Technical Data TD450040EN RSS and RSSP Strobes Strobe Plates Wheelock patented RSS Strobe appliances and RSSP Strobe by Eaton have lower current draw while maintaining performance reliability and cost effectiveness These appliances will satisfy virtually all requirements for indoor or ceiling mount applications options include the Wheelock Patented MCW multi candela with field selectable candela settings of 15 30 75 110cd or the intensity MCWH strobe with field selectable 135 185cd Ceiling models include the patented MCC multi candela ceiling strobe field selectable intensities of 15 30 75 95cd or the high intensity strobe with field selectable 115 177cd models may be synchronized using the Wheelock DSM Sync Wheelock Power Supplies or other manufacturers panels the Wheelock Patented Sync Protocol Synchronized can eliminate possible restrictions on the number of in the field of view Wheelock synchronized strobes offer easy way to comply with ADA recommendations concerning epilepsy as well as meeting the requirements of 72 Wheelock Series RSS Strobes employ a Patented Integral Mounting Plate that can be mounted to a single gang double 4 square 100mm European backboxes or the SHBB surface If the flush backbox has side or top space between it and finished wall the NATP Notification Appliance Trimplate may used It provides an additional 65 of trim for the Appliance An cover plate is provided for a clean finished appearance on models RSSP Multi Candela Strobe Plates are a cost effective way retrofit required wall strobe appliances to bells horns chimes or speakers and easily mounts to standard 4 backboxes for surface mount use with the Wheelock SBL2 surface backbox July 2016Supersedes July 2011 firealarmresources com Data TD450040EN July 2016 Approvals include UL Standard 1971 New York City MEA California State Fire Marshal CSFM Factory Mutual FM and BFP See approvals by model in Specifications and information ADA NFPA UFC ANSI compliant Meets OSHA 29 Part 1910.16 Wall mount Multi Candela models are available with Field Candela Settings of 15 30 75 110cd or 135 185cd Wall mount Multi Candela models are available with Field Candela Settings of 15 30 75 110cd or 135 185cd Strobes produce 1 flash per second over the regulated voltage 12 and 24 VDC models with wide UL Voltage using DC or unfiltered VRMS input voltage Synchronize using the Wheelock sync modules or panels with Wheelock Patented Sync Protocol Fast installation with IN OUT screw terminals using 12 to 18 wire CAUTIONS and WARNINGS are identified by the symbol are printed in bold capital letters All 1 RSS wall strobe Front Side Views WARNING READ THESE SPECIFICATIONS AND ASSOCIATED INSTALLATION CAREFULLY BEFORE USING SPECIFYING OR APPLYING PRODUCT VISIT WWW EATON COM MASSNOTIFICATION OR EATON FOR THE CURRENT INSTALLATION INSTRUCTIONS TO COMPLY WITH ANY OF THESE INSTRUCTIONS CAUTIONS OR COULD RESULT IN IMPROPER APPLICATION INSTALLATION OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR TO YOU AND OR OTHERS Notes Strobes are designed to flash at 1 flash per second minimum over Voltage Range Note that NFPA 72 specifies a rate of 1 to 2 flashes per second and ADA Guidelines specify flash rate of 1 to 3 flashes per second All candela ratings represent minimum effective Strobe intensity on UL 1971 for RSSP Series Appliances Bells MT NH HS E70 ET70 RSS and RSSP Strobes and Strobe PlatesEATON www eaton comfirealarmresources com Data TD450040EN July 2016 1 Maximum RMS Current Strobes VDC 16.0 33.0 MAX CURRENT a 24VDC 135cd 2 Specification Ordering Information Agency Approvals Strobe Candela Red White Wall Ceiling 75 on Axis 75 on Axis b Round UL MEA CSFM FM BFP 77F 77 F F 75 on Axis 3 Specifications Temperature Connections Power General voltage Output Rating Flash Rate Models or white textured UV stabilized colored impregnated engineered plastic Exceeds 94V 0 UL flammability rating Strobe 0.40 lbs 0.181 kg Lexan 943A Strobe 4.75 W x 4.75 H x 2.58 33.8 to 120.2 0 to 49 and maximum humidity of 93 through 18 AWG VRMS 1971 are designed to flash at 1 flash per second can be synchronized with Wheelock DSM Sync Modules Power Supplies or SAFEPATH products using patented sync protocol RMS current ratings are per UL maximum RMS method UL max current rating is the maximum RMS current within the listed voltage range 16 33v for 24v units For the UL max current is usually at the minimum listed voltage 16v for 24v units For audibles the max current is usually at the maximum listed voltage 33v for units For unfiltered FWR ratings see installation instructions For information on mounting options refer to specification sheet TD450028EN RSS and RSSP Strobes and Strobe PlatesEATON www eaton comfirealarmresources com Data TD450040EN July 2016 and Engineers Specifications visual notification appliances shall be Wheelock RSS Strobe or approved equals The Series RSS shall meet and be for UL Standard 1971 Emergency Devices for the Hearing for Indoor Fire Protection Service The strobe shall be listed indoor use and shall meet the requirements of FCC Part 15 Class The strobe appliances shall produce a flash rate of one 1 flash second over the Regulated Voltage Range and shall incorporate a flashtube enclosed in a rugged Lexan lens All inputs shall be with standard reverse polarity supervision of circuit wiring a Fire Alarm Control Panel FACP When Strobe Plates are to be they shall be the Wheelock Series RSSP Strobe Plate and have the same electronic circuitry as the Wheelock Series RSS RSS Strobe shall be of low current design Where Multi appliances are specified the strobe intensity shall have selectable settings and shall be rated per UL Standard 1971 at or 135 185cd for wall mount and 15 30 75 95cd or for ceiling mount The selector switch for selecting the shall be tamper resistant synchronization is required the appliance shall be compatible Wheelock DSM Sync Modules Wheelock Power Supplies or manufacturers panels with built in Wheelock Patented Sync The strobes shall not drift
