Wheelock s8 ceiling speakers and strobe data sheet

Technical Data TD450020EN S 8 Ceiling Speakers Strobes Wheelock S product line includes Speakers and Speaker Strobes designed for high efficiency sound output with dual voltage VRMS capability and field selectable taps from 1 8 to 8 watts Wheelock S Speaker Strobe models incorporate the Low Current RSS Strobes Strobe options for ceiling mount models include patented MCC multi candela ceiling strobe with field intensities of 15 30 75 95cd or the high intensity MCCH with field selectable 115 177cd S 8 Speakers and Speaker Strobes provide high audio output clear audibility and are designed to meet the critical needs of the safety industry for effective emergency voice communications signaling and visible signaling to alert the hearing impaired strobe portion of all Series S Speaker Strobes may be when used in conjunction with the Wheelock DSM Modules or Wheelock Power Supplies with Patented Sync Wheelock synchronized strobes offer an easy way to with ADA recommendations concerning photosensitive Wheelock S Speaker Strobes are UL Listed for indoor use under 1971 Signaling Devices for the Hearing Impaired and 1480 Speaker Appliances and use a Xenon flashtube with state circuitry enclosed in a rugged Lexan lens to provide reliability for effective visual signaling All inputs are and employ IN OUT wiring terminals for fast installation 12 to 18 AWG wiring S 8 Ceiling Speakers and Speaker Strobes are available in three Dual Voltage multi tap speaker S8 24MCC Speaker strobe with field selectable settings of S8 24MCCH Speaker strobe with field selectable candela of 115 117cd January 2016Supersedes January 2015 firealarmresources com Data TD450020EN January 2016 Frequency High efficient design for high minimum output wattage 200 Hz 15 kHz 400 HZ 4 kHz UL 6 Field Selectable Settings Ceiling mount models are available with field selectable candela of 15 30 75 95cd or 115 177cd Multi candela models Field Selectable Taps 1 8 watt to 8 watts 25 or 70 VRMS operation Quick installation with IN OUT screw terminals using 12 to 18 wires Speaker impedance 8 ohms Round metal 12 grille with white power coated finish Compatible with DC circuit supervision 24 VDC with wide UL Voltage using filtered DC or VRMS input voltage Strobe Synchronization Components Meet synchronizing standards with Wheelock DSM Sync PS Power Supplies or SAFEPATH products Compliance UL 1971 UL 1480 ULC S526 ULC S541 Low frequency requirements of UL 464 520 Hz to meet 520 Hz tone requirements for sleeping areas California State Fire Marshal CSFM ADA NFPA ANSI OSHA FCC Part 15 ICE Note All CAUTIONS and WARNINGS are identified by the All warnings are printed in bold capital letters WARNING READ THESE SPECIFICATIONS AND ASSOCIATED INSTALLATION CAREFULLY BEFORE USING SPECIFYING OR APPLYING PRODUCT VISIT WWW EATON COM MASSNOTIFICATION OR EATON FOR THE CURRENT INSTALLATION INSTRUCTIONS TO COMPLY WITH ANY OF THESE INSTRUCTIONS CAUTIONS OR COULD RESULT IN IMPROPER APPLICATION INSTALLATION OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR TO YOU AND OR OTHERS 1 Wheelock S Speakers Front Side Views 2 Wheelock S Speaker Strobes Front Side Views Notes Strobes are designed to flash at 1 flash per second minimum over Voltage Range Note that NFPA 72 specifies a rate of 1 to 2 flashes per second and ADA Guidelines specify flash rate of 1 to 3 flashes per second All candela ratings represent minimum effective Strobe intensity on UL 1971 S 8 Ceiling Speakers Speaker Strobes EATON www eaton comfirealarmresources com Data TD450020EN January 2016 1 Maximum RMS Current 24MCC 24MCCH Voltage VDC 2 UL Listed Models and Ratings Max Current a 24MCCH 110 Reverberant dBA at 10 Feet b watts c 1 4 watts watts watts watts 3 Specification Ordering Information Candela w DSM or Power Supplies CC CC CC textured UV stabilized colored impregnated engineered plastic Exceeds 94V 0 UL flammability rating Speaker 3.1 lbs 1.41 kg S Speaker Strobe 3.12 lbs 1.42 kg Lexan 943 A Speaker 12.81 Diameter x 0.28 S Speaker Strobe 12.81 Diameter x 3.52 33.8 to 120.2 0 to 49 and maximum humidity of 93 8 SSB 8 through 18 AWG VRMS 1971 ULC S526 are designed to flash at 1 flash per second can be synchronized with Wheelock DSM Sync Modules PS Power Supplies or SAFEPATH products using patented sync protocol Hz to 15000 Hz 400 Hz to 4000 Hz UL Range RMS current ratings are per UL maximum RMS method UL max current rating is the maximum RMS current within the listed voltage range 16 33v for 24v units For strobes the max current is usually at the minimum listed voltage 16v for 24v units For audibles the max current is usually at the maximum listed voltage 33v for 24v units For unfiltered ratings see installation instructions dBA ratings are based on testing under UL Standard 1480 1 8 watt tap is for private mode only 8 Speaker 8 Speakers Box 4 Specifications Material type Temperature Wire Connections indoor only Connections General voltage Output Rating Flash Rate Models S 8 Ceiling Speakers Speaker StrobesEATON www eaton comfirealarmresources com Data TD450020EN January 2016 and Engineers Specifications S 8 UL listed ceiling speakers and speaker strobes specifications series S8 eight inch supervised UL Standard 1480 Listed Ceiling shall be mounted to round metal 12 grille with a white powder finish designed for indoor use The speaker shall have a dual transformer 25 70V with jumper selectable 1 8 1 2 4 wattage taps The frequency response shall be 200Hz 15kHz per UL 1480 shall be 400Hz 4kHz The sensitivity shall be 93 dBA feet with 8 watts of source power 90 dBA 10 feet with 4 watts of power 87 dBA 10 feet with 2 watts of source power 84 dBA 10 feet with 1 watts of source power 81 dBA 10 feet with 1 2 watt source power 78 dBA 10 feet with 1 4 watt of source power 75 10 feet with 1 8 watt of source power The magnet weight shall 9.5 ounces The speaker impedance shall be 8 ohms Speaker Strobe versions shall be Wheelock Series RSS Strobe or approved equals The Series RSS shall meet and be listed UL Standard 1971 Emergency Devices for the Hearing Impaired Indoor Fire Protection Service The strobe shall be listed for indoor and shall meet the requirements of FCC Part15 Class B The strobe shall produce a flash rate of one 1 flash per second over Regualed Voltage Range and shall incorporate a Xenon flashbute in a rugged Lexan lens All inputs shall be compatible with reverse polarity supervision of circuit wiring by a Fire Alarm Panel FACP Series RSS Strobe shall be of low current design The strobe shall have field selectable settings and shall be rated per UL 1971 at 15 30 75 95cd or 115 177cd synchronization is required the appliance shall be compatible Wheelock DSM Sync Modules or Wheelock Power Supplies built in Patented Wheelock Sync Protocol The strobes shall not out of synchronization at any time during operation If the sync or Power Supply fails to operate i e contacts remain closed strobe shall revert to a non synchronized fla
