Wheelock SA-S speakers and strobes data sheet

Technical Data TD450047EN Supervised Self Amplified and Speaker Strobes Supervised Self Amplified Speakers and Speaker Strobes are to meet the critical needs for the life safety industry These and speaker strobes are a perfect fit for SCIF Sensitive Information Facilities room applications Approvals UL 1480 speakers UL 1638 UL 1971 speaker strobes Power input voltage 16.0 to 33.0 VDC Wall or ceiling models Speaker strobes utilize Wheelock synchronizable Multi Candela 1 watt high efficiency speaker Frequency range of 400Hz to 4000Hz Mounts onto a 4 square deep backbox with an extension ring SBB surface backbox February 2021 firealarmresources com Data TD450047EN February 2021 Power Input Voltage 16.0 33.0 VDC Appliance Input Level 0.5 V RMS or 25 V RMS Switch selectable Appliance Input Impedance 0.5 V Setting Greater than 400 Ohms equivalent to less than 1 1000 W 0.001 W or 1 mW load 25 V Setting Greater than 20 kOhms equivalent to less than 1 32 W 03125 W or 31.25 mW load Sound Level Speaker Amplifier Current Draw Level 6 Loudest 120mA RMS Level 5 97mA RMS Level 4 80mA RMS Level 3 68mA RMS Level 2 60mA RMS Level 1 Lowest 54mA RMS read these specifications and associated installation instruc before using specifying or installing this product Visit Eaton com for current installation instructions Notes Strobes are designed to flash at 1 flash per second minimum over Voltage Range Note that NFPA 72 specifies a rate of 1 to 2 flashes per second and ADA Guidelines specify flash rate of 1 to 3 flashes per second All candela ratings represent minimum effective Strobe intensity on UL 1971 The volume level has been adjusted to the factory default dBA However the installer may need to adjust the volume set to better suit the application 1 SA S70 Speaker Strobes Front Side Views wall mount 2 SA S90 Speaker Strobes Front Side Views ceiling mount Speakers and Speaker StrobesEATON www eaton comfirealarmresources com Data TD450047EN February 2021 1 Average Strobe Current Max Current a 16 33 VDC 16 33 VFWR 16 33 VDC 16 33 VFWR 2 dBA Sound Output level SA speakers Reverberant Input RMS current ratings are per UL maximum RMS method UL max current rating is the maximum RMS current within the listed voltage range 16 33v for 24v units For strobes the max current is usually at the minimum listed voltage 16v for 24v units For audibles the max current is usually at the maximum listed voltage 33v for 24v units For unfiltered ratings see installation instructions For information on mounting options refer to specification sheet TD450028EN 3 Specification Ordering Information b Lettering Candela Red White UL Strobes X X X X X X X X 6175 9784 6153 X X X Amber X X X X X X X X X X X X X Speakers and Speaker StrobesEATON www eaton comfirealarmresources com Data TD450047EN February 2021 and Engineers Specifications SA S Self Amplified Speakers and Speaker Strobes shall be UL under Standards UL 1480 Standard for Speakers for Fire Emergency and Commercial and Professional Use The Strobe models shall be UL Listed under Standards UL 1971 for Signaling Devices for the Hearing Impaired and for fire protection service Series SA S Self Amplified Speakers and Speaker Strobes shall a choice of 6 different sound output levels and operate audio input levels of 0.5 V RMS and 25 V RMS all by means of switch settings Series SA S Self Amplified Speakers and Speaker Strobes incorporate a high efficiency speaker for maximum output at power across a frequency range of 400Hz to 4000Hz and a sealed back construction for extra protection and improved All inputs shall be polarized for compatibility with standard polarity supervision of circuit wiring via a Control Panel SA S Series Multi Candela Speaker Strobe models shall offer selectable light output intensities in one unit and can provide non synchronized strobe appliance when connected directly to a Alarm Control Panel FACP or provide a synchronized strobe when used in conjunction with a Dual Sync Module DSM Wheelock Power Supplies listed for synchronization ceiling mount Speaker Strobe models shall provide 15 30 75 95 options The wall mount Speaker Strobe models shall provide candela options All strobe candela options shall be field via a tamper resistant selector switch Strobe uses a Xenon flashtube with solid state circuitry enclosed a rugged polycarbonate lens to provide maximum visibility and for effective visible signaling SA S Series shall be listed for indoor use to continuous development of our products specifications and offerings are subject to change without notice in accordance with Cooper Inc dba Eaton standard terms and conditions ENCOURAGE AND SUPPORT NICET CERTIFICATION YEAR WARRANTY is a registered trademark All other trademarks are property of their respective owners SA S Speakers and Speaker Strobes Eaton1000 Eaton BoulevardCleveland OH 44122United StatesEaton comEatonLife safety mass notification solutions273 Branchport Ave Long Branch NJ 07740www eaton com massnotification 2021 EatonAll Rights ReservedPrinted in USAPublication No TD450047ENFebruary 2021firealarmresources com
