cd Min 30cd Min 75cd 110cd 0 5 0 5 Min Min 4B UL Light Output Vertical Plane in deg Min 15cd Min 30cd Min 75cd 110cd Y 2 of 5 AND MOUNTING INFORMATION The following figures A F show the maximum number of field wires conductors that can enter the backbox used with each mounting option If limits are exceeded there may be insufficient space in the backbox to accommodate the field wires and stresses from the wires could damage the product Check that the installed product will have sufficient clearance and wiring room prior to installing backboxes and conduit especially if sheathed cable or 3 4 conduit fittings are used the limits shown for each mounting option comply with the National Electrical Code NEC Cooper Notification recommends use of the largest backbox shown and the use of approved stranded field wires whenever possible to provide additional wiring room for easy installation and minimum stress o
